Korea 1500 mm Length Lathe Machine

Name: Korea 1500 mm Length Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 15500 INR
Availability: InStock

Price 15500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Korea 1500 mm Length Lathe Machine Specification

Product Type
Conventional Lathe Machine

Material
Cast Iron Body

Cutting Thickness
Depends on tooling and material

Cutting Speed
Variable (Manual adjustment)

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
400 mm

Voltage
400V / 3 Phase / 50Hz

Weight (kg)
1850 kg (Approx)

Dimension (L*W*H)
2250 mm x 750 mm x 1150 mm (Approx)

Capacity
1.5 Meter (Center Distance)

Feature
Heavy Duty, Precision-Built, Hardened Bedways

Color
Standard Factory Grey/Blue

Number of Spindle Speeds
8-12

Gearbox
Heavy Duty, Hardened Gears

Surface Finish
Ground and Hardened

Spindle Bore
52 mm

Tailstock Quill Travel
150 mm

Chuck Size
200 mm

Coolant System
Inbuilt

Lead Screw Pitch
4 mm

Distance Between Centers
1500 mm

Bed Length
1500 mm

Main Motor Power
3 HP

Korea 1500 mm Length Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Korea 1500 mm Length Lathe Machine About

Make - Korea

Model - S1-250 (same as TOS SU 50 Lathe)

Center Height - 250 mm

Length of Job - 1500 mm

Max. Swing Diameter over Bed - 500 mm

Max. Swing Diameter over Cross-Slide - 270 mm

Bed Width - 420 mm

Spindle Speeds - 11.2 rpm to 1400 rpm

Spindle Bore - 55 mm

Chuck Diameter - 250 mm

- Motorized Rapid Travels on Carriage & Cross-Slide.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/cS2e1wpvHNU

Precision Engineering for Heavy-Duty Tasks

Designed with hardened bedways and a heavy-duty gearbox, this machine is well-suited for high-precision turning applications. Its solid cast iron construction provides stability and minimizes vibrations during operation, ensuring a fine surface finish on workpieces.

Versatile and Adjustable Machining

With a center distance of 1.5 meters and a max swing diameter of 400 mm, this manual lathe can handle a wide variety of workpiece sizes. Variable cutting speed, adjustable via manual controls, allows for flexibility across different materials and tooling requirements.

Built for Endurance and Operator Comfort

The Korea lathe machine features an inbuilt coolant system and ground, hardened gears for sustained use under rigorous conditions. Its standard factory grey/blue color ensures easy integration into industrial environments, while clear manual controls make it operator-friendly.

FAQs of Korea 1500 mm Length Lathe Machine:

Q: How does the manual control system of this lathe machine work?

A: The lathe uses a manual control system, allowing operators to adjust cutting speeds and machining operations directly on the machine. This hands-on approach enables precise control over the cutting process and caters to diverse workpiece requirements.

Q: What types of materials can be processed with this lathe?

A: Thanks to its heavy-duty build and adjustable speed settings, the lathe can handle a range of materials, including various metals and hard plastics. The specific cutting thickness achievable depends on the choice of tooling and workpiece material.

Q: When should I use the inbuilt coolant system?

A: The inbuilt coolant system should be activated during extended or high-speed turning operations. It helps dissipate heat generated by the cutting process, thereby prolonging tool life and ensuring a superior surface finish.

Q: Where is this lathe machine typically used?

A: This lathe is commonly found in manufacturing workshops, metal fabrication plants, and repair shops. Its robust design makes it suitable for exporters, importers, manufacturers, and machine traders seeking reliable heavy-duty machinery.

Q: What is the process for changing spindle speeds on the lathe?

A: Spindle speeds can be adjusted manually through the gearbox. The machine offers 8 to 12 spindle speed options, enabling operators to match cutting conditions with material type and tooling requirements for optimal performance.

Q: What are the main benefits of using a Korea 1500 mm Length Lathe Machine?

A: Key benefits include high-precision machining, adaptability to various workpiece sizes, reliable heavy-duty construction, and longevity thanks to ground and hardened surfaces. Its manual operation provides experienced machinists with enhanced control.
