Huron NU5 Universal Milling Machine

Name: Huron NU5 Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huron NU5 Universal Milling Machine Specification

Rotation
Swiveling Table: 45

Model
Huron NU5

Product Type
Universal Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron

Type
Horizontal / Vertical Universal

Capacity
Heavy Duty

Weight (kg)
Approx. 3500 kg

Computerized
No

Automatic
Manual

CNC Or Not
No (Conventional/Manual)

Control System
Manual

Table Size
1400 x 360 mm

Table Slide Way
Box Type

Floor Space
2300 x 2000 mm

Spindle Speed
30 1500 RPM (12 Steps)

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2400 x 2050 x 1600 mm

Feature
Swiveling Table, Heavy Duty, High Precision

Color
Gray/Blue

Lubrication System
Centralized automatic

Spindle Taper
ISO 50

Distance from Spindle Nose to Table
30 - 530 mm

Table Longitudinal Travel (X-Axis)
1350 mm

Head Tilt/Swivel
Yes (Universal head)

Coolant System
Provided

Main Motor Power
7.5 kW

Rapid Traverse Rate
2000 mm/min

Spindle Feed Range
12 steps

Overarm (Horizontal Spindle)
120 mm

Max. Table Load
900 kg

Table Vertical Travel (Z-Axis)
500 mm

T-Slot Width
18 mm

Number of T-Slots
3

Table Cross Travel (Y-Axis)
400 mm

Huron NU5 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Huron NU5 Universal Milling Machine

Make - Huron (France)

Model - NU 5

Table Size - 1635 mm x 460 mm

XYZ Travel - 1300 mm x 700 mm x 500 mm

Spindle Speeds - 30 rpm to 2066 rpm

Spindle Taper - ISO 50

Feed Rates - 1.6 mm/min to 820 mm/min

- Double Swivel type Universal Milling Head.

- Equipped with a 3-Axis DRO.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/xj92wjscIAs

Versatile Universal Milling for Demanding Tasks

The Huron NU5 is designed to deliver dependable high-precision milling, suitable for a wide range of industrial operations. Its ability to handle horizontal and vertical milling jobs, combined with a swiveling table, ensures adaptability for complex shaping tasks. The heavy-duty cast iron build maintains stability, even under heavy loads, supporting efficient production in manufacturing, metalworking, and tooling environments.

Engineered for Precision and Durability

With a generous 1350 mm X-axis travel, box-type slide ways, and a universal head, the NU5 provides high accuracy and flexibility. The centralized automatic lubrication system and robust main motor promote longevity and smooth performance. Operators benefit from twelve spindle speeds and a strong table load capacity, making it ideal for precision or bulk material removal.

FAQs of Huron NU5 Universal Milling Machine:

Q: How does the Huron NU5 Universal Milling Machine improve industrial milling processes?

A: The Huron NU5 offers both horizontal and vertical milling with a swiveling universal head, enabling complex machining tasks in one setup. Its sturdy construction, precise table movements, and features like rapid traverse and automated lubrication streamline workflow and enhance output quality in industrial environments.

Q: What are the main benefits of using a manual universal milling machine like the NU5?

A: Manual control allows for flexible machining and direct intervention during operations, making it suitable for custom or short production runs. The NU5s heavy-duty build, high load capacity, and precision features ensure dependable, high-quality results without the complexities or costs of CNC systems.

Q: Where can the Huron NU5 be used most effectively?

A: The machine is ideal for use in industrial settings such as manufacturing plants, metal fabrication workshops, and tool rooms where robust, precise, and adaptable milling is required. Its capacity for heavy-duty and high-precision work makes it suitable for diverse applications, from component machining to maintenance.

Q: What process steps are involved in operating the Huron NU5?

A: Operating the NU5 typically involves mounting the workpiece on the table, selecting and installing the appropriate tool, adjusting spindle speeds and feeds (12 steps), and setting the desired travel via manual controls. The automatic lubrication and coolant systems assist in smooth, efficient cutting during the process.

Q: How does the Huron NU5 facilitate precision in milling operations?

A: The machines robust cast iron structure, box-type slide ways, and 12 selectable spindle speeds enable precise control over material removal. The swiveling table and universal head allow intricate positioning, while central lubrication minimizes wear, maintaining accuracy over prolonged use.

Q: What maintenance features does the Huron NU5 provide for extended reliability?

A: It includes a centralized automatic lubrication system and a provided coolant system, reducing manual maintenance requirements and ensuring consistent performance. These features extend machine lifespan and help prevent premature component wear during repeated industrial use.
