Alpa 200 mm x 450 mm Surface Grinding Machine

Price 45000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Alpa 200 mm x 450 mm Surface Grinding Machine Specification

Rotation
Clockwise

Model
Alpa 200x450

Product Type
Surface Grinding Machine

General Use
Surface Grinding

Material
Cast Iron (Body)

Type
Horizontal

Capacity
Heavy Duty

Weight (kg)
Approx 950 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
No

Control System
Manual

Table Size
200 mm x 450 mm

Table Slide Way
V & Flat

Magnetic Chuck Size
200 mm x 450 mm

Grinding Wheel Size
200 mm x 13 mm x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
450 mm

Floor Space
1200 mm x 1000 mm

Fuel Tank Capacity
30 Liters (Hydraulic Tank)

Spindle Speed
2800 RPM

Power
1.5 HP

Voltage
415 V

Dimension (L*W*H)
1200 mm x 1000 mm x 1750 mm

Feature
Precision Grinding, Robust Structure

Color
Standard Grey/Blue

Max Table Travel (Longitudinal)
475 mm

Cross Feed on Hand Wheel
150 mm

Lubrication System
Centralized

Coolant Pump
Included

Main Motor Power
1.5 kW

Table Speed (Longitudinal)
3-25 m/min

Max Distance from Table Surface to Spindle Center
350 mm

Max Table Travel (Crosswise)
225 mm

Hand Wheel Graduation
0.01 mm/rev

Surface Finish (Ra)
0.003 mm

Alpa 200 mm x 450 mm Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Alpa 200 mm x 450 mm Surface Grinding Machine

Make - Alpa (Italy)

Model - RT 450

Magnet Size - 200 mm x 450 mm

Longitudinal Travel - 500 mm

Cross Travel - 220 mm

Grinding Wheel Size - Diameter 225 mm x 25 mm Width

Max. Distance b/w Magnet to Wheel-Axis - 375 mm

Least Count - 1 Micron

Grinding Wheel Motor - 2.2 kW

- Micro-Feed Adjustments in both Vertical & Cross Travel.

- Features like Motorised Rapid Vertical Travel, Auto-Cut etc.

- Equipped with a top mounted Wheel Dresser.

- Complete with Coolant Tank.

- Machine is in excellent working condition.

Video of The machine -

https://youtu.be/51k9gnNLF64

Precision Surface Grinding

The Alpa 200x450 is purpose-built for delivering outstanding accuracy in surface grinding. With a table size of 200 mm x 450 mm and maximum longitudinal travel of 475 mm, it accommodates a variety of workpiece sizes. Manual controls and hand wheel graduation of 0.01 mm enhance operator precision, ensuring consistent, smooth finishing suitable for high-standard applications.

Robust Construction & Performance

Crafted with a robust cast iron frame and designed for heavy-duty operation, this machine promises durability even under intensive industrial use. The centralized lubrication system and included coolant pump support longer operational life and prevent wear, while a powerful 1.5 kW motor ensures efficient, high-speed grinding for various materials.

Ease of Operation and Maintenance

Despite its industrial-grade performance, the Alpa 200x450 remains accessible with manual controls and semi-automatic features. The clear graduation on the hand wheel, V & flat slideways, and ergonomic design streamline daily operation and routine maintenance, allowing operators to focus on productivity with minimal downtime.

FAQs of Alpa 200 mm x 450 mm Surface Grinding Machine:

Q: How does the Alpa 200x450 ensure precise surface grinding results?

A: The machine offers manual cross feed via a hand wheel with fine graduation (0.01 mm/rev), stable V & Flat table slideways, and a precision magnetic chuck, allowing operators to achieve high-accuracy surface finishes, further supported by a consistent grinding wheel speed of 2800 RPM.

Q: What types of parts can be processed on the Alpa 200x450 Surface Grinding Machine?

A: This model is capable of grinding flat surfaces on a wide range of metal and alloy components, typically used in toolrooms, factories, and workshops requiring precision and heavy-duty performance for items up to a maximum of 450 mm in length and 200 mm in width.

Q: When should the lubrication and coolant systems be checked?

A: Both the centralized lubrication system and the built-in coolant pump should be inspected daily before operation to ensure optimal functionality, prevent excessive wear, and support long-term machine reliability.

Q: Where is the Alpa 200 mm x 450 mm Surface Grinding Machine manufactured?

A: This machine is manufactured in Italy and distributed worldwide. It is suited for exporters, importers, manufacturers, and suppliers seeking high-quality, precision grinding solutions for various industries.

Q: What is the process for adjusting grinding parameters on this model?

A: Grinding parameters such as feed rate, table speed (3-25 m/min), and spindle speed (2800 RPM) are manually set using the machines accessible control systems, allowing users to tailor operations according to specific material and finish requirements.

Q: How is the machine maintained for long-term durability?

A: Routine checks of the centralized lubrication system, cleaning of the coolant pump, timely replacement of the grinding wheel, and regular inspection of slideways and the magnetic chuck help sustain robust machine performance and extend operational life.

Q: What are the main benefits of using this surface grinder?

A: Key benefits include high-precision grinding, robust construction for heavy-duty use, easy operation with manual controls, and reliable, long-lasting performance thanks to advanced lubrication and cooling systems, all packaged in a machine suitable for a variety of industrial sectors.
