Anbas Italy Fully Automatic Bandsaw Machine

Name: Anbas Italy Fully Automatic Bandsaw Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Anbas Italy Fully Automatic Bandsaw Machine Specification

Noise Level
Below 80 dB

Frame Type
Heavy Duty Rigid Frame

Production Capacity
Up to 500 cuts/hour

Model No
ANBAS-FA-Italy

Drive
Hydraulic Drive

Lubricating System
Automatic Lubrication

Cooling System
Flood Coolant

Power Rating
5 HP

Voltage
415 V

Features
Auto Material Feeding, High Efficiency, Rigid Construction, Safety Guards, Blade Tension Indicator

Control System
Programmable Logic Controller (PLC)

Frequency
50 Hz

Accuracy
0.2 mm

Operating Temperature
5C 45C

Connectivity Options
Panel Mounted Interfaces

Machine Type
Hydraulic Automatic Bandsaw

Motor Power
5 HP

Product Type
Fully Automatic Bandsaw Machine

Technology
CNC / PLC Controlled

Power Source
Electric

Operating Type
Automatic

Power
5 kW

Pressure
Hydraulic Controlled

Surface Treatment
Powder Coated

Dimension (L*W*H)
2450 x 1300 x 1600 mm

Weight (kg)
1100 kg

Color
Blue & Silver

Usage & Applications
Industrial Metal Cutting

Blade Speed Control
Variable - Inverter Controlled

Maximum Cutting Capacity (Round)
280 mm

Saw Blade Size
3505 x 27 x 0.9 mm

Blade Guide
Carbide & Roller Guides

Finish
Corrosion Resistant

Coolant Tank Capacity
40 Liters

Material of Construction
Alloy Steel & MS

Hydraulic Oil Tank Capacity
60 Liters

Safety Features
Emergency Stop Button, Overload Protection

WorkingSpeed
24 90 m/min (Variable)

Main Drive Type
V-Belt & Gearbox

User Interface
Touchscreen (HMI)

Maximum Cutting Capacity (Square)
250 x 250 mm

Clamping System
Hydraulic Vice

Anbas Italy Fully Automatic Bandsaw Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Anbas Italy Fully Automatic Bandsaw Machine About

Make - Anbas (Italy)

Model - TR-AU 150

Cutting Capacity (for Round) - 150 mm

Max. Travel for Auto-Feed Vice - 600 mm (single time)

Max. No. of Travels for Auto-Feed Vice - 9 Times

Max. Job Length for Auto-Feed - 5400 mm

Type - Fully Automatic ; Hydraulic.

- Can be used for Manual, Semi-Automatic & Full Automatic Mode.

- Complete with Coolant Tank, Pump and Splash Guards.

- Hand-Wheel Control for adjusting Stock Length.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/bArNKc41sUw

High Precision Industrial Cutting

Designed for demanding industrial applications, this bandsaw ensures accurate cuts on alloy steel and mild steel. Its automated hydraulic feed and programmable logic controller (PLC) maximize consistency, making it suitable for high-volume production lines. The combination of carbide and roller guides delivers stability and minimizes blade deviation, catering to both square and round profiles.

Advanced Automation and User Interface

Featuring a modern touchscreen HMI, operators can effortlessly control cutting parameters and monitor machine status. The inverter-controlled blade speed and hydraulic vice clamping system are tailored for flexible operation across various materials. Automatic feeding further enhances efficiency, while panel-mounted interfaces allow seamless connectivity and control integration.

Safety and Durability for Industrial Workflows

Safety is built-in with features such as an emergency stop button, overload protection, and robust safety guards. The machine's powder-coated, corrosion-resistant frame is engineered for long-term durability amid demanding industrial conditions. Its quiet operation and automatic lubrication system reduce maintenance, supporting continuous, safe, and reliable output.

FAQ's of Anbas Italy Fully Automatic Bandsaw Machine:

Q: How does the automatic feeding feature benefit industrial users?

A: Automatic material feeding ensures consistent throughput and reduces manual intervention, enabling higher production capacity-up to 500 cuts per hour. This automation decreases labor requirements and improves safety during high-volume operations.

Q: What types of materials can the Anbas Italy Fully Automatic Bandsaw cut?

A: This machine is suitable for cutting alloy steel, mild steel (MS), and other industrial metals. Its rigid frame and adjustable hydraulic pressure make it ideal for a wide variety of industrial metal cutting tasks.

Q: When should the hydraulic oil and coolant tanks be refilled or maintained?

A: Regular maintenance is advised; the 60-liter hydraulic oil tank and 40-liter coolant tank should be checked daily or after every production shift to ensure optimal machine performance and cooling efficiency.

Q: Where is the best place to use this bandsaw machine?

A: This fully automatic bandsaw is best deployed in manufacturing plants, fabrication workshops, and other industrial environments where high-precision, high-volume metal cutting is required.

Q: What process does the machine follow to achieve precise cuts?

A: The machine uses a programmable logic controller (PLC) that automates material feeding, blade speed adjustment, and hydraulic pressure. Carbide and roller guides stabilize the blade, while the flood coolant system maintains temperature and accuracy for consistent, clean cuts.

Q: How does the machine ensure operator safety during use?

A: Operator safety is ensured thanks to the emergency stop button, overload protection circuit, robust safety guards, and a blade tension indicator. These features collectively reduce the risk of accidents during operation and maintenance.

Q: What are the main operational benefits of the Anbas Italy bandsaw machine?

A: Key operational benefits include high cutting accuracy (0.2 mm), efficient output, quiet performance (below 80 dB), robust safety measures, and simple, touchscreen-based control. These features contribute to increased productivity and reliability for industrial metal cutting.
