F. Ruffati Italy Drilling and Milling Machine

Name: F. Ruffati Italy Drilling and Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

F. Ruffati Italy Drilling and Milling Machine Specification

Cutting Area
800 mm (X-axis), 220 mm (Y-axis)

Dimension (L*W*H)
1200 x 1000 x 1700 mm

Condition
Used/Imported

Features
Fine feed for precision, tilting & swiveling head, rigid construction, smooth operation

Diameter
Drilling: up to 32 mm

Spindle Speed
Variable, 75 - 2000 rpm

Table Size
800 x 240 mm

Machine Type
Vertical Drilling and Milling

Noise Level
Low

Frequency
50 Hz

Motor Power
3 HP

Product Type
Drilling and Milling Machine

Material
Heavy-duty Cast Iron & Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V (Three Phase)

Power
2.2 kW

Power Source
Electric

Weight (kg)
Approximately 650 kg

Capacity
Drilling up to 32 mm, Milling up to 25 mm

Color
Industrial Green & White

Usage & Applications
Precision drilling and milling for metal working, workshops, tool rooms, and manufacturing

Quill Travel
120 mm

Spindle Taper
ISO 40

Table Movement (manual)
Longitudinal: 500 mm, Cross: 220 mm

Coolant System
Provided

Surface Finish
Precision Ground

Lubrication
Centralized Lubrication System

Main Shaft Bearing
Heavy-duty, ball bearing

T-Slot Size
14 mm

Max Distance Spindle to Table
400 mm

Head Swivel
±45 degrees

F. Ruffati Italy Drilling and Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About F. Ruffati Italy Drilling and Milling Machine

Make - F. Ruffati (Italy)

Model - RAG TF-35

Drilling Capacity - 35 mm

Table Size - 550 mm x 200 mm

Spindle Diameter - 72 mm

Spindle Taper - MT 4

Spindle Speeds - 75 rpm to 2100 mm

Spindle Feed Travel - 125 mm

Spindle Feed Travel Rates - 0.10 mm/rev to 0.50 mm/rev

X-Y Travel of Table - 425 mm x 200 mm

Distance between Spindle Center to Vertical Column - 280 mm

Tilting Angle of Table - 0 degree to 90 degree

- Complete with Coolant Pump and inbuilt Coolant Tank.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/yt6SS6MJ30M

Precision Engineering for Demanding Tasks

Ruffati's vertical drilling and milling machine delivers outstanding accuracy in metalworking. Its variable spindle speed and tilting head enable operators to execute intricate operations with ease. The centralized lubrication system and heavy-duty bearings ensure consistent performance over prolonged usage.

Built for Reliability and Longevity

Crafted from heavy-duty cast iron and steel, the F. Ruffati machine offers a rigid construction that minimizes vibration. Precision ground surfaces and a robust powertrain make it suitable for high-volume tasks in demanding industrial environments, ensuring both reliability and consistent output quality.

Versatile Applications in Metalworking

With a longitudinal table movement of 500 mm and a cross movement of 220 mm, this machine adapts well to various tasks such as drilling, milling, and slotting. Its semi-automatic/manual control is ideal for workshops, tool rooms, and manufacturing setups seeking adjustable, efficient solutions.

FAQ's of F. Ruffati Italy Drilling and Milling Machine:

Q: How does the centralized lubrication system benefit overall machine performance?

A: The centralized lubrication system consistently supplies oil to critical components, reducing friction and wear. This results in smoother operation, extended machine lifespan, and lower maintenance requirements, making it ideal for high-volume industrial use.

Q: What materials is the F. Ruffati machine designed to work with?

A: This machine is built for precision drilling and milling in metals, supported by its heavy-duty cast iron and steel construction. It is suitable for processing various ferrous and non-ferrous metal workpieces in manufacturing and tool room settings.

Q: When should the head swivel feature be used in operation?

A: The 45-degree swiveling head is useful when precise angular drilling or milling is needed. It allows operators to easily adjust the tool orientation for complex jobs such as slots or angled holes without repositioning the workpiece.

Q: Where is the ideal setting to use the F. Ruffati drilling and milling machine?

A: The machine is best suited for metalworking workshops, tool rooms, and manufacturing units requiring high-precision operations. Its versatile design and sturdy build make it adaptable for industrial environments handling heavy workloads.

Q: What is the drilling and milling capacity of this model?

A: The F. Ruffati machine can drill holes up to 32 mm in diameter and perform milling up to 25 mm. The precision feed mechanism ensures accurate material removal even with complex shapes and larger workpieces.

Q: How does the manual control system impact the user's workflow?

A: The manual control system offers operators full control over speed adjustments (75-2000 rpm), feed rates, and table movements. This allows for fine-tuned operations, ensuring optimal results for precision tasks without the need for computerized automation.

Q: What advantages does the heavy-duty main shaft bearing provide?

A: Heavy-duty ball bearings in the main shaft minimize vibration and support higher loads during drilling and milling. This enhances stability, ensures smoother cutting, and leads to superior surface finishes on machined parts.
