GSP France Automatic Drilling and Tapping Machine

Name: GSP France Automatic Drilling and Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 45000 INR
Availability: InStock

Price 45000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GSP France Automatic Drilling and Tapping Machine Specification

Noise Level
<75 dB

Motor Power
3.0 HP

Frequency
50/60 Hz

Diameter
Drilling: max 25 mm, Tapping: max M16

Condition
New

Spindle Speed
70 - 2800 rpm

Dimension (L*W*H)
1200 x 800 x 1750 mm

Table Size
600 x 400 mm

Machine Type
Automatic Drilling and Tapping

Features
High precision, user-friendly interface, rapid tool change, robust construction

Cutting Area
600 x 400 mm

Product Type
Automatic Drilling and Tapping Machine

Material
Cast Iron, Stainless Steel

Computerized
Yes

Automatic Grade
Automatic

CNC Or Not
CNC

Control System
PLC Control

Voltage
380V / 415V

Power
3.0 kW

Power Source
Electric

Weight (kg)
750 kg

Capacity
25 mm drilling diameter, M3M16 tapping capacity

Color
Standard Industrial Green (customizable)

Usage & Applications
Suitable for mass production of drilled and tapped holes in metal or non-metal workpieces

Lubrication System
Automatic centralized lubrication

Worktable Movement
X and Y manual adjustment

Protection
Emergency stop, overload protection

Number of Spindles
Single

Coolant System
Integrated coolant with recirculation

Clamping System
Hydraulic or manual vice

Movement
Vertical spindle movement, manual or automatic workpiece feeding

Applicable Materials
Steel, aluminum, brass, plastic

Display
Digital interface for parameter setting

Chuck Size
upto 16 mm

GSP France Automatic Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About GSP France Automatic Drilling and Tapping Machine

Make - GSP (France)

Capacity - 50 mm

Spindle Diameter - 95 mm

Table Size - 800 mm x 400 mm

Spindle Feed Travel - 325 mm

Spindle Taper - MT 4

XYZ Travel of Table - 415 mm x 300 mm x 350 mm

Max. Distance between Table & Spindle - 600 mm

Distance between Spindle Center to Machine Body - 415 mm

Spindle Speeds - 40 rpm to 1800 rpm

Spindle Feed Rates of Travel - 0.045 mm/rev to 0.50 mm/rev

No. of Stop Limits that can be set for Spindle Travel - 20

- Automatic Tapping Feature.

- Automatic Hydraulic Gear Shifting.

- Micro-Feed for Precise adjustment of Automatic Depth Stop Limit.

- Equipped with Coolant Pump & Tank.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/h6UCFcGfmIU

High Performance and Versatility

Designed for professional operations, the machine efficiently drills up to 25 mm and taps up to M16 threads in a variety of materials. Its flexible worktable offers manual X and Y adjustment, supporting dimensional adaptability and precision. Whether youre working with steel, aluminum, brass, or plastic, the machine ensures consistently accurate results, suitable for both standard and specialized production lines.

Advanced Control and User-Friendly Interface

Featuring a digital display for parameter settings, the machine is easy to operate and configure, even for complex jobs. With PLC-based control and CNC functionality, users can achieve repeatable accuracy and swift transitions between drilling and tapping. Integrated safety measures protect both operators and the machine, making productivity reliable and worry-free.

FAQs of GSP France Automatic Drilling and Tapping Machine:

Q: How does the GSP France Automatic Drilling and Tapping Machine improve production efficiency?

A: Thanks to its CNC and PLC control systems, along with rapid tool change capabilities, this machine streamlines drilling and tapping processes. The automatic feeding and lubrication systems reduce operator intervention, speeding up mass production while maintaining high precision.

Q: What materials can be processed with this drilling and tapping machine?

A: The machine is engineered to work with steel, aluminum, brass, and plastic, making it suitable for varied industrial requirements. Its robust construction ensures consistent performance across all supported materials.

Q: Where can the GSP France Automatic Drilling and Tapping Machine be installed?

A: Due to its compact design and moderate dimensions, the machine fits easily into industrial workshops, manufacturing facilities, or production lines. It operates on standard industrial electrical supplies (380V/415V), facilitating straightforward installation.

Q: What is the process for setting drilling and tapping parameters?

A: Users set parameters via the intuitive digital interface. Spindle speeds, drilling diameters, and tapping sizes can be adjusted quickly. The interface guides users, making setup and operation simple for both routine and custom jobs.

Q: How does the integrated coolant and lubrication system benefit operation?

A: The coolant system with recirculation maintains optimal cutting temperatures, reducing tool wear and enhancing finish quality. Automatic centralized lubrication ensures moving parts run smoothly, minimizing maintenance and extending machine life.

Q: When is manual workpiece feeding recommended over automatic feeding?

A: Manual feeding is ideal for smaller batches or when handling irregular-shaped workpieces. Automatic feeding is preferable for longer production runs where uniformity and throughput are priorities.
