Ajax England Pure Vertical Milling Machine

Name: Ajax England Pure Vertical Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ajax England Pure Vertical Milling Machine Specification

Rotation
Clockwise/Counterclockwise

Model
Ajax England Pure Vertical

Product Type
Vertical Milling Machine

General Use
Heavy Duty Milling Operations

Material
Cast Iron & Steel

Type
Pure Vertical

Capacity
3001000 kg/hr (Depending on Job)

Weight (kg)
Approx. 1350 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
1370 mm x 290 mm (Approx)

Table Slide Way
Dovetail

Floor Space
1960 mm x 1770 mm (Approx)

Spindle Speed
502000 rpm (Variable Speed)

Power
3 HP

Voltage
415 V, 3 Phase

Dimension (L*W*H)
1960 mm x 1770 mm x 2100 mm (Approx)

Feature
Precision Machined Dovetail Guideways, Heavy Duty Spindle, Robust Construction

Color
Green & White

Max Distance Spindle to Table
420 mm

Coolant System
Yes, Fitted

Table Feed
Manual & Power

Max Distance Spindle to Column
345 mm

Number of T-slots
3

T-slot Size
16 mm

Quill Travel
127 mm

Condition
Reconditioned/Good Working Order

Spindle Taper
ISO 40

Lubrication System
Automatic

Ajax England Pure Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ajax England Pure Vertical Milling Machine

Make - Ajax (England)

Table Size - 1650 mm x 355 mm

XYZ Travel - 1250 mm x 315 mm x 475 mm

Spindle Speeds - 45 rpm to 1400 rpm

Spindle Taper - ISO 50

Table Feed Rates - 15 mm/min to 500 mm/min

- Vertical Milling Head can be Tilted.

- Rotating type Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/YD4GWuuEuxk

Precision Engineering for Demanding Jobs

Built with robust cast iron and steel, the Ajax England Pure Vertical Milling Machine provides exceptional durability and stability for sustained heavy-duty use. Its machined dovetail guideways and heavy-duty spindle enhance accuracy, making it suitable for intricate and demanding milling applications. With its versatile speed range, it's tailored for engineers and machinists requiring reliable manual control.

Efficient Manual Control and Maintenance

The machine features simple manual controls alongside automatic lubrication and a fitted coolant system, reducing the need for frequent maintenance and ensuring consistent performance. Power and manual table feeds add convenience, allowing operators to adjust settings efficiently during various milling processes. Its reconditioned state ensures good working order, making it a cost-effective solution for businesses.

FAQ's of Ajax England Pure Vertical Milling Machine:

Q: How do I operate the Ajax England Pure Vertical Milling Machine for heavy-duty tasks?

A: You can operate the machine using its manual control system, selecting the appropriate spindle speed (50-2000 rpm) and adjusting the feed according to your task. Both manual and power table feeds are available, making it suitable for various heavy-duty milling operations.

Q: What benefits do the precision machined dovetail guideways and robust construction offer?

A: The precision dovetail guideways and robust cast iron and steel construction provide outstanding stability, accuracy, and durability, ensuring consistent milling performance and minimizing vibration during operation.

Q: When is it appropriate to use the power feed instead of the manual table feed?

A: The power feed is ideal for extended or repetitive milling operations that require consistent, uniform movement of the table, improving efficiency and reducing operator fatigue. Manual feed is best for detailed or intricate adjustments.

Q: Where is the Ajax England Pure Vertical Milling Machine manufactured and exported from?

A: This vertical milling machine is manufactured, exported, and supplied from the United Kingdom by Ajax England and associated partners.

Q: What is the process for maintaining the lubrication and coolant systems?

A: Maintenance is minimal because the lubrication is automatic and the coolant system is already fitted. Regularly inspect fluid levels and check system functionality to ensure reliable operation.

Q: Who can benefit from using this milling machine?

A: Manufacturers, engineers, and technicians involved in heavy-duty milling processes, especially those who require manual operation and high-capacity throughput (300-1000 kg/hr), will benefit from the machine's capacity, reliability, and precise control.
