Arter Horizontal Rotary Surface Grinder

Price 12000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Arter Horizontal Rotary Surface Grinder Specification

Rotation
Table Rotary

Model
Arter Type

Product Type
Rotary Surface Grinder

General Use
Industrial Surface Grinding

Material
Mild Steel

Type
Horizontal Rotary

Capacity
Standard

Weight (kg)
2850 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
18 Inch

Table Slide Way
V & Flat Guideways

Magnetic Chuck Size
18 Inch

Grinding Wheel Size
16 Inch

Grinding Wheel Speed
1440 rpm

Grinding Length
457 mm

Floor Space
1900 x 1350 mm

Spindle Speed
1440 rpm

Power
5 HP

Voltage
415 V

Dimension (L*W*H)
1900 x 1350 x 1950 mm

Feature
Precision Surface Grinding

Color
Green

Arter Horizontal Rotary Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Arter Horizontal Rotary Surface Grinder

Make - Arter (USA)

Model - A3-16

Magnetic Chuck Diameter - 400 mm

Max. Swing inside Covers - 550 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Tilting Angle of Work-Table - +10 degree to -10 degree

Max. Height of Job - 225 mm

Magnetic Chuck Speeds - 30 rpm to 150 rpm

- Complete with Coolant Tank & Pump.

Video Link -

https://youtu.be/NcgrOX6VgWI

Precision Engineering for Industrial Demands

Engineered for rigorous industrial workflows, the Arter Horizontal Rotary Surface Grinder guarantees reliable, high-precision results. Its mechanical rotary table and robust guideways facilitate smooth, steady motion and exacting tolerances. The centralized lubrication and efficient coolant system prolong machine life and ensure continuous, top-tier operation, making it an ideal choice for those prioritizing accuracy and reliability.

Versatile Grinding Capabilities

This machine accommodates a range of workpiece sizes up to 250 mm in height and 400 kg in weight, ideal for standard industrial surface grinding requirements. Its 18-inch magnetic chuck ensures secure component clamping, supporting efficient and flexible material processing. The variable working speed and 16-inch grinding wheel provide versatility for multiple metal fabrication and finishing applications.

User-Friendly Features for Better Control

Equipped with a manual control system, the Arter Surface Grinder allows skilled operators to tailor each job with precision. The non-CNC design ensures straightforward maintenance and adjustments, while the easy-to-access controls make the grinder suitable for both high-volume production and specialized job shop environments.

FAQs of Arter Horizontal Rotary Surface Grinder:

Q: How does the Arter Horizontal Rotary Surface Grinder achieve high-precision surface finishes?

A: The grinder utilizes a sturdy construction with V & flat guideways and a stable 18-inch magnetic chuck to securely hold workpieces. Combined with a precisely balanced 16-inch grinding wheel and variable working speeds, this setup delivers fine, consistent surface finishes on metal components.

Q: What is the maximum workpiece size and weight the machine can handle?

A: The maximum workpiece height is 250 mm, and the magnetic chuck can securely clamp workpieces weighing up to 400 kg, making this grinder suitable for most industrial metal surface grinding needs.

Q: When is it recommended to use this grinder for surface finishing tasks?

A: This machine is best suited for high-precision metal surface grinding in industrial settings, especially when a non-computerized, manually operated solution is preferred. It excels in both precision finishing and regular batch production applications.

Q: Where can the Arter Horizontal Rotary Grinder be installed for optimal performance?

A: The grinder should be placed on a stable, level surface with enough space to accommodate its 1900 x 1350 x 1950 mm dimensions, ideally in an industrial workshop or manufacturing facility equipped with a suitable three-phase 415 V power supply.

Q: What is the process of operating the grinder?

A: Operators manually set up the workpiece on the magnetic chuck, select the desired table and spindle speeds, and engage the mechanical table drive. Centralized lubrication and a built-in coolant system maintain optimal grinding conditions throughout the operation.

Q: How does the centralized lubrication improve the grinders efficiency?

A: Centralized lubrication distributes oil evenly to all key moving parts, reducing wear and tear, enhancing operational smoothness, and minimizing maintenance requirements, which together extend the lifespan and reliability of the machine.

Q: What are the main benefits of using the Arter Horizontal Rotary Surface Grinder?

A: Key benefits include exceptional surface finish quality, robust construction for durability, straightforward manual operation, and operational versatility for various industrial metalworking applications, making it a dependable choice for exporters, importers, and manufacturers.
