Emcoturn CNC Turning Center

Get a Price/Quote

Emcoturn CNC Turning Center Specification

Product Type
CNC Turning Center

General Use
Industrial machining, Precision turning

Material
Cast Iron Frame, Sheet Metal Enclosure

Type
Horizontal Turning Center

Capacity
Up to 32 mm bar capacity

Weight (kg)
1500 kg

Computerized
Yes

Automatic
Fully automatic operations

PLC Control
Available

Bar Feeder
Optional

Power Source
Electric

Power Consumption
5.5 kW

Rigidity
High rigid polymer concrete bed

Voltage
400 V

Motor
Servo Motor

Table Size
200 mm (Chuck size)

Spindle Speed
50 to 5000 rpm

Axial Choice
2 Axis (X, Z)

Dimension (L*W*H)
1700 x 1100 x 1700 mm

Feature
Linear guideways, High accuracy, Compact design

Color
White & Red

Noise Level
< 70 dB

Coolant System
Integrated

Turret Type
Servo-driven, 8-station turret

Max Turning Diameter
200 mm

Chuck Type
Hydraulic

Rapid Traverse Rate
24 m/min (X/Z)

Machine Enclosure
Fully enclosed splash guard

Controller Brand
Siemens or Fanuc

Lubrication System
Automatic central lubrication

Operator Safety
Emergency stop, Door interlock

Max Turning Length
220 mm

Tool Shank Size
20 x 20 mm

Air Supply
Required; 6 bar

Tailstock
Programmable

Chip Conveyor
Optional

About Emcoturn CNC Turning Center

CNC Turning Center

Make Emcoturn Austria

Model 340TC

Max Turning Diameter 158 mm

Max Turning Length 300 mm

Swing Over Bed 340 mm

Spindle Diameter 60 to 4000 rpm stepless

CNC Control Siemens Sinumerik 810

Main Drive Motor 11 kW

Automatic Turret 8tool bidirectional

Machine is in excellent working condition

Precision and Efficiency Combined

With a spindle speed range of 50 to 5000 rpm, the Emcoturn CNC Turning Center easily manages intricate turning operations on up to 32 mm bar material. Its compact design and linear guideways ensure both workspace efficiency and consistent accuracy for every project, whether for small-batch or large-scale production.

Operator-Centric Safety and Automation

Safety is a priority thanks to the fully enclosed splash guard, emergency stop, and door interlock system. The fully automated operations, driven by servo motors and PLC control, minimize manual intervention and maximize productivity, making it ideal for demanding industrial settings.

Innovative Design and Rigidity

Constructed with a high-rigid polymer concrete bed and cast iron frame, this CNC turning center resists vibration, ensuring precise machining even with heavy workloads. Optional features like chip conveyors and bar feeders offer further adaptability to fit specific production needs.

FAQs of Emcoturn CNC Turning Center:

Q: How does the automatic lubrication system benefit machine maintenance?

A: The automatic central lubrication system ensures that critical machine components are consistently lubricated, reducing manual maintenance intervals and prolonging machine lifespan. This ensures smoother operations and minimizes the risk of wear over time.

Q: What materials and workpieces can be machined on this CNC turning center?

A: The Emcoturn CNC Turning Center is suitable for machining a wide range of industrial materials, especially metals, thanks to its rigid cast iron frame and robust design. It accommodates workpieces up to 220 mm in length and 200 mm in diameter, with up to 32 mm bar capacity.

Q: When should the optional chip conveyor and bar feeder be used?

A: Optional chip conveyor and bar feeder systems are especially useful in high-volume or unattended machining environments. They facilitate continuous production by automatically managing chip removal and material feeding, minimizing downtime and manual labor.

Q: Where can this turning center be installed?

A: Due to its compact footprint (1700 x 1100 x 1700 mm) and fully enclosed design, the machine is well-suited for most industrial workshops or manufacturing plants, provided a 6 bar air supply and 400V electric connection are available.

Q: What makes the servo-driven 8-station turret advantageous for users?

A: The servo-driven 8-station turret enables quick tool changes and precise positioning, enhancing machining flexibility and reducing cycle times. This results in higher efficiency, particularly in applications requiring frequent tool switching or multi-operation processes.

Q: How does the fully enclosed splash guard improve operator safety?

A: The enclosure, along with features like emergency stops and door interlocks, keeps the operator protected from coolant splashes, chips, and moving parts, ensuring a safe working environment and compliance with industrial safety standards.
