Huron KU5 Universal Milling Machine

Name: Huron KU5 Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 31000 INR
Availability: InStock

Price 31000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huron KU5 Universal Milling Machine Specification

Model
KU5

Rotation
360° Universal Head Rotation

Product Type
Universal Milling Machine

General Use
Industrial, Milling Operations

Material
Cast Iron Body

Type
Horizontal & Vertical

Capacity
Heavy duty, Large workpiece capability

Weight (kg)
Approx. 5000 kg

Computerized
No

Automatic
Semi-automatic (with manual controls)

CNC Or Not
Conventional (Not CNC)

Control System
Manual

Table Size
2000 mm x 500 mm

Table Slide Way
Dovetail/Boxed

Floor Space
3250 mm x 2860 mm

Spindle Speed
30 - 1410 rpm (18 steps)

Power
7.5 kW Main Motor

Voltage
415 V, 3 Phase

Dimension (L*W*H)
3250 mm x 2860 mm x 1870 mm

Feature
Universal head swivelling, Heavy-duty construction

Color
Grey/Blue Combination

T-Slot Size
18 mm

Coolant System
Yes, Integrated

Table Cross Travel
900 mm

Rapid Traverse Speed
2250 mm/min max

Number of T-Slots on Table
5

Max Distance Spindle Nose to Table
600 mm

Table Vertical Travel
500 mm

Feeds
18 different feed rates (12 - 1000 mm/min)

Main Motor RPM
1440 rpm

Spindle Taper
ISO 50

Longitudinal Travel
1500 mm

Swivel Angle of Milling Head
±45°

Huron KU5 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Huron KU5 Universal Milling Machine

Make - Huron (France)

Model - KU 5

Table Size - 1635 mm x 400 mm

XYZ Travel - 1300 mm x 700 mm x 450 mm

Spindle Speeds - 30 rpm to 2066 rpm

Spindle Taper - ISO 40

Feed Rates - 1.5 mm/min to 750 mm/min

- Double Swivel type Universal Milling Head.

- Equipped with a 3-Axis DRO.

- Operating Manual of the Machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/IU89l9Sx8ys

Versatile Milling for Large Workpieces

The Huron KU5 is designed to handle intensive milling on substantial components, thanks to its heavy-duty build and expansive table. Both horizontal and vertical milling operations are possible, making the machine ideal for workshops that require adaptability to different tasks. Its universal swiveling head and 360 head rotation add significant operational flexibility.

Precision and Performance Engineered

With 18 selectable feed rates (121000 mm/min) and rapid traverse speeds up to 2250 mm/min, the KU5 ensures smooth and accurate machining. The spindle operates in 18 speed steps from 30 to 1410 rpm, powered by a 7.5 kW main motor, supporting rigorous industrial use. The integrated coolant system keeps operations stable, prolonging tool life.

Robust Manual Control System

The KU5 operates as a conventional (not CNC) milling machine, employing manual controls for all settings. This enables direct, hands-on adjustment during milling work, making it well-suited for operators who prefer tactile machining over computerized systems. The semi-automatic feature streamlines tasks while granting full control to the user.

FAQs of Huron KU5 Universal Milling Machine:

Q: How do I operate the Huron KU5 Universal Milling Machine for different milling tasks?

A: The Huron KU5 features manual controls for all key functions. To adapt the machine for various tasks, use the hand wheels and levers to adjust the tables cross, longitudinal, and vertical travels, swivel the universal head as needed (45), and select from 18 feed rates and spindle speeds to match your specific material and cutting requirements.

Q: What are the primary benefits of using the KU5 for industrial milling applications?

A: The main advantages include its large workpiece capacity, heavy-duty construction, and universal head design. The machine allows for both horizontal and vertical millingmaking it suitable for a wide array of operations. Its robust build ensures stability and precision, even during intensive milling sessions.

Q: When should I use the universal head swiveling feature?

A: The universal head swiveling capability is especially useful when you need to perform angled or complex multi-face milling. Adjusting the head up to 45, or utilizing the full 360 head rotation, enables access to hard-to-reach surfaces and facilitates the machining of intricate components without changing setups.

Q: Where is the Huron KU5 typically installed and used?

A: This milling machine is primarily found in industrial workshops, metal fabrication plants, and manufacturing facilities specializing in heavy or large-part milling. Its substantial floor space requirement (3250 mm x 2860 mm) is best suited for facilities with ample room for large machines.

Q: How does the integrated coolant system enhance the machining process?

A: The KU5s built-in coolant system helps dissipate heat generated during milling, reducing thermal distortion of both the workpiece and the cutting tool. This results in improved machining accuracy, extended tool life, and greater operational stability, especially during high-speed or extended-duration cutting tasks.

Q: What materials and components can the KU5 accommodate?

A: Due to its robust capacity and five 18 mm T-slots, the KU5 can securely hold and mill a variety of heavy and large-sized metal workpieces. Its ISO 50 spindle taper supports large cutting tools, making it versatile for a broad range of industrial milling tasks, including steel, cast iron, and other hard metals.
