Jotes 1000 mm x 300 mm Surface Grinding Machine

Price 100000 INR/ Piece

Get a Price/Quote

Jotes 1000 mm x 300 mm Surface Grinding Machine Specification

Rotation
Clockwise (wheel rotation)

Model
Jotes 1000 x 300

Product Type
Surface Grinding Machine

General Use
Precision surface grinding for metalworking and tool rooms

Material
Cast Iron, Steel

Type
Horizontal spindle

Capacity
Heavy duty (1000 mm grinding length)

Weight (kg)
Approx. 4500 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Conventional (Not CNC)

Control System
Manual

Table Size
1000 mm x 300 mm

Table Slide Way
V and flat guideways

Magnetic Chuck Size
1000 mm x 300 mm

Grinding Wheel Size
350 mm diameter

Grinding Wheel Speed
1400 RPM

Grinding Length
1000 mm

Floor Space
Approximately 2500 mm x 2200 mm

Fuel Tank Capacity
n/a (electrically powered)

Spindle Speed
1400 RPM

Power
7.5 kW

Voltage
415 V, 3 phase

Dimension (L*W*H)
Approx. 2500 mm x 2200 mm x 1800 mm

Feature
Hydraulic table drive, coolant system, precision feed

Color
Industrial Grey

Jotes 1000 mm x 300 mm Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Jotes 1000 mm x 300 mm Surface Grinding Machine

Make - Jotes (Poland)

Model - SPD - 30C

Magnet Size - 300 mm x 1000 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Max. Distance between Wheel Center to Table - 575 mm

Max. Cross Travel of Wheel - 370 mm

Least Count of Vertical Travel - 2 Microns (0.002 mm)

Weight - 5 tons (Approximately)

- Complete with Magnetic Coolant Filtration Unit, Tank & Pump.

- Equipped with a Wheel-Top Mounted Wheel Dresser.

- Complete with its Operating Manual.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/-suQQyfFsh8

Robust Heavy-Duty Construction

The Jotes 1000 x 300 features a solid cast iron and steel build, ensuring exceptional stability and vibration dampening during operations, even under high table loads. Its substantial weight and large footprint allow for smooth, reliable performance in continuous precision grinding.

Precision Surface Grinding

Offering cross feed graduation of 0.01 mm and vertical feed graduation of 0.001 mm, this machine is tailored for high-accuracy metalworking. The heavy-duty magnetic chuck and hydraulic table drive provide uniform and controlled material removal for a flawless surface finish.

Integrated Systems for Efficiency

Fitted with an automatic lubrication system and an integrated coolant unit, this surface grinder minimizes downtime for maintenance. These systems boost the machines lifespan and ensure consistent, uninterrupted operation during prolonged grinding sessions.

FAQs of Jotes 1000 mm x 300 mm Surface Grinding Machine:

Q: How does the Jotes 1000 x 300 Surface Grinding Machine achieve such high surface finish accuracy?

A: The Jotes 1000 x 300 is engineered with precision ground V and flat guideways, hydraulic table movement, and finely graduated feed mechanisms (down to 0.001 mm). Combined with an integrated coolant system, these features help maintain surface finish accuracy up to 0.003 mm.

Q: What types of parts or materials can be processed with this machine?

A: This surface grinding machine is designed for precision grinding of metal parts and components, including steel and cast iron. It is ideal for tool rooms and metalworking industries requiring flat, highly accurate surfaces.

Q: When should I use the integrated magnetic chuck feature?

A: The electromagnetic chuck is recommended whenever you need to securely hold ferromagnetic workpieces for precision grinding. Its 1000 x 300 mm surface keeps components rigidly positioned throughout the operation, ensuring uniform grinding results.

Q: Where is the Jotes 1000 x 300 best utilized?

A: It is best suited to heavy-duty industrial environments such as manufacturing plants, metalworking shops, and tool rooms where demanding surface grinding tasks are regularly carried out.

Q: What maintenance processes are involved with this surface grinder?

A: With automatic lubrication and an integrated coolant system, routine maintenance is simplified. Regular checks should include cleaning the grinding wheel, inspecting hydraulic oil levels, and ensuring guideway surfaces are free of debris for optimal performance.

Q: How does the hydraulic system benefit the grinding process?

A: The hydraulic table drive delivers smooth, consistent table movement, reducing operator fatigue and enhancing grinding precision over long work cycles.

Q: What are the advantages of using this conventional, semi-automatic surface grinding machine over CNC alternatives?

A: This model offers ease of use, lower operational complexity, robust construction, and precise manual control. It excels where repetitive tasks with minimal setup change are required, making it a practical option for various workpieces and batch sizes.
