G. Vernier FV3S Universal Milling Machine

Name: G. Vernier FV3S Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G. Vernier FV3S Universal Milling Machine Specification

Model
FV3S

Rotation
Clockwise & Anticlockwise

Product Type
Universal Milling Machine

General Use
Universal Milling Operations

Material
High Grade Cast Iron

Type
Horizontal & Vertical Mill

Capacity
Medium Duty

Weight (kg)
Approximately 1800 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC (Conventional)

Control System
Manual

Table Size
1300 x 300 mm

Table Slide Way
Box Type

Floor Space
2000 x 1800 mm (Approx.)

Spindle Speed
40 2000 rpm (12 Steps)

Power
3 HP (2.2 kW)

Voltage
415 V, 3 Phase

Dimension (L*W*H)
2000 x 1800 x 1750 mm (Approx.)

Feature
Universal Swivel Table, Hardened & Ground Table, Horizontal & Vertical Spindle Arrangement

Color
Grey & Blue

Maximum Swing of Milling Head
360

Coolant Pump Motor
0.15 HP

Horizontal Spindle Taper
ISO 40

Y-Axis Travel
300 mm

T-Slot of Table
3 Slots / 16 mm width

Vertical Spindle Taper
ISO 40

Z-Axis Travel
450 mm

Ram Travel
400 mm

X-Axis Travel
900 mm

Quill Movement
70 mm

Standard Accessories
Vertical head, overarm, table guards, drawbar, tool kit

Main Motor (3 phase)
2.6 kW (3.5 HP)

Feed Range
10-600 mm/min

G. Vernier FV3S Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G. Vernier FV3S Universal Milling Machine

Make - G. Vernier (France)

Model - FV3S

Table Size - 1500 mm x 320 mm

XYZ Travel - 1000 mm x 300 mm x 500 mm

Spindle Speeds - 32 rpm to 1500 rpm

Spindle Taper - ISO 40

Table Feed Travel Rate - 9 mm/min to 440 mm/min

- Complete with Bracket for Horizontal Milling.

- Double Swivel type Vertical Milling Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/TldMH_qK87Q

High Precision Versatility

Designed for a wide spectrum of milling operations, the FV3S offers both horizontal and vertical spindle arrangements. Its universal swivel table and box-type slide ways provide stability, enabling precise multi-directional machining for batch, repair, or prototyping work.

Durable and User-Friendly

Built with high-grade cast iron, the FV3S ensures long service life, even under continuous operation. Its semi-automatic controls, ergonomic design, and comprehensive standard accessories, like a vertical head and tool kit, make it straightforward to operate and maintain.

Ideal for Medium-Duty Workshops

With a capacity tailored for medium-duty tasks, a 3 HP power supply, and spacious table, this model is perfect for small manufacturing units, training institutes, repair shops, and general engineering environments requiring universal milling capability.

FAQs of G. Vernier FV3S Universal Milling Machine:

Q: How do I switch between horizontal and vertical milling operations on the FV3S Universal Milling Machine?

A: The FV3S is equipped with both horizontal and vertical spindle tapers (ISO 40). To switch, you simply mount the appropriate spindle accessories: the vertical head attaches for vertical milling, and the overarm supports horizontal operations. Both components and the drawbar are included as standard accessories.

Q: What general types of materials and jobs is this machine suitable for?

A: The FV3S is ideal for a variety of universal milling applications, particularly with medium-duty materials such as cast iron, mild steel, and aluminum alloys. Its suited for batch production, prototyping, repairing parts, and producing slots, pockets, and complex surfaces.

Q: When is it necessary to use the ram travel feature, and how much movement does it allow?

A: Ram travel is essential when you need to adjust the spindle position horizontally to accommodate larger or irregularly shaped workpieces. The FV3S offers up to 400 mm of ram travel, allowing for greater flexibility in setup and machining accessibility.

Q: Where can the G. Vernier FV3S be installed, and what are its space requirements?

A: This milling machine has an approximate footprint of 2000 x 1800 mm, making it suitable for installation in most medium-sized workshops or training facilities. Verify the installation area is level and can support a weight of approximately 1800 kg.

Q: What is the process for changing spindle speeds, and what range does the FV3S offer?

A: Spindle speeds can be changed manually using the gear selector. The FV3S features 12 stepped speed settings, ranging from 40 rpm to 2000 rpm, allowing for tailored cutting parameters based on the specific workpiece or tooling.

Q: How does the machine benefit users in terms of productivity and precision?

A: Thanks to its universal swivel table, hardened and ground surfaces, and robust spindle arrangement, the FV3S achieves both highly accurate and complex machining. Rapid feed ranges (10600 mm/min) and ergonomic controls enhance workflow efficiency and reduce operator fatigue.
