Colchester Student 650 mm Lathe Machine

Name: Colchester Student 650 mm Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester Student 650 mm Lathe Machine Specification

Product Type
Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 20 mm (dependent on tool and material)

Cutting Speed
25-2000 RPM

CNC Or Not
No, Manual Lathe

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
330 mm (over bed)

Voltage
415 V, 3 Phase

Weight (kg)
950 kg (approx.)

Dimension (L*W*H)
1700 mm x 800 mm x 1220 mm

Capacity
650 mm between centers

Feature
Robust Construction, High Precision, Hardened Bed Ways

Color
Standard Industrial Green/Grey

Cross Slide Travel
175 mm

Lead Screw Diameter
25 mm

Distance Between Centers
650 mm

Tool Post
4-way turret

Spindle Speed Range
25-2000 RPM (Variable)

Thread Cutting Metric Range
0.2 - 7 mm

Spindle Bore
40 mm

Bed Width
187 mm

Bed Type
Gap Bed

Chuck Size
200 mm (standard 3 jaw)

Power Consumption
2.2 kW

Thread Cutting Inch Range
2 - 72 TPI

Number of Spindle Speeds
12

Tailstock Quill Travel
100 mm

Frequency
50 Hz

Colchester Student 650 mm Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Colchester Student 650 mm Lathe Machine

Make - Colchester (England)

Model - Student 1800

Center Height - 165 mm

Max. Length of Job - 650 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 210 mm

Max. Job Diameter in Gap - 480 mm

4-Jaw Chuck Diameter - 255 mm

3-Jaw Chuck Diameter - 200 mm

Bed Width - 230 mm

Spindle Speeds - 22 rpm to 1800 rpm

Spindle Bore - 40 mm

- Equipped with DRO.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/jegTs40b8lg

Precision and Versatility in Turning

With a variable spindle speed range of 252000 RPM, the Colchester Student Lathe adapts seamlessly to diverse turning and threading operations. Whether fabricating complex components or performing general repairs, its 12 selectable speeds and robust construction deliver consistent results. The gap bed design offers exceptional flexibility for larger workpieces, while the 330 mm maximum swing diameter enhances its versatility.

Robust Construction with User-Friendly Features

Constructed from durable cast iron and featuring hardened bed ways, this lathe ensures longevity and minimal maintenance. The 4-way turret tool post, standard 200 mm 3-jaw chuck, and 175 mm cross slide travel allow for swift tool changes and precision control, making it suitable for experienced machinists as well as trainees. Color options include standard industrial green or grey, ideal for any professional setting.

FAQs of Colchester Student 650 mm Lathe Machine:

Q: How do I adjust the spindle speed on the Colchester Student 650 mm Lathe?

A: The lathe features a variable spindle speed range (252000 RPM) controlled manually through a mechanical speed selection lever. You can choose from 12 preset speeds to match the material and operation, ensuring optimum performance for turning and threading tasks.

Q: What materials can be processed using this lathe machine?

A: Thanks to its robust cast iron construction and hardened bed ways, the Colchester Student Lathe can handle various materials, including mild steel, aluminum, brass, and plastics. Cutting performance is influenced by the tool, speed, and material properties, with a recommended maximum thickness of up to 20 mm.

Q: When is this lathe most beneficial in a workshop?

A: The Colchester Student Lathe excels in environments requiring precision, longevity, and flexible operations. It is especially valuable for educational workshops, small-scale manufacturing, and maintenance departments where manual turning and threading are frequent.

Q: Where is the Colchester Student 650 mm Lathe commonly used?

A: This lathe is widely used in vocational training institutes, engineering workshops, repair facilities, and small manufacturing plants across the United Kingdom and beyond, owing to its reliability and versatile capabilities.

Q: What is the process for cutting threads on this lathe?

A: To cut threads, select the appropriate feed rate for either metric (0.27 mm) or inch (272 TPI) threads using the lathes controls. Engage the lead screw (25 mm diameter) and utilize the tool post for accurate tool positioning. Ensure the workpiece and tool are correctly secured before starting the operation.

Q: What are the main benefits of this lathe machine for users?

A: Users benefit from its high precision, robust build, and user-friendly controls. The gap bed accommodates larger parts, while the 4-way turret allows for quick tool switching. This ensures efficiency, repeatability, and safety in both training and industrial applications.
