IMET Italy Sirio-315 Automatic Circular Sawing Machine

Name: IMET Italy Sirio-315 Automatic Circular Sawing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

IMET Italy Sirio-315 Automatic Circular Sawing Machine Specification

Lubricating System
Automatic

Machine Type
Circular Sawing

Production Capacity
up to 500 cuts/hour

Noise Level
< 80 dB(A)

Operating Temperature
5C - 40C

Drive
Gear Drive

Connectivity Options
Manual/Basic Remote Control

Features
Automatic feeding, fast cycle time, precision clamping

Motor Power
2.2 kW

Power Rating
2.2 kW

Cooling System
Integrated Coolant System

Frequency
50 Hz

Accuracy
0.1 mm

Frame Type
Heavy Duty Steel

Control System
Electro-Mechanical

Model No
Sirio-315

Voltage
400 V

Product Type
Automatic Circular Sawing Machine

Technology
Automatic, Cold Saw

Power Source
Electric

Operating Type
Automatic

Power
2.2 kW

Pressure
Hydraulic, Adjustable

Surface Treatment
Powder Coated

Dimension (L*W*H)
1100 x 700 x 1500 mm

Weight (kg)
260 kg

Color
Grey/Blue

Usage & Applications
Industrial bar and tube cutting

Cutting Angle Range
0 - 45

Cutting Capacity (Round)
Up to 100 mm

Display Type
Mechanical Dial

Standards Compliance
CE Certified

Material Suitable
Steel, Stainless Steel, Non-Ferrous Metals

Clamping System
Double Vice, Rapid

Blade Type
HSS Circular Blade

Service Support
Onsite/Remote Assistance

Blade Bore
32 mm

Phase
Three Phase

Automation Grade
Automatic

Maximum Cutting Length
600 mm

Working Speed
15/30 rpm (Blade Speeds)

Safety Features
Emergency Stop, Safety Guards

Grip Type
Hydraulic Clamping

Stroke Length
600 mm (bar feed stroke)

Feed System
Automatic Bar Feeder

Minimum Cutting Length
10 mm

Cutting Capacity (Square)
Up to 90 x 90 mm

Blade Diameter
315 mm

About IMET Italy Sirio-315 Automatic Circular Sawing Machine

IMET (Italy) make Fully Automatic Ciruclar Sawing Machine in excellent working condition. The model of the machine is SIRIO-315 Automatic and the Cutting Capacity for Solid Round is 70 mm Diameter. The machine can work in Full Automatic Mode as well as in Semi-Automatic Mode. The machine has provision for Angular (Mitre) Cutting as well. The technical details are as follows -

Make - IMET (Italy)

Model - SIRIO-315 Automatic

Cutting Capacity for Solid Round - 70 mm

Cutting Capacity for Round Pipe - 105 mm

Cutting Capacity for Square Pipe - 88 mm

Cutting Capacity for Rectangle Pipe - 140 mm x 80 mm

Circular Saw Blade Diameter - 315 mm

Maximum Vice Opening - 180 mm

Max. Travel for Auto-Feed Vice - 590 mm (single time)

Max. No. of Travels for Auto-Feed Vice - 2 Times

Saw Blade Rotation Speeds - 9 / 18 / 36 / 74 rpm

Type - Fully Automatic

- Machine has provision for Angular (mitre) cutting.

- Can be used in Full Automatic Mode and Semi-Automatic Mode.

- Complete with Coolant Tank & Coolant Pump.

- The machine is in as good as new condition.

Video of The Machine -

https://youtu.be/ydhrguzGuI4

Unmatched Cutting Versatility

The Sirio-315 offers precise cutting performance for a wide variety of metals including steel, stainless steel, and non-ferrous materials. With a maximum cutting capacity of 100 mm (round) and 90 x 90 mm (square), it is highly suitable for industrial fabrication, bar, and tube processing operations. Its heavy-duty construction and reliable clamping system ensure top-notch results every cycle.

Automated Efficiency and User Safety

Featuring an automatic bar feeding system and fast hydraulic clamping, the Sirio-315 is engineered for high productivity-achieving up to 500 cuts per hour. Operator safety is prioritized with features such as emergency stop buttons and comprehensive safety guards. The machine's power-efficient 2.2 kW motor and advanced cooling system enable consistent operation with minimal downtime.

Precision Engineering and Support

With accuracy up to 0.1 mm, adjustable cutting angles (0-45), and integrated lubrication, the Sirio-315 ensures consistently clean and precise results. Users benefit from CE-certified standards, built-in display dials for monitoring, and the option for onsite or remote technical assistance-backed by trusted service across India.

FAQ's of IMET Italy Sirio-315 Automatic Circular Sawing Machine:

Q: How does the automatic bar feeder work in the Sirio-315 circular sawing machine?

A: The automatic bar feeder in the Sirio-315 enables continuous material feeding during cutting cycles. It uses a hydraulic system to securely grip and feed the bar up to the set stroke length (600 mm), resulting in consistent, hands-free operation and significantly reducing manual intervention.

Q: What types of materials can be processed with the Sirio-315 saw?

A: The machine is capable of cutting steel, stainless steel, and non-ferrous metals. Its HSS circular blade and sturdy hydraulic clamping make it ideal for a wide range of industrial metalworking and fabrication tasks.

Q: When should the machine's integrated coolant and lubrication systems be used?

A: The integrated coolant and automatic lubrication systems should always be used during operation. These features help maintain blade longevity, improve cutting performance, and reduce heat buildup, ensuring cleaner cuts and extended service life.

Q: Where can the Sirio-315 be installed and operated?

A: The Sirio-315 is suitable for installation in industrial workshops, fabrication plants, and manufacturing units. Its compact dimensions (1100 x 700 x 1500 mm) and low noise (<80 dB[A]) make it adaptable to various production environments.

Q: What is the process for setting the cutting angle and length on this machine?

A: Operators can set the cutting angle between 0 and 45 using the mechanical dial. The desired cutting length, from 10 mm up to 600 mm, is adjusted on the automatic feeder. Once configured, the machine executes precise, repeatable cuts according to the programmed specifications.

Q: What benefits does the double vice hydraulic clamping system provide?

A: The double vice hydraulic clamping ensures stable and secure positioning of the workpiece during cutting. This minimizes vibration, enhances accuracy, improves safety, and allows for rapid cycle times-resulting in high-quality end products with each operation.
