Cincinnati Double Spindle Milling Machine

Name: Cincinnati Double Spindle Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Cincinnati Double Spindle Milling Machine Specification

Model
Cincinnati Double Spindle

Rotation
Clockwise & Counterclockwise

Product Type
Double Spindle Milling Machine

General Use
Heavy-duty metalworking and industrial milling operations

Material
Cast iron body and steel components

Type
Horizontal Spindle

Capacity
Up to 1000 kg workpiece

Weight (kg)
4200 kg

Computerized
No

Automatic
Semi-automatic (manual/manual feed)

CNC Or Not
No

Control System
Manual

Table Size
1500 mm x 350 mm

Table Slide Way
Box type

Floor Space
2700 mm x 2200 mm

Spindle Speed
45 to 1440 rpm

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
2700 mm x 2200 mm x 1800 mm

Feature
Double spindle, rigid construction, high precision

Color
Cincinnati industrial green

Max Milling Width
350 mm

Overarm
Adjustable heavy-duty

Number of Spindles
2

Precision
±0.02 mm

Spindle Taper
ISO 50

Working Speed
Variable, mechanical adjustment

Table Travel (Longitudinal)
1200 mm

Table Travel (Cross)
350 mm

Coolant System
Built-in, recirculating

Drive Type
Mechanical gear drive

Main Motor
10 HP

Feed Range
18 to 720 mm/min

Lubrication
Centralized automatic lubrication system

Cincinnati Double Spindle Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Cincinnati Double Spindle Milling Machine

Make - Cincinnati (USA)

Table Size - 1385 mm x 255 mm

XYZ Travel - 670 mm x 225 mm x 375 mm

Horizontal Spindle Speeds - 25 rpm to 1500 rpm

Horizontal Spindle Taper - ISO 50

Vertical Spindle Speeds - 100 rpm to 1030 rpm

Vertical Spindle Taper - ISO 50

Table Feed Rates of Travel - 6.35 mm/min to 760 mm/min

Center Height of Dividing Head - 140 mm

- Double Swivel type Vertical Milling Head.

- Equipped with a Dividing Head & Tail-Stock.

- Over-Arm Travel suitable for extra width jobs.

- Rotating type Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/DW2XmQAmMc4

Unmatched Double Spindle Productivity

Enhance your milling capabilities with the Cincinnati Double Spindle Milling Machine. Its dual spindle design allows simultaneous machining, significantly increasing productivity on large or complex workpieces. The adjustable overarm and robust construction ensure outstanding stability and reduced setup times, making it ideal for busy industrial environments where high-precision results are crucial.

Engineered for Durability and Precision

With a heavy-duty cast iron frame, steel components, and a rigid box-type table slide way, this machine guarantees precision up to 0.02 mm. The centralized automatic lubrication and built-in coolant system minimize wear and thermal distortion, ensuring consistent accuracy even during prolonged shifts. Designed to handle demanding metalworking tasks, the Cincinnati Double Spindle model stands out for reliability and efficiency.

FAQs of Cincinnati Double Spindle Milling Machine:

Q: How does the double spindle feature benefit heavy-duty metalworking operations?

A: The double spindle design allows operators to perform simultaneous milling tasks, reducing cycle times and increasing throughput. This is especially useful for machining large or complex components efficiently, resulting in higher productivity and lower operational costs.

Q: What is the maximum table travel and milling width of the Cincinnati Double Spindle Milling Machine?

A: The machine offers a maximum longitudinal table travel of 1200 mm, a cross travel of 350 mm, and can mill workpieces up to 350 mm wide, accommodating large or multiple parts with ease.

Q: When should I use the built-in coolant and automatic lubrication systems?

A: The built-in recirculating coolant system and centralized automatic lubrication should be used during all milling operations to maintain tool life, minimize heat buildup, and ensure smooth, precise machine movement. These features greatly enhance performance in continuous or heavy-duty use.

Q: Where can this milling machine be installed and what are its floor space requirements?

A: It is suited for industrial workshops, manufacturing plants, or heavy-duty metalworking facilities. The recommended floor space for installation is 2700 mm x 2200 mm, ensuring ample room for operation and maintenance.

Q: What is the process for adjusting spindle speed and table feed rate?

A: Spindle speed (45 to 1440 rpm) and feed rate (18 to 720 mm/min) are both mechanically adjustable via the machines gear drive controls. This flexible range enables operators to match tooling and material needs for optimal performance.

Q: How precise is the Cincinnati Double Spindle Milling Machine, and what types of workpieces can it handle?

A: The machine is engineered to deliver precision up to 0.02 mm and can accommodate workpieces weighing up to 1000 kg, making it suitable for high-accuracy tasks on large metal components.

Q: What are the main benefits of choosing a manual, non-computerized milling machine like this model?

A: Manual control provides greater operator flexibility, cost savings on electronic maintenance, and ease of use for skilled machinists working on custom or low-volume production runs.
