Huron NU-4 Universal Milling Machine

Name: Huron NU-4 Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huron NU-4 Universal Milling Machine Specification

Model
Huron NU-4

Rotation
Reversible

Product Type
Universal Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron

Type
Universal

Capacity
Heavy Duty

Weight (kg)
Approx. 3200 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
1500 x 355 mm

Table Slide Way
Box Type

Floor Space
Approx. 2600 x 2300 mm

Spindle Speed
351500 rpm

Power
7.5 HP / 5.5 kW

Voltage
415 V / 3 Phase

Dimension (L*W*H)
2600 x 2300 x 1800 mm approx.

Feature
Universal Swivel Head, Rigid Construction

Color
Blue & Grey

Work Table Feed
Mechanical & Automatic

Longitudinal Table Travel
1100 mm

Main Motor
7.5 HP

Spindle Taper
ISO 50

Cross Table Travel
470 mm

Vertical Table Travel
500 mm

Working Speed
Variable

Milling Cutter Diameter
Up to 125 mm

Swivel Head
Universal/360°

Overarm
Yes, for Horizontal Milling

Huron NU-4 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Huron NU-4 Universal Milling Machine

Make - Huron (France)

Model - NU 4

Table Size - 1435 mm x 460 mm

XYZ Travel - 1100 mm x 700 mm x 500 mm

Spindle Speeds - 30 rpm to 2066 rpm

Spindle Taper - ISO 40

Feed Rates - 1.6 mm/min to 820 mm/min

- Double Swivel type Universal Milling Head.

- Suitable for Vertical, Angular & Horizontal Milling Operations.

- Can be operated from Front Side as well as Back Side.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/S5jC7IqfYWU

Versatile Universal Swivel Head

Featuring a universal swivel head that rotates a full 360, the Huron NU-4 allows for complex and angled milling operations. Its adaptability makes it suitable for a wide range of workpieces and machining tasks, enhancing productivity and precision in various industrial applications.

Heavy-Duty Construction for Enhanced Stability

Constructed from high-grade cast iron, this milling machine ensures robust performance and minimized vibrations. Its box-type table slide way and solid 3200 kg build provide stability, making it optimal for heavy-duty machining, long-lasting durability, and reliable repeatability.

Large Table and Extended Travel Capacities

The machine is equipped with a spacious 1500 x 355 mm work table, offering ample room for sizable components. Its longitudinal, cross, and vertical table travels accommodate demanding operations, providing flexibility for handling large industrial milling projects efficiently.

FAQ's of Huron NU-4 Universal Milling Machine:

Q: How does the universal swivel head on the Huron NU-4 enhance machining capabilities?

A: The 360 universal swivel head allows operators to perform milling from various angles, making it easier to machine complex geometrical features and increasing the machine's overall flexibility for diverse industrial applications.

Q: What materials and workpiece sizes can the Huron NU-4 accommodate?

A: With its heavy-duty cast iron construction, spacious table dimensions (1500 x 355 mm), and large travel capacities, the NU-4 can handle robust materials and larger workpiece sizes typical in industrial and manufacturing settings.

Q: When should I choose mechanical versus automatic feed on this milling machine?

A: Mechanical feed is ideal for standard operations requiring operator control, while automatic feed is beneficial during lengthy or repetitive milling tasks, ensuring consistent results and reducing manual effort over extended production sessions.

Q: Where is the Huron NU-4 typically installed and used?

A: The Huron NU-4 is mainly installed in manufacturing plants, metalworking workshops, and industrial production environments that require versatile and robust horizontal milling operations for a variety of large and heavy components.

Q: What is the process for changing spindle speeds on the NU-4?

A: The Huron NU-4 features a variable spindle speed system ranging from 35 to 1500 rpm. Operators can manually select the appropriate speed based on the material and type of milling operation, facilitating precision and efficiency in machining.

Q: How does the box-type table slide way design benefit milling operations?

A: The box-type slide way ensures enhanced stability and minimizes table deflection, resulting in higher machining accuracy and improved surface finish, especially during heavy-duty and high-load operations.
