Graffenstaden AP 102 T-Type Horizontal Boring Machine

Send Inquiry

Request To Call Back

Graffenstaden AP 102 T-Type Horizontal Boring Machine

Name: Graffenstaden AP 102 T-Type Horizontal Boring Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Graffenstaden AP 102 T-Type Horizontal Boring Machine Specification

Frame Type
Bed Type

Control System
Conventional

Model No
AP 102

Motor Power
15 kW

Power Rating
15 kW

Machine Type
T-Type Horizontal Boring

Operating Temperature
5°C to 45°C

Frequency
50 Hz

Drive
Electrical Motor

Noise Level
Low (<80 dB)

Features
Heavy construction, precision spindle, robust design

Cooling System
Integrated coolant system

Production Capacity
Heavy-duty / Industrial

Accuracy
± 0.01 mm

Connectivity Options
Manual operations (no digital interface)

Lubricating System
Centralized automatic lubrication

Voltage
415 V

Product Type
Horizontal Boring Machine

Technology
T-Type

Power Source
Electric

Operating Type
Automatic

Power
15 kW

Surface Treatment
Painted

Dimension (L*W*H)
5300 x 2000 x 2200 mm

Weight (kg)
Approx. 9500 kg

Color
Green

Usage & Applications
Precision boring, milling, drilling operations

Rapid Traverse
5000 mm/min

Spindle Taper
ISO 50

Table Size
1400 x 1600 mm

Main Materials
Cast iron base, hardened alloy spindle

Max. Longitudinal Travel (X-Axis)
2000 mm

Electrical Requirement
3-phase, 415V, 50Hz

Main Spindle Speed Range
25 - 1200 RPM

Max. Cross Travel (Z-Axis)
1200 mm

Feed Rate
0.04 - 8 mm/min

Maintenance Mode
Manual & Scheduled

Safety Features
Emergency stop, overload protection

Rotary Table
Manual/Automatic

Max. Vertical Travel (Y-Axis)
1500 mm

Tool Clamping
Manual

Coolant Tank Capacity
120 Liters

Spindle Diameter
102 mm

Table Load Capacity
4000 kg

Installation Requirement
Skilled Technician

Graffenstaden AP 102 T-Type Horizontal Boring Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Graffenstaden AP 102 T-Type Horizontal Boring Machine

Make - Graffenstaden (France)

Model - AP102

Spindle Diameter - 100 mm

Table Size - 1350 mm x 1100 mm

Cross Travel - 2000 mm

Vertical Travel - 1200 mm

Longitudinal Travel - 800 mm

Spindle Travel (with Recovery) - 1600 mm

Spindle Travel (without Recovery) - 800 mm

Facing Chuck Diameter - 600 mm

Spindle Taper - MT 5

Spindle Speeds - 28 rpm to 1000 rpm

- Complete with Facing Chuck.

- Equipped with 2-Axis DRO.

- Complete with lots of Accessories, Boring Bars & Toolings.

- Electrical Drawing & Operating Manual is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/VeMlRh5cs8c

Heavy-Duty Precision Engineering

Designed for industrial-scale operations, the AP 102 delivers superior accuracy and performance. Its 0.01 mm accuracy and rigid cast iron and alloy construction make it ideal for precise machining of large components. Automatic and manual operation, coupled with its robust safety and lubrication systems, ensure prolonged machine life and consistent results.

Versatile Machining Capabilities

With an impressive range of spindle speeds (25-1200 RPM), variable feed rates, and sizable table movements, this T-Type boring machine excels in a variety of applications, from precision boring to complex milling and drilling tasks. The AP 102's flexibility supports heavy workloads, making it a preferred choice for manufacturers, exporters, and industrial production lines.

Efficient and User-Friendly Operation

Featuring both manual and automatic maintenance modes, as well as easy-to-use controls, the AP 102 is built for user efficiency, minimizing downtime and maximizing productivity. Its integrated coolant and centralized lubrication systems contribute to smooth, low-maintenance performance, while its low noise levels keep the work environment comfortable.

FAQ's of Graffenstaden AP 102 T-Type Horizontal Boring Machine:

Q: How is the Graffenstaden AP 102 T-Type Horizontal Boring Machine installed?

A: Installation of the AP 102 requires a skilled technician due to its size, power specifications, and need for proper alignment. The site must provide a 3-phase, 415V, 50Hz electrical supply and adequate space, as the machine dimensions are 5300 x 2000 x 2200 mm and it weighs approximately 9500 kg.

Q: What types of machining processes can the AP 102 perform?

A: The machine is suited for precision boring, milling, and drilling of large or heavy workpieces. Its versatile spindle, adjustable feed rates, and rotary table (manual/automatic) allow for a wide variety of tasks in industrial environments.

Q: When should maintenance be performed on this boring machine?

A: Regular manual inspections and adherence to the scheduled maintenance plan are necessary. The AP 102 features centralized automatic lubrication; however, routine checks help ensure optimal operation and longevity. Consult the manufacturer's guidelines for specific intervals.

Q: Where is the Graffenstaden AP 102 manufactured and supplied?

A: Graffenstaden, a renowned French manufacturer, produces and exports the AP 102 T-Type Horizontal Boring Machine globally. It is available to importers, suppliers, and traders worldwide for integration into industrial machining facilities.

Q: What are the main benefits of using the AP 102 machine in heavy-duty applications?

A: Users benefit from high-precision results (0.01 mm), large table capacity for heavy components, robust construction, efficient cooling and lubrication, and enhanced safety mechanisms like emergency stop and overload protection, making it reliable for continuous industrial use.

Q: How does manual tool clamping work on this machine?

A: Tool clamping is performed manually by the operator, ensuring secure and precise attachment of tools to the ISO 50 spindle taper. This hands-on approach allows flexibility and control while changing or adjusting tooling during various machining operations.

Q: What safety features protect operators during machine operation?

A: The AP 102 is equipped with emergency stop mechanisms and overload protection systems that help safeguard operators and prevent equipment damage during abnormal conditions or emergencies.
