Martin Germany 3200 mm Length Heavy Duty Lathe Machine

Name: Martin Germany 3200 mm Length Heavy Duty Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Martin Germany 3200 mm Length Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 10 mm (depending on tool and material)

Cutting Speed
Up to 40 m/min

CNC Or Not
No (Conventional Lathe)

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
700 mm

Voltage
415 V

Weight (kg)
Approximately 4200 kg

Dimension (L*W*H)
Approx. 4700 mm x 1100 mm x 1450 mm

Capacity
Heavy Duty

Feature
Rigid Structure, High Precision

Color
Machine Grey

Bed Length
3200 mm

Cross Slide Travel
400 mm

Tailstock Quill Diameter
75 mm

Application
Metal Turning, Facing, Drilling, Thread Cutting

Tailstock Quill Travel
200 mm

Distance Between Centers
2000 mm

Main Motor Power
7.5 HP

Surface Finish
Precision Ground

Spindle Bore
80 mm

Spindle Speed Range
321600 RPM

Bed Width
470 mm

Chuck Size
400 mm 3-jaw

Lead Screw Diameter
40 mm

Martin Germany 3200 mm Length Heavy Duty Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Martin Germany 3200 mm Length Heavy Duty Lathe Machine

Make - Martin (Germany)

Model - D-80

Center Height - 405 mm

Max. Length of Job - 3200 mm

Max. Job Diameter over Bed - 800 mm

Max. Job Diameter over Cross-Slide - 520 mm

Max. Job Diameter in Gap - 1100 mm

Max. Job Length in Gap - 315 mm

Bed Width - 530 mm

Chuck Diameter - 895 mm

Spindle Speeds - 14 rpm to 630 rpm

Spindle Bore - 94 mm

- Complete with 2 x Job Steady, Centers and other accessories.

- Machine is in excellent working condition.

Video of the machine -

https://youtu.be/-iqoG7_SYwI

Robust Design for Heavy-Duty Performance

Built with a sturdy cast iron frame and a precision-ground surface finish, this lathe delivers maximum rigidity and stability, essential for high-precision machining. Its substantial 4200 kg weight and wide 470 mm bed ensure consistent performance during demanding metal turning and cutting tasks.

Versatile Machining Capabilities

Equipped to carry out a spectrum of processes such as turning, facing, drilling, and thread cutting, the Martin heavy-duty lathe allows flexibility for users across various industries. The large cross slide travel, adjustable spindle speeds, and a 400 mm chuck ensure work on diverse and complex workpieces.

User-Friendly Manual Operation

Designed for manual control, this conventional lathe provides direct operator engagement, enabling precise adjustments and craftsmanship. Its non-CNC control system is ideal for users seeking hands-on machining, making it suitable for both skilled professionals and educational purposes.

FAQ's of Martin Germany 3200 mm Length Heavy Duty Lathe Machine:

Q: How does the Martin Germany 3200 mm Heavy Duty Lathe Machine improve metalworking productivity?

A: This lathe features a powerful 7.5 HP motor, adjustable spindle speeds from 32 to 1600 RPM, and robust construction, enabling efficient handling of large, heavy workpieces. Its precision-ground bed and stable frame minimize vibrations, enhancing accuracy and throughput in metal turning and cutting operations.

Q: What materials and processes can be performed with this lathe?

A: Primarily designed for metalworking, the lathe can perform turning, facing, drilling, thread cutting, and similar tasks on various metals. Its rigid cast iron structure accommodates cutting, shaping, and finishing processes for materials up to 10 mm in thickness, depending on the tool and material used.

Q: When is manual operation advantageous for this machine?

A: Manual operation is beneficial when precise, hands-on control is required. Operators can make real-time adjustments and develop high-quality custom components. This is particularly advantageous for prototyping, repair work, and training environments where operator expertise is valued.

Q: Where is the ideal setting to use this lathe machine?

A: Due to its size, weight, and capabilities, this lathe is best suited for industrial machine shops, manufacturing facilities, educational institutions, and repair workshops involved in medium to heavy-duty metalworking activities.

Q: What is the process for changing spindle speed and setup on this lathe?

A: Spindle speed can be manually adjusted within the range of 32-1600 RPM, providing flexibility for different types of cuts and materials. Setup involves selecting the appropriate speed, positioning the workpiece using the robust 400 mm chuck, and adjusting the cross slide and tailstock as needed for accuracy.

Q: What are the key benefits of using this heavy-duty lathe machine?

A: Major benefits include high rigidity for precise machining, versatility in handling different workpiece dimensions, manually controlled setups for operator flexibility, and long-term durability because of its cast iron structure and precision-engineered components.
