Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine

Name: Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine Specification

Rotation
Vertical

Model
Ludor 1600

Product Type
Vertical Milling Machine

General Use
Industrial Vertical Milling Operations

Material
Cast Iron

Type
Milling Machine

Capacity
Heavy Duty

Weight (kg)
Approx. 2900 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 mm x 380 mm

Table Slide Way
Box Type

Magnetic Chuck Size
380 mm

Grinding Wheel Size
160 mm

Grinding Wheel Speed
2800 rpm

Grinding Length
1600 mm

Floor Space
Approx. 3200 mm x 2000 mm

Spindle Speed
3 Speed (85-650 rpm)

Power
5 HP

Voltage
415 V

Dimension (L*W*H)
3200 mm x 2000 mm x 2200 mm

Feature
High Precision, Rugged Construction

Color
White & Blue

Spindle Taper
ISO 40

T-Slot Size (Table)
18 mm

Coolant Pump
0.15 HP

Quill Diameter
75 mm

Number of T-Slots
3

Maximum Table Load
700 kg

Distance from Spindle Nose to Table
max. 480 mm

Longitudinal Table Travel
1250 mm

Vertical Travel (Knee)
450 mm

Distance from Spindle Axis to Column
420 mm

Quill Travel
140 mm

Working Speed
Variable

Main Motor
5 HP / 3.75 kW

Feed Range
16 Feed Rates

Cross Table Travel
340 mm

Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine

Make - Grazioli (Italy)

Model - Ludor 3V

Table Size - 1600 mm x 380 mm

XYZ Travel - 1050 mm x 340 mm x 500 mm

Spindle Taper - ISO 50

Spindle Speeds - 24 rpm to 1160 rpm

Max. Height between Table Top to Spindle - 525 mm

Table Feed Rates - 12.3 mm/min to 550 mm/min

Head Swivel Angle - +45 degree to -45 degree

- Vertical RAM Travel in Spindle Head.

- Machine is in excellent working condition.

Video of the machine -

https://youtu.be/HhPaHCeSE1I

Advanced Precision and Robust Construction

Engineered with cast iron and high-precision components, the Grazioli Ludor 1600 offers stability during demanding milling operations. The heavy-duty table supports up to 700 kg, while the box-type slide way ensures smooth, long-lasting performance. Its variable speed and ISO 40 spindle achieve precise results on diverse materials.

Flexible Manual Operation for Industrial Use

With manual controls and 16 feed rates, operators can fine-tune settings for each project. The Ludor 1600 suits various milling applications in manufacturing and industrial workshops, providing flexibility for complex and routine tasks. Its ergonomic design enhances operator efficiency and safety.

Ample Working Space and High Capacity

The generous table size (1600 mm x 380 mm) with three T-slots accommodates large and heavy workpieces. Longitudinal, cross, and vertical travels extend operational versatility, enabling the machine to handle intricate milling and grinding jobs with consistent accuracy.

FAQ's of Grazioli Ludor 1600 mm x 380 mm Vertical Milling Machine:

Q: How is the Grazioli Ludor 1600 Vertical Milling Machine operated?

A: This machine features a manual control system, allowing operators to adjust speed, feed rates, and table movement directly. It is not computerized and does not include CNC capabilities.

Q: What types of industrial tasks is the Ludor 1600 suitable for?

A: The Ludor 1600 is designed for heavy-duty vertical milling operations in manufacturing and machining industries. It is ideal for processing large workpieces, precise cutting, and grinding applications requiring robust construction and high accuracy.

Q: When should I consider using this milling machine over CNC models?

A: Choose the Ludor 1600 when your operations demand high reliability, ruggedness, and manual versatility rather than automated tasks. It is best for workshops that require flexible, hands-on control for custom or varied milling projects.

Q: Where can the Ludor 1600 Vertical Milling Machine be installed?

A: Due to its substantial size and weight (approx. 2900 kg), it should be installed in a spacious industrial shop or manufacturing unit with floor space of at least 3200 mm x 2000 mm and appropriate electrical supply (415 V).

Q: What benefits does the ISO 40 spindle taper provide?

A: The ISO 40 spindle taper allows for secure tool mounting and efficient power transfer, enhancing the machine's precision and reliability during heavy-duty milling operations.

Q: How is the table loaded and what is its capacity?

A: The table supports a maximum load of 700 kg, with three T-slots for secure clamping. Large and heavy workpieces can be easily mounted for stable, accurate machining processes.

Q: What maintenance process is recommended for this machine?

A: Regular cleaning, lubrication of slide ways and spindle, inspection of feed mechanisms, and timely replacement of wear parts are advised to ensure longevity and high performance of the Ludor 1600 milling machine.
