Tiger 2000 mm x 600 mm Bed Milling Machine

Name: Tiger 2000 mm x 600 mm Bed Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 16500 INR
Availability: InStock

Price 16500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tiger 2000 mm x 600 mm Bed Milling Machine Specification

Model
Tiger Bed Milling

Rotation
Spindle: Clockwise/Counter-Clockwise

Product Type
Bed Milling Machine

General Use
Heavy-duty Milling Operations

Material
Cast Iron, Steel Components

Type
Horizontal Bed Milling

Capacity
Capable of handling large workpieces up to 2000 mm length

Weight (kg)
Approx. 3200 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
2000 mm x 600 mm

Table Slide Way
Hardened & Ground

Grinding Length
2000 mm

Floor Space
Approx. 3200 mm x 2400 mm

Spindle Speed
Variable, up to 1400 RPM

Power
7.5 HP (Motor Power)

Voltage
415 V, 3 Phase

Dimension (L*W*H)
3200 x 2400 x 2000 mm

Feature
Rugged Construction, Precise Milling, Easy Operation

Color
Tiger Orange & Black

Tool Clamping
Manual with Easy-release Mechanism

Optional Accessories
Digital Readout, Rotary Table, Vice

Standard Accessories
Machine Lamp, Coolant Pump, Draw Bar, Wrench Set

Spindle Motor
Three-phase induction motor

Surface Finish
Machined and Ground

Safety Features
Overload Protection, Emergency Stop

Spindle Bore
MT 5

Vertical Traverse
350 mm

Ram Travel
350 mm

Cross Traverse
600 mm

Table Movement
Longitudinal, Cross, and Vertical

Lubrication
Centralized

Working Table T-Slots
5 Slots, 18 mm each

Max Load on Table
1200 kg

Coolant System
Standard Equipped

Bed Type
Extra Rigid Single Piece Bed

Tiger 2000 mm x 600 mm Bed Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Tiger 2000 mm x 600 mm Bed Milling Machine

Make - Tiger (Italy)

Model - FMT-700

Table Size - 2000 mm x 600 mm

XYZ Travel - 1500 mm x 700 mm x 700 mm

Horizontal Spindle Speeds - 21 rpm to 1235 rpm

Vertical Spindle Speeds - 40 rpm to 1500 rpm

Feed Travel Rates - 10 mm/min to 900 mm/min

Horizontal Spindle Taper - ISO 50

Vertical Spindle Taper - ISO 50

Weight of the Machine - 7.7 tons (Approximately)

- Horizontal Overarm Travel of Vertical Milling Head.

- Double Swivel type Vertical Milling Head.

- Electrical Drawings of the machine are available.

- Equipped with DRO.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/rS7hfDuf5Bc

Rugged Construction for Precision

Designed with an extra rigid, single-piece bed and constructed from premium cast iron and steel components, the Tiger Bed Milling Machine minimizes vibration and ensures consistent accuracy during demanding milling operations. The hardened and ground slide ways, along with machined and ground surface finishes, further enhance the precision, making this machine suitable for a wide range of heavy-duty industrial applications.

Versatile Movements and Easy Operation

This milling machine offers longitudinal, cross, and vertical table movements, with generous traverse distances for versatility. Manual controls are user-friendly, providing straightforward operation and allowing real-time adjustments. Standard equipment like the machine lamp, coolant pump, and wrench set improve operational convenience, while easy-release tool clamping speeds up changing tasks, maximizing productivity and efficiency.

Comprehensive Safety and Accessibility

Safety is paramount, with integral features such as overload protection and an emergency stop mechanism. Standard and optional accessories, including digital readout and rotary table, increase the machines adaptability. Ample table loading capacity and support for large workpieces up to 2000 mm accommodate diverse fabrication projects, all within a durable and visually distinctive Tiger Orange & Black enclosure.

FAQs of Tiger 2000 mm x 600 mm Bed Milling Machine:

Q: How do I operate the Tiger Bed Milling Machine for heavy-duty tasks?

A: Operation is manual and straightforward, utilizing ergonomic controls for longitudinal, cross, and vertical table movements. All actions, including spindle rotation and tool clamping, are direct and user-driven, suitable for precise, heavy-duty milling on large workpieces up to 2000 mm.

Q: What safety features does the Tiger Bed Milling Machine include?

A: The milling machine integrates overload protection and an emergency stop mechanism as standard to prevent damage and ensure the operators safety during intensive milling processes.

Q: When should users apply the longitudinal, cross, and vertical table movements?

A: Apply these movements based on required cutting paths: the longitudinal for longer workpiece passes, the cross movement for width adjustments, and the vertical for depth control, providing flexibility for various milling needs.

Q: Where can I install the Tiger Bed Milling Machine, considering its floor space?

A: Installation requires a floor space of approximately 3200 mm x 2400 mm. Place the machine in a well-ventilated industrial workshop or factory setting where stable power supply (415 V, 3 Phase) and proper maintenance access are ensured.

Q: What is the process for tool clamping and changeover?

A: Tools are clamped manually via an easy-release mechanism. Simply loosen the clamping device, switch tools, and re-tightenallowing fast and secure tool changeover with minimal downtime.

Q: How does the centralized lubrication benefit machine operation?

A: Centralized lubrication ensures all critical moving components receive consistent lubrication, reducing wear, enhancing longevity, and promoting smoother, more reliable performance during extended milling sessions.

Q: What are the primary benefits of choosing the Tiger Bed Milling Machine for my workshop?

A: You gain robust construction, the ability to handle large, heavy workpieces, precise machining, and operational safetyall complemented by a well-equipped set of standard features and a choice of optional add-ons for enhanced versatility.
