G Dufour France Universal Milling Machine

Send Inquiry

Request To Call Back

G Dufour France Universal Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G Dufour France Universal Milling Machine Specification

Rotation
360 Universal Swivel

Model
G. Dufour

Product Type
Universal Milling Machine

General Use
Industrial Milling

Material
Cast Iron, Alloy Steel

Type
Horizontal & Vertical Milling

Capacity
Heavy Duty

Weight (kg)
Approx. 2000 Kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual Feed

Table Size
1200 mm x 300 mm

Table Slide Way
Dovetail / Hardened

Floor Space
1800 mm x 1700 mm

Spindle Speed
40 - 1750 RPM

Power
3.7 kW (5 HP)

Voltage
415 V

Dimension (L*W*H)
1800 mm x 1700 mm x 1600 mm

Feature
High Precision Construction, Robust Build

Color
Machine Blue/Gray

Feed Range
12 Steps

Max. Distance Spindle to Table
400 mm

Number of T-Slots
3

Table Travel (Vertical)
400 mm

Main Motor
5 HP

Accessories Included
Dividing Head, Arbor Supports, Vertical Head

Construction
Heavy Duty Cast Iron

Lubrication System
Centralized Automatic System

Spindle Taper
ISO 40

Max. Distance Spindle to Column
300 mm

Table Travel (Longitudinal)
900 mm

Rapid Feed Mechanism
Provided

T-Slot Size
14 mm

Coolant System
Built-in Coolant Tank

Table Travel (Cross)
300 mm

Working Speed
Variable

G Dufour France Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G Dufour France Universal Milling Machine

Make - G. Dufour (France)

Model - F. 51

Table Size - 1100 mm x 250 mm

XYZ Travels - 680 mm x 235 mm x 400 mm

Spindle Speeds - 21 rpm to 1600 rpm

Spindle Taper - ISO 40

Table Feed Rates - 10 mm/min to 375 mm/min

Table Rotation - 60 degree to -60 degree

- With Bracket (Arbour Support) for Horizontal Milling.

- Double Swivel type Vertical Milling Head.

- Complete with Rotating type Vice & Coolant Pump.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/VmBmxkp-zpE

Heavy-Duty, High-Precision Construction

Manufactured with a robust cast iron body and alloy steel components, the G Dufour Universal Milling Machine ensures accuracy and durability even under intense continuous operation. Precision dovetail/hardened slide ways deliver smooth table movement, while the centralized lubrication system aids maintenance and prolongs machine life.

Versatile Milling Operations

With both horizontal and vertical milling capabilities, plus a 360 universal swivel, this model supports a wide range of industrial tasks. The variable working speed (40-1750 RPM), manual feed, and built-in rapid feed mechanism allow operators to adapt quickly to different materials and project requirements.

Comprehensive Accessories and Features

Every machine comes equipped with a dividing head, arbor supports, vertical head, integrated coolant system, and a centralized automatic lubrication unit. These features streamline operations, ensuring users have a complete milling solution right out of the box.

FAQ's of G Dufour France Universal Milling Machine:

Q: How does the built-in coolant system benefit my milling operations?

A: The built-in coolant tank keeps both the spindle and workpiece at optimal temperatures during machining, reducing tool wear and ensuring smooth, precise cuts for prolonged periods-especially valuable in heavy-duty industrial applications.

Q: What table travels are supported by this machine, and what does that mean for my projects?

A: The machine offers 900 mm longitudinal, 300 mm cross, and 400 mm vertical table travel. These generous movements accommodate larger workpieces or complex setups, enhancing flexibility for a wide variety of milling tasks.

Q: When should I use the universal swivel feature on the machine?

A: The 360 universal swivel is ideal for milling angular or complex surfaces. Use it whenever your project requires non-standard angles or intricate part geometries to maximize precision without repositioning your workpiece manually.

Q: Where can this milling machine be installed for optimal usage?

A: Its heavy-duty construction (approx. 2000 kg) and floor footprint (1800 x 1700 mm) require a stable, industrial-floor environment with proper anchoring and access to three-phase 415 V power, common in most manufacturing plants.

Q: What is included with the G Dufour Universal Milling Machine?

A: Standard accessories include a dividing head, arbor supports, vertical head, built-in coolant tank, and a centralized automatic lubrication system, providing users with necessary tools for versatile and efficient milling operations.

Q: How does the centralized automatic lubrication system enhance operation?

A: It delivers continuous lubrication to all critical moving parts, minimizing maintenance needs, preventing premature wear, and ensuring lasting smooth operation during long working cycles.

Q: What are the main benefits of manual feed control on this machine?

A: Manual feed gives operators full control over cutting speed and feed rate, allowing for precision adjustments in real-time and the ability to fine-tune operations for specialized or delicate workpieces.
