TOS W100A Horizontal Boring Machine

Price 100000 INR/ Piece

Get a Price/Quote

TOS W100A Horizontal Boring Machine Specification

Accuracy
High precision, 0.01 mm repeatability

Frequency
50 Hz

Motor Power
11 kW

Model No
W100A

Frame Type
Heavy-duty cast iron frame

Noise Level
<80 dB

Features
Robust structure, adjustable work table, high reliability

Drive
Mechanical

Control System
Manual Controls

Production Capacity
High (varies with setup)

Lubricating System
Centralized Lubrication

Operating Temperature
5C - 40C

Cooling System
Integrated Coolant System

Voltage
400 V

Machine Type
Horizontal Boring Machine

Power Rating
11 kW

Product Type
Horizontal Boring Machine

Technology
Conventional

Power Source
Electric

Operating Type
Semi Automatic

Power
11 kW

Surface Treatment
Painted

Dimension (L*W*H)
4800 x 2300 x 2400 mm

Weight (kg)
9500 kg

Color
Industrial Blue / Grey

Usage & Applications
Boring, drilling, milling and facing operation in engineering workshops

About TOS W100A Horizontal Boring Machine

Make - TOS (Czech Republic)

Model - W100A

Spindle Diameter - 100 mm

Table Size - 1250 mm x 1250 mm

Cross Travel - 1600 mm

Vertical Travel - 1120 mm

Longitudinal Travel - 1250 mm (with Tail-Stock equipped)

Spindle Travel - 900 mm

Facing Chuck Diameter - 600 mm

Spindle Taper - MT 6

Spindle Speeds - 7 rpm to 1120 rpm

- Complete with Facing Chuck & Tailstock.

- Equipped with 3-Axis DRO.

- With Angle Plate, Tools and other accessories etc.

- Machine is in excellent working condition.

Video link - https://youtu.be/mpQd6cidIEg

High Precision and Versatility

The TOS W100A Horizontal Boring Machine offers exceptional accuracy with 0.01 mm repeatability, making it ideal for precise engineering tasks. Its robust 100 mm spindle, adjustable 360 rotating worktable, and wide longitudinal and cross travels enable the machine to accommodate a diverse range of large workpieces. This model is suitable for boring, drilling, milling, and facing operations, providing flexibility for workshops and manufacturing units.

Enhanced Durability and Safety

Built with a heavy-duty cast iron frame, the W100A ensures long-term durability and stability even during extended use. Safety is paramount, featuring overload protection, an emergency stop mechanism, and comprehensive operation and maintenance manuals. The integrated lubrication and coolant systems help maintain machine performance and prolong component life.

Powerful Performance and User-friendly Operation

Equipped with an 11 kW electric motor and mechanical drive, the W100A delivers strong and consistent performance. Manual controls allow for semi-automatic operation, while standard industrial electrical fittings simplify installation. The ergonomic interface, thoughtful control layout, and clear documentation facilitate efficient machine setup and operation for both seasoned machinists and new users.

FAQs of TOS W100A Horizontal Boring Machine:

Q: How does the TOS W100A Horizontal Boring Machine ensure high accuracy during operations?

A: The TOS W100A is engineered for high-precision tasks, featuring 0.01 mm repeatability and robust mechanical construction. The adjustable worktable, precise spindle extension, and consistent feed steps help maintain accuracy for all boring, drilling, and milling operations.

Q: What types of workpieces and materials can this machine handle?

A: The W100A is suitable for a wide range of engineering applications, handling workpieces up to 3000 kg. Its large table size and powerful spindle enable machining of steel, cast iron, and other industrial materials for boring, drilling, milling, and facing tasks.

Q: When should the integrated coolant and lubrication systems be used?

A: Both systems are designed for continuous use during machining processes. The centralized lubrication ensures moving parts remain properly oiled, while the integrated coolant system maintains optimal temperature, preventing overheating and prolonging tool life.

Q: Where can this machine be installed, and what are the ambient requirements?

A: The TOS W100A is ideal for installation in industrial workshops or manufacturing facilities. It operates reliably within an ambient temperature range of 5C to 40C, requires a 400 V, 50 Hz power supply, and should be used in well-ventilated spaces to maintain safety and efficiency.

Q: What is the process for changing tools and setting up for different machining operations?

A: Tool changes are performed manually using the keyed chuck and ISO 50 spindle taper. The operation and maintenance manuals provide clear instructions for safe and efficient tool setups. The worktable and spindle settings are easily adjustable to suit various machining requirements.

Q: What are the main benefits of using the TOS W100A in a workshop?

A: Key benefits include its high precision, flexibility for multiple machining processes, durable construction, and comprehensive safety features. The machines user-friendly interface and detailed manuals help reduce operator error while enhancing productivity.
