Barber Colman 6-10 Horizontal Gear Hobbing Machine

Name: Barber Colman 6-10 Horizontal Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Barber Colman 6-10 Horizontal Gear Hobbing Machine Specification

Machine Type
Horizontal Gear Hobbing Machine

Weight
Approx 5200 kg

Color
Industrial Green

Dimension (L*W*H)
2950 mm x 1700 mm x 1700 mm

Used For
Gear manufacturing cutting various gear types

Capacity
Maximum gear diameter up to 600 mm

Voltage
415 V

Power
12 kW

Condition
Used

Output
High accuracy gears

Feature
Robust construction, precision machining capability

Spindle Speeds
10 steps, 32 to 200 rpm

Table Diameter
520 mm

Coolant System
Integrated coolant pump and reservoir

Machine Material
Cast Iron & Steel components

Max Gear Width
200 mm

Lubrication System
Automatic central lubrication

Number of Feeds
12 feeds, 0.4 to 5.05 mm/rev

Max Module Cut
10

Floor Space Required
Approx 5 m²

Control System
Manual

Table Rotation Range
360°

Hob Arbor Diameter
32 mm

Accessories Included
Standard change gears, hob arbor, manuals

Barber Colman 6-10 Horizontal Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Barber Colman 6-10 Horizontal Gear Hobbing Machine

Make - Barber Colman (USA)

Model - 6-10

Max. Gear Diameter - 6" (152 mm)

Max. Gear Width - 10" (254 mm)

Max. DP - 16 DP (1.6 Module)

Max. Distance between Work-Spindle Face to Center - 15.75" (400 mm)

Max. Hob Carriage Travel - 10.5" (267 mm)

Max. Hob Diameter - 2.0625" (52.4 mm)

Hob Speeds - 133 rpm to 533 rpm

Work Spindle Bore - 1.03" (26.1 mm)

- Complete with Change Gears, Mandrels, Coolant Pump etc.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/vYqHcMS6Qr8

Precision and Performance for Gear Manufacturing

Designed for dependable gear production, the Barber Colman 6-10 Horizontal Gear Hobbing Machine delivers precision with its sturdy cast iron and steel build. Capable of handling modules up to 10 and gear diameters as large as 600 mm, this machine ensures high accuracy and repeatability. Its versatile spindle speeds and feeds accommodate a broad spectrum of gear-cutting requirements, making it suitable for manufacturers, exporters, and suppliers alike.

Integrated Systems for Efficient Operation

Enhancing workflow, the machine integrates both a coolant system with pump and reservoir, and an automatic central lubrication system. These features reduce maintenance downtime and improve machining consistency, resulting in high-quality gear outputs. The spacious table and easy manual control system streamline the gear cutting process, while included accessories offer added value to operators and businesses.

FAQ's of Barber Colman 6-10 Horizontal Gear Hobbing Machine:

Q: How does the Barber Colman 6-10 Gear Hobbing Machine ensure precision in gear cutting?

A: The machine combines robust cast iron and steel construction with precise spindle speed (32-200 rpm) and feed rate (0.4-5.05 mm/rev) controls, enabling it to efficiently cut gears up to 600 mm in diameter with high accuracy and repeatability.

Q: What types of gears can be manufactured using this machine?

A: This horizontal gear hobbing machine is suitable for cutting a variety of gear types, including spur, helical, and worm gears, catering to diverse industrial and manufacturing needs.

Q: When should I use the integrated coolant and lubrication systems?

A: Both systems operate continuously during gear cutting, helping to maintain optimal tool life and part quality by reducing heat buildup and ensuring smooth machine operation.

Q: Where can this machine be installed and how much space does it require?

A: The Barber Colman 6-10 requires about 5 square meters of floor space and can be installed in workshops, gear manufacturing plants, or industrial facilities with appropriate power supply (12 kW at 415 V).

Q: What is the process for changing the gear module or setting different cutting feeds?

A: Operators can change the module by selecting the correct hob and adjusting the machine's change gears and hob arbor. Feed rates can be set through the machine's manual controls to match the desired gear cutting parameters.

Q: How does the robust construction benefit daily usage and machine longevity?

A: The heavy-duty cast iron and steel composition minimizes vibration and enhances durability, translating to consistent gear quality and extended service life even under continuous use.

Q: What accessories are included with this gear hobbing machine?

A: The machine is supplied with standard change gears, a hob arbor, and operation manuals, ensuring users have the essential components to begin operations directly after installation.
