MRF Spain 1760 mm x 450 mm Bed Milling Machine

Send Inquiry

Request To Call Back

MRF Spain 1760 mm x 450 mm Bed Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MRF Spain 1760 mm x 450 mm Bed Milling Machine Specification

Rotation
Spindle Rotation Clockwise/Counterclockwise

Model
Spain

Product Type
Bed Milling Machine

General Use
Industrial Metal Milling

Material
Cast Iron/Steel

Type
Horizontal

Capacity
Heavy Duty

Weight (kg)
Approx. 4000 kg

Computerized
No

Automatic
Semi Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
1760 mm x 450 mm

Table Slide Way
Hardened and Ground

Grinding Length
1760 mm

Floor Space
Approx. 2500 mm x 2200 mm

Spindle Speed
3 Steps, 50-2000 rpm

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
Approx. 2500 mm x 2200 mm x 2200 mm

Feature
Sturdy Construction, Precision Ground Table, Operator Friendly

Color
Blue & White

MRF Spain 1760 mm x 450 mm Bed Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About MRF Spain 1760 mm x 450 mm Bed Milling Machine

Make - MRF (Spain)

Table Size - 1760 mm x 450 mm

XYZ Travels - 1350 mm x 500 mm x 600 mm

Spindle Taper - ISO 50

Spindle Speeds - 45 rpm to 1700 rpm

Feed Travel Rates - 10 mm/min to 1000 mm/min

Max. Height between Table & Spindle Nose - 675 mm

- Equipped with Ball-Screws and Servo-Motors on all the 3-Axis.

- Universal type Milling Head for Vertical, Horizontal & Angular Milling.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1Xjvt55AEsk

Heavy-Duty Precision Engineering

Built for demanding industrial environments, the MRF Spain Bed Milling Machine combines sturdy cast iron construction with a precision ground, hardened table surface. Its generous work envelope and robust power output allow for efficient machining of sizeable metal components, enhancing both productivity and durability.

Advanced Operator Features

Designed with operator efficiency in mind, this machine incorporates automatic and manual table feed controls and a centralized automatic lubrication system. The operator-friendly interface ensures ease of use, while its solid construction reduces vibration and increases accuracy during extended milling processes.

Versatile Milling Capabilities

Sporting an ISO 50 main spindle taper and three spindle speed steps, this milling machine covers a wide speed range suited for various materials. Its bidirectional spindle rotation and heavy-duty table capacity allow for versatile applications in manufacturing, supplying, and trading sectors.

FAQs of MRF Spain 1760 mm x 450 mm Bed Milling Machine:

Q: How does the automatic centralized lubrication system benefit the machine?

A: The automatic centralized lubrication system ensures that all critical moving parts are consistently lubricated, which reduces wear, minimizes maintenance intervals, and extends the machines service life. This enhances overall efficiency and reliability during heavy-duty milling operations.

Q: What type of operations can be performed with the MRF Spain Bed Milling Machine?

A: This milling machine is suitable for industrial metal milling tasks, such as face milling, slotting, drilling, and heavy-duty shaping of large metal components. Its automatic and manual table feeds, precision table, and variable spindle speeds make it ideal for various machining processes.

Q: Where is the MRF Spain Bed Milling Machine typically used?

A: It is commonly used in large-scale industrial workshops, manufacturing facilities, and metal fabrication plants. Its robust design and large working table make it ideal for heavy-duty applications where precision and durability are critical.

Q: What are the benefits of the precision ground and hardened table slide ways?

A: Precision ground and hardened table slide ways enhance the smoothness and accuracy of table movement. This results in more precise machining, less wear over time, and greater resistance to deformation, even under heavy loads.

Q: When should the spindle speed be adjusted, and how is it controlled?

A: The spindle speed, which ranges from 502000 rpm in three selectable steps, should be adjusted based on the type of material and the specific operation being performed. Speed selection is manual, allowing operators to adapt cutting conditions for optimal results.

Q: How does the machine accommodate different workpiece sizes and weights?

A: The large table size (1760 mm x 450 mm), five T-slots, and a maximum load capacity of 1200 kg enable secure mounting of variously sized and heavy workpieces. Operators can confidently handle substantial components during milling processes.

Q: What makes this milling machine operator-friendly?

A: Features such as manual and automatic table feed, intuitive manual controls, simple spindle speed adjustment, and a well-designed workstation contribute to ease of operation. These aspects, combined with safety-focused construction, make it user-friendly even for extended use.
