IZPE Thru-Feed Thread Rolling

Get a Price/Quote

MOQ : 1 Piece

IZPE Thru-Feed Thread Rolling Specification

Feature
Thru-Feed Thread Rolling suitable for continuous operation

Machine Type
Thru-Feed Thread Rolling

Origin
India

Warranty
Not available

Output
High efficiency thread rolling

Manufacturing Year
Not available

Weight
Estimated 600 kg

Voltage
220V

Dimension (L*W*H)
Not available

Capacity
Up to 6mm thread rolling

Color
Grey

Condition
Used

Used For
Thread rolling operations for screws bolts and fasteners

Power
3 HP

About IZPE Thru-Feed Thread Rolling

Make - IZPE (Spain)

Model - V2E

Job Diameter - 8 mm to 75 mm

Maximum Roll Diameter - 180 mm

Maximum UNC or BSW Pitch - 4 T.P.I.

Spindle Speeds - 37 rpm to 214 rpm

Incline Angle of Rolls - +10 to -10

- With spare gears (for speed changing), stand, coolant pump etc.

- Machine is in excellent working condition.

Vidoa link - https://youtu.be/zLUDxMJunzc

High-Efficiency Thru-Feed Thread Rolling

The IZPE machine is engineered for uninterrupted, high-speed thread rolling, allowing for optimal productivity in batch manufacturing. Its thru-feed feature facilitates continuous material flow, thereby reducing cycle times and improving overall output for screws, bolts, and fasteners.

Durable Construction and Reliable Power

With a solid build and a 3 HP motor running on 220V, the IZPE Thru-Feed Thread Rolling machine ensures stability and consistent operation. The machines estimated 600 kg weight contributes to its robust performance, making it suitable for diverse industrial environments.

FAQs of IZPE Thru-Feed Thread Rolling:

Q: How does the IZPE Thru-Feed Thread Rolling machine operate?

A: This machine uses a thru-feed system to continuously roll threads onto screws, bolts, and fasteners, effectively supporting large-scale production without frequent interruption.

Q: What types of threads can be produced with this machine?

A: The IZPE model can efficiently roll threads up to 6mm in diameter, accommodating a variety of fasteners used across multiple industries.

Q: When is it best to use the IZPE Thru-Feed Thread Rolling machine?

A: It is most effective for high-volume manufacturing processes requiring continuous thread rolling, especially when speed and efficiency are critical.

Q: Where can this machine be used in industrial settings?

A: The machine is suitable for deployment in manufacturing units, workshops, and export-oriented facilities, with particular use in Spain, as well as international operations.

Q: What is the process for operating this thru-feed thread rolling machine?

A: Operators feed fastener blanks into the machine, which automatically rolls threads as the components pass through, using precision dies and controlled pressure for accuracy.

Q: What are the main benefits of using this thread rolling machine?

A: Benefits include enhanced production efficiency, consistent thread quality, reduced cycle times, and the ability to handle continuous operations with minimal downtime.
