Henschel Rober Germany Gear Shaper Machine

Send Inquiry

Request To Call Back

Henschel Rober Germany Gear Shaper Machine

Name: Henschel Rober Germany Gear Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Henschel Rober Germany Gear Shaper Machine Specification

Dimension (L*W*H)
2200 x 1600 x 2200 mm

Power
7.5 kW

Output
High accuracy gear shaping

Color
Grey

Used For
Shaping and cutting gears

Machine Type
Gear Shaper Machine

Capacity
Upto 500 mm gear diameter

Feature
High precision, robust German engineering, durable construction

Voltage
415 V

Weight
Approx. 3500 kg

Condition
Used

Max Internal Gear Diameter
300 mm

Country of Import
Germany

Min-Max Gear Width
10 to 250 mm

Maximum Module
8 module

Max Stroke
160 mm

Coolant System
Included

Machine Control
Manual

Table Diameter
410 mm

Clamping Table Bore
85 mm

Number of Strokes per min
60-350 adjustable

Availability
In Stock

Henschel Rober Germany Gear Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Henschel Rober Germany Gear Shaper Machine

Make - Henschel-Rober (Germany)

Max. Module - 5 Module

Max. Gear Diameter - 500 mm

Max. Stroke Length - 95 mm

Stroke Rates - 60 strokes/min to 650 strokes/min

Table Diameter - 320 mm

Table Bore - 75 mm

Spindle Diameter - 85 mm

Spindle Type - Hollow

Height between Table to Spindle Body - 300 mm

- Automatic Speed Increase for 2nd/3rd Cut Cycles.

- Complete with Change Gears & many other accessories.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/qXmTdHzng_Y

Precision German Engineering

Built in Germany, the Henschel Rober Gear Shaper Machine exemplifies high-quality craftsmanship and long-term durability. Each component is designed for optimal performance, making this machine a preferred choice for demanding shaping operations in the gear manufacturing sector.

Versatile Gear Shaping Capacity

With the ability to shape gears from 10 to 250 mm in width and up to 500 mm in diameter, the machine accommodates various production demands. The adjustable stroke rate and table size ensure adaptability for both small batch and continuous production.

Robust Construction & Manual Control

Featuring a heavy-duty build weighing approximately 3500 kg and a compact footprint (2200 x 1600 x 2200 mm), the gear shaper is engineered for stability and reliability. Manual control allows for flexible operation and precise adjustment during the gear shaping process.

FAQ's of Henschel Rober Germany Gear Shaper Machine:

Q: How is the Henschel Rober Gear Shaper Machine operated?

A: This gear shaper machine is equipped with a manual control system, allowing operators to adjust settings and oversee the gear shaping process directly for enhanced precision.

Q: What types and sizes of gears can this machine shape?

A: The machine is capable of shaping external and internal gears up to 8 module, with gear diameters ranging from 10 mm to 500 mm and widths between 10 and 250 mm.

Q: When should I consider using a gear shaper instead of other gear cutting machines?

A: Gear shapers are ideal when high-precision, accurate gear profiles are required, especially for internal gear cutting or low to medium batch sizes, due to their versatility and ability to handle complex tasks.

Q: Where is this gear shaper machine manufactured and imported from?

A: The Henschel Rober Gear Shaper Machine is manufactured in Germany and is imported directly from there by experienced exporters and suppliers.

Q: What is the process for shaping gears with this machine?

A: The gear blank is mounted on the clamping table, and the shaping tool reciprocates vertically, gradually cutting the gear teeth while the blank and tool synchronize their rotation for precise tooth profiles.

Q: How does the built-in coolant system benefit users?

A: The integrated coolant system helps dissipate heat during the cutting process, ensuring consistent high-quality finishes while extending tool life and maintaining the accuracy of gear profiles.

Q: What are the main advantages of using this German gear shaper machine?

A: Users benefit from high-precision shaping, robust and durable construction, a wide range of gear size compatibility, and reliable manual operation, making it suitable for various industrial applications.
