Gloria Super Italy Automatic Pitch Controlled Tapping Machine

Name: Gloria Super Italy Automatic Pitch Controlled Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Gloria Super Italy Automatic Pitch Controlled Tapping Machine Specification

Drive
Belt drive

Operating Temperature
5°C to 45°C

Voltage
230 V

Machine Type
Automatic Tapping

Production Capacity
Up to 800 pieces/hr

Model No
Super Italy

Lubricating System
Centralized

Features
Adjustable pitch, precision threading, robust frame

Frequency
50 Hz

Motor Power
0.75 kW

Accuracy
±0.05 mm

Frame Type
Heavy-duty steel

Power Rating
Single Phase, 0.75 kW

Control System
Automatic pitch control panel

Connectivity Options
Manual interface, optional PLC

Cooling System
Integrated coolant pump

Noise Level
Below 75 dB

Product Type
Automatic Pitch Controlled Tapping Machine

Technology
Automatic Pitch Control

Power Source
Electric

Operating Type
Semi-Automatic

Power
0.75 kW

Pressure
Adjustable up to 4 bar

Surface Treatment
Polished

Dimension (L*W*H)
820 x 500 x 1200 mm

Weight (kg)
290 kg

Color
Blue & Silver

Usage & Applications
Thread cutting, Metal fabrications

Supported Tap Sizes
M3 - M16

Maximum Workpiece Diameter
60 mm

Table Opening (mm)
50 mm

Clamping Type
Quick clamp with safety lock

Material of Construction
Alloy steel & cast iron

Safety Features
Emergency stop switch, interlock guards

Standard Accessories
Collet set, coolant system, maintenance tools

Spindle Travel
70 mm

Main Shaft Speed
Adjustable, up to 1200 rpm

Phase
Single Phase

Electrical Protection
Overload and short circuit protection

Gloria Super Italy Automatic Pitch Controlled Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Gloria Super Italy Automatic Pitch Controlled Tapping Machine About

Make - Gloria Super (Italy)

Model - ROMA

Capacity in Diameter - 20 mm

Table Size - 360 mm x 310 mm

Spindle Diameter - 40 mm

Max. Spindle Travel - 60 mm

Spindle Speeds - 180 rpm to 780 rpm

Spindle Motor - 1.50 HP

Different Pitch Bushes Available - 0.5 / 1.0 / 1.25 / 1.50 / 1.75 / 2.00 mm

- Complete with Coolant Tank & Pump.

- Can be used in Continuous, Timer Controlled, Singular & Impulse Mode.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/hwPileO7rXM

Advanced Pitch Control Technology

Gloria Super Italy's automatic pitch control panel streamlines threading operations, enabling precise pitch adjustments with minimal effort. This advancement automates the intricate task of maintaining thread accuracy, reducing operator errors while increasing efficiency in repeated tapping jobs. Users can easily select and alter pitch settings using the intuitive control interface, optimizing output for various production needs.

Safe and Efficient Operation

Safety is integral to the Super Italy Tapping Machine. Equipped with emergency stop switches, interlock guards, and comprehensive electrical protection, the operator is shielded from unexpected incidents. These features work alongside the robust framework and quick clamp system to further prevent mishaps, making it ideal for high-paced industrial environments. The integrated coolant system and centralized lubrication extend machine longevity and reliability.

Versatile Performance Applications

Suitable for a diverse range of metal fabrication and thread cutting applications, the Super Italy model's broad support for M3-M16 tap sizes makes it perfect for workshops, factories, and industrial production lines. Designed for up to 800 pieces per hour and heavy-duty, continuous operation, it meets the high demands of exporters, manufacturers, and suppliers requiring dependable tapping solutions with low noise and precise finishes.

FAQ's of Gloria Super Italy Automatic Pitch Controlled Tapping Machine:

Q: How does the Super Italy Tapping Machine maintain accurate thread pitches during operation?

A: The machine uses an automatic pitch control panel, ensuring each thread is precisely formed to the set pitch within 0.05 mm accuracy. This system eliminates manual errors and maintains thread consistency for every workpiece.

Q: What steps are involved in setting up the machine for tapping metal components?

A: Begin by securing the workpiece using the quick clamp with safety lock. Select the appropriate collet and tap size (M3-M16), adjust spindle speed and pressure as required, set the pitch on the control panel, and ensure the coolant and lubrication systems are active before starting the operation.

Q: When should the built-in coolant and lubrication systems be used?

A: Both systems should be activated during every tapping operation to reduce heat generation, ensure smoother threading, and prolong tool and machine life. Regular maintenance of these systems is advised for continuous, trouble-free performance.

Q: Where can the Super Italy Tapping Machine be utilized effectively?

A: This machine is ideal for metal fabrication workshops, manufacturing units, and industrial environments that require volume thread cutting. It suits exporters, manufacturers, suppliers, and traders handling diverse tapping tasks.

Q: What are the main benefits of using an automatic pitch controlled tapping machine?

A: Automatic pitch control minimizes thread errors, enhances process repeatability, and boosts productivity. The machine's safety features, robust build, and quick setup also lead to reduced downtime and higher operational safety.

Q: How does the safety system protect operators during use?

A: Safety is ensured via emergency stop switches, interlock guards, and integrated overload and short-circuit protection. These features promptly halt operations and prevent accidental injury or machine damage.

Q: What is the maximum workpiece diameter and tap size the machine supports?

A: The Super Italy Tapping Machine accommodates workpieces up to 60 mm in diameter, with tap sizes ranging from M3 to M16, allowing for versatile application in various metalworking scenarios.
