TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine

Name: TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine Specification

Model
FGSV 50

Rotation
Spindle: Vertical

Product Type
Vertical Milling Machine

General Use
Heavy Duty Vertical Milling

Material
Cast Iron, Hardened Steel

Type
Heavy Duty

Capacity
Heavy Material Machining

Weight (kg)
3700

Computerized
No

Automatic
No

CNC Or Not
Conventional

Control System
Manual

Table Size
1250 mm x 320 mm

Table Slide Way
Dovetail

Floor Space
2300 mm x 2120 mm

Spindle Speed
50-1800 rpm

Power
7.5 kW (Motor Power)

Voltage
415 V

Dimension (L*W*H)
2300 mm x 2200 mm x 2320 mm

Feature
High Precision, Robust Construction

Color
Industrial Grey

Rapid Traverse Rate
1800 mm/min

Max. Distance Spindle to Table
500 mm

Lubrication System
Automatic Centralized

Main Drive
Gear Driven

Feed Travel (X/Y/Z)
1000 mm / 350 mm / 400 mm

Number of T-Slots
3

Milling Head Swivel
±45°

Safety Features
Emergency Stop, Overload Protection

Table Load Capacity
700 kg

Noise Level
<75 dB

Spindle Taper
ISO 50

T-Slot Size
18 mm

Coolant System
Fitted

TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine

Make - TOS (Czech Republic)

Model - FGSV 50

Table Size - 1800 mm x 630 mm

XYZ Travel - 1400 mm x 690 mm x 500 mm

Spindle Speeds - 45 rpm to 1400 rpm

Spindle Taper - ISO 50

Feed Travel Rates - 10 mm/min to 1800 mm/min

Spindle Motor Power - 15.0 kW

Weight of Machine - 7.0 tons (Approx)

- Equipped with 3-Axis DRO.

- Feature of Automatic Up & Down Travel of Table by 0.5 mm.

- With Automatic Hydraulic Clamping of the Tool-Holder.

- It is a Heavy-Duty Pure Vertical Milling Machine.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/Deq54jjzXTs

Robust Construction for Heavy Duty Applications

Built from cast iron and hardened steel, the FGSV50's robust frame supports machining of heavy materials. Its 1250 mm x 320 mm dovetailed table and 700 kg load capacity make it suitable for demanding industrial requirements, ensuring long-term reliability even under continuous usage.

Precision Machining Capabilities

The FGSV50 delivers precise results, equipped with high-accuracy feed travels (X/Y/Z) and a spindle speed range of 50-1800 rpm. Its 45 milling head swivel and three 18 mm T-slots allow versatile clamping and operational flexibility, making it an asset for producing intricate and heavy-duty components.

Safety and Efficiency Built In

Safety is paramount in the FGSV50, featuring an emergency stop and overload protection. The automatic centralized lubrication and integrated coolant system maintain optimal machine performance while minimizing downtime, while its gear-driven mechanism ensures consistent torque and low noise levels (<75 dB).

FAQ's of TOS Kurim FGSV50 Heavy Duty Vertical Milling Machine:

Q: How is the table load capacity of the FGSV50 Vertical Milling Machine utilized in industrial settings?

A: The machine's table load capacity of 700 kg enables it to handle substantial workpieces typically found in heavy manufacturing sectors, such as automotive, aerospace, and metal fabrication, allowing for the machining of large parts without compromising stability or precision.

Q: What safety features does the FGSV50 offer during operation?

A: The FGSV50 includes an emergency stop and overload protection, ensuring operator safety by instantly halting the machine in hazardous situations and protecting the system against excessive mechanical stress during demanding tasks.

Q: Where is the TOS Kurim FGSV50 commonly installed and used?

A: This milling machine is widely deployed in industrial workshops, manufacturing plants, and tool rooms, particularly in environments requiring high-precision heavy-duty vertical milling on robust materials such as cast iron and hardened steel.

Q: When should the cooling and lubrication systems be maintained?

A: Routine checks and maintenance should be carried out according to the manufacturer's schedule, typically after specified operating intervals or when performance indicators signal the need, ensuring optimal functioning of both the fitted coolant system and automatic centralized lubrication.

Q: What advantages does the ISO 50 spindle taper provide?

A: The ISO 50 spindle taper delivers secure and stable tool holding, accommodating heavy-duty milling operations while enhancing machining accuracy and reducing vibrations, especially important for high-load and precision applications.

Q: How does the manual control system benefit users of the FGSV50?

A: The manual control system offers direct, intuitive operation, making it ideal for skilled machinists who require hands-on oversight and swift adjustments during complex procedures, without relying on computerized automation.
