GSP 60 mm Radial Drilling Machine

Name: GSP 60 mm Radial Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 11000 INR
Availability: InStock

Price 11000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GSP 60 mm Radial Drilling Machine Specification

Features
Rigid Construction, High Accuracy, Easy Operation, Durable Finish

Spindle Speed
75 1220 RPM (Variable) Per Steps

Frequency
50 Hz

Cutting Area
Large / 60 mm Diametric Capability

Motor Power
3 HP / 1440 RPM

Diameter
60 mm

Table Size
560 mm x 410 mm

Dimension (L*W*H)
2300 mm x 1100 mm x 2600 mm

Noise Level
Low

Machine Type
Heavy Duty Radial Drill

Condition
New

Product Type
Radial Drilling Machine

Material
Heavy Duty Cast Iron and Steel Components

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual Control

Voltage
415 V

Power
3 HP

Power Source
Electric

Weight (kg)
Approx. 2200 kg

Capacity
60 mm Drilling

Color
Sky Blue & Black

Usage & Applications
Drilling, Boring, Tapping for Industrial, Metal & Engineering Workshops

Spindle Taper
MT-5

Table Adjustment
Vertical & Rotational

Column Diameter
280 mm

Distance From Spindle To Base
1160 mm Max

Spindle Travel
280 mm

Coolant Pump
Provided

Arm Elevation Motor
0.5 HP

Arm Length
1500 mm

Base Size
1350 mm x 800 mm

Distance Between Column to Spindle Center
1220 mm Max

Number of Spindle Speeds
8

About GSP 60 mm Radial Drilling Machine

Make - GSP (France)

Drilling Capacity - 60 mm

Spindle Diameter - 95 mm

Arm Length - 1570 mm

Spindle Taper - MT 5

Spindle Speeds - 40 rpm to 1800 rpm

Downward Spindle Feed Travel - 335 mm

Spindle Feed Rate of Travel - 0.045 mm/rev to 0.50 mm/rev

Vertical Travel of the Arm - 775 mm

Table Size - 600 mm x 450 mm

Clamping Type - Hydraulic

- Automatic Hydraulic Gear Shifting.

- Complete with Coolant pump, Vice etc.

- Machine is in excellent working condition.

Video link - https://youtu.be/J6GMGaZLPB0

Robust Build and High Precision

The GSP 60 mm Radial Drilling Machine features rugged cast iron and steel construction, ensuring exceptional rigidity and longevity. Its high precision components make it suitable for demanding industrial applications, maintaining accurate results with every use. Designed for heavy-duty tasks, it is efficient in drilling, boring, and tapping operations. The durable finish and low noise operation further enhance its working environment suitability.

Versatile Operation and Large Capacity

Boasting a 60 mm drilling capacity and spacious working dimensions, this machine accommodates sizable workpieces with ease. The spindles 8-speed variable settings and arm elevation motor provide flexibility for varying project requirements. The adjustable table supports both vertical and rotational movements, maximizing its usability for metal and engineering workshops. With a powerful 3 HP motor, the GSP 60 mm ensures consistent output and reliability.

User-Friendly Features for Industrial Use

Equipped with a manual control system, the GSP 60 mm Radial Drilling Machine prioritizes straightforward, easy operation for technicians. Its semi-automatic grade strikes a balance between automation and operator involvement. The provided coolant pump ensures smooth cutting and tool longevity. The machines high accuracy, quiet performance, and ergonomic design make it a valuable addition to industrial, manufacturing, and engineering facilities.

FAQs of GSP 60 mm Radial Drilling Machine:

Q: How does the GSP 60 mm Radial Drilling Machine benefit metal and engineering workshops?

A: Its heavy-duty construction and large drilling capacity enable efficient handling of extensive workpieces, while high precision and low noise contribute to a productive workshop environment. The machine is ideal for drilling, boring, and tapping operations required in industrial tasks.

Q: What is the process for arm elevation and table adjustment on this machine?

A: Arm elevation is powered by a 0.5 HP motor, allowing smooth vertical movements. The table offers both vertical and rotational adjustments, which enable flexible positioning of workpieces for precise drilling and machining applications.

Q: Where can this radial drilling machine be utilized effectively?

A: The GSP 60 mm Radial Drilling Machine is suited for metal fabrication shops, engineering workshops, industrial plants, and manufacturing facilities where precision drilling, boring, and tapping are frequently required.

Q: What types of materials can be drilled with this machines 60 mm capacity?

A: It is designed to drill through various metalsincluding steel, cast iron, and alloysthanks to its rigid build and variable spindle speed settings. The 60 mm diameter capacity allows for versatile use across demanding projects.

Q: How is the spindle speed controlled, and what range can operators expect?

A: Operators manually select from 8 spindle speeds, ranging from 75 to 1220 RPM in variable steps. This flexibility allows adaptation to different material types and drilling requirements, enhancing precision and efficiency.

Q: When is it ideal to use manual control over computerized or CNC alternatives?

A: Manual control is preferred when flexibility, direct intervention, and adaptability are needed, especially for custom or complex workpieces. The semi-automatic grade provides reliable results without complicated programming, suitable for skilled technicians wanting hands-on operation.

Q: What distinguishes this machine from automatic or CNC models?

A: Unlike fully automated or CNC machines, the GSP 60 mm offers manual, semi-automatic control for greater operator input and adaptability. It ensures straightforward use, lower maintenance, and is cost-effective for workshops needing reliable, versatile drilling solutions.
