Maut Italy 50 mm Capacity Radial Drilling Machine

Send Inquiry

Request To Call Back

Maut Italy 50 mm Capacity Radial Drilling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Maut Italy 50 mm Capacity Radial Drilling Machine Specification

Condition
Used / Good Working Condition

Noise Level
Low

Spindle Speed
8 - 1200 rpm (Varied steps)

Cutting Area
Adjustable, up to arm length

Machine Type
Arm Type Radial Drill

Table Size
560 mm x 420 mm (approx)

Features
High rigidity, Smooth operation, Adjustable arm, Precision gearbox, Hardened parts

Frequency
50 Hz

Dimension (L*W*H)
2300 mm x 950 mm x 2700 mm

Motor Power
4 HP main motor

Diameter
50 mm in mild steel

Product Type
Radial Drilling Machine

Material
Heavy-duty Cast Iron & Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Voltage
415V, 3 Phase, 50 Hz

Power
4 kW

Power Source
Electric

Weight (kg)
Approx. 2400 kg

Capacity
50 mm Drilling Capacity

Color
Green / Grey

Usage & Applications
Drilling, Reaming, Boring in Metalworking and Fabrication industries

Max Distance Spindle to Base
1250 mm

Base Working Surface
1650 mm x 850 mm

Made in
Italy

Vertical Travel of Arm
900 mm

Drilling Radius
1200 mm

Safety Features
Operator guards, Emergency stop

Spindle Taper
MT 5

Coolant System
Fitted

Minimum Distance Spindle to Base
350 mm

Spindle Travel
300 mm

Arm Length
1600 mm

Column Diameter
300 mm

Maut Italy 50 mm Capacity Radial Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Maut Italy 50 mm Capacity Radial Drilling Machine

Make - Maut (Italy)

Drilling Capacity - 50 mm

Spindle Diameter - 80 mm

Arm Length - 1325 mm

Spindle Speeds - 43 rpm to 1100 rpm

Spindle Taper - MT 4

Spindle Feed Travel - 270 mm

Spindle Feed Travel Rates - 0.05 mm/rev to 0.35 mm/rev

Vertical Travel of Arm - 630 mm

Table Size - 655 mm x 450 mm

Clamping - Hydraulic + Manual

- Complete with Coolant Tank and Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1yZ3vO77IBs

Built for Heavy-Duty Metalworking

Designed for continuous operation in demanding environments, the Maut Italy Radial Drilling Machine is manufactured with high-strength cast iron and steel to ensure durability and minimal vibration. Its hardened parts and precision gearbox contribute to reliability and consistent performance in drilling, reaming, and boring tasks.

Flexible Drilling Radius and Adjustable Arm

This machine features a generous 1200 mm drilling radius and a robust 1600 mm arm length, providing flexibility to reach multiple points on large workpieces. The vertical travel of 900 mm and adjustable cutting area allow for efficient positioning and adapting to various fabrication needs.

User Safety and Simple Operation

Equipped with operator guards, emergency stop function, and a manual control system, the machine prioritizes user protection while maintaining ease of operation. Its ergonomics, along with an intuitive manual interface, make it suitable for both experienced machinists and skilled workshop personnel.

FAQs of Maut Italy 50 mm Capacity Radial Drilling Machine:

Q: How is the Maut Italy 50 mm Radial Drilling Machine operated?

A: This machine operates with a manual control system, allowing the operator to manage drilling speeds, arm adjustments, and spindle travel directly. It is semi-automatic, meaning essential movements require operator involvement, ensuring precise and safe execution of tasks.

Q: What are the primary applications of this radial drilling machine?

A: The machine is ideal for drilling, reaming, and boring in metalworking and fabrication industries. Its design supports working on mild steel and other metals, making it suitable for manufacturing, repair shops, and production facilities requiring reliable heavy-duty drilling capabilities.

Q: Where can the Maut Italy 50 mm Capacity Radial Drilling Machine be installed?

A: This radial drilling machine is best placed in industrial workshops, fabrication units, and metalworking plants where heavy-duty and large-scale operations are common. Its size, power requirements, and base dimensions require sufficient floor space and access to 415V, 3 Phase, 50 Hz electrical supply.

Q: What safety features does the machine offer during operation?

A: To ensure operator safety, the machine is equipped with operator guards and an emergency stop button. These features help protect the user from accidental contact with moving parts and allow for immediate halting of operation in case of emergencies.

Q: When should you use the coolant system during drilling?

A: The fitted coolant system should be used whenever drilling, reaming, or boring operations generate significant heat, especially in continuous or deep drilling tasks. This ensures optimal tool life, smooth cutting, and prevents material warping due to elevated temperatures.

Q: How does the adjustable arm benefit the drilling process?

A: The machines adjustable arm allows the operator to position the drill head over various points of large workpieces, improving accessibility and flexibility. This feature streamlines machining workflows, reduces repositioning time, and accommodates projects of different sizes and complexities.

Q: What are the main benefits of using this radial drilling machine?

A: With its high rigidity, precision gearbox, and hardened parts, the machine delivers stable cutting, low noise, and longevity. It supports a wide cutting area and spindle speeds ranging from 8 to 1200 rpm, enabling versatility and precision in operations, ultimately boosting productivity in metalworking tasks.
