Colchester 1500 mm Lathe Machine

Name: Colchester 1500 mm Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester 1500 mm Lathe Machine Specification

Product Type
Conventional Lathe Machine

Material
Heavy-duty cast iron bed and hardened steel gears

Cutting Thickness
Varies according to tool and setup

Cutting Speed
Up to 2000 RPM

CNC Or Not
No (Manual Operation)

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
375 mm

Voltage
415 V, 3 Phase

Weight (kg)
Approx. 1200 kg

Dimension (L*W*H)
Approximately 2600 mm x 950 mm x 1450 mm

Capacity
1500 mm between centers

Feature
Hardened & ground bedways, quick-change gearbox, high rigidity

Color
Standard Grey/Blue

Spindle Bore
38 mm

Lead Screw Diameter
30 mm

Thread Cutting Range (Imperial)
2 to 72 TPI

Spindle Speed Range
302000 RPM

Main Motor Power
3 HP (2.2 kW)

Distance Between Centers
1500 mm

Tailstock Quill Travel
125 mm

Number of Spindle Speeds
12

Chuck Size
200 mm (3-jaw)

Bed Width
250 mm

Noise Level
70 dB

Longitudinal Feed Range
0.05 to 1.70 mm/rev

Thread Cutting Range (Metric)
0.2 to 14 mm

Cross Slide Travel
200 mm

Tool Post
4-way tool post

Tailstock Quill Diameter
55 mm

Colchester 1500 mm Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Colchester 1500 mm Lathe Machine About

Make - Colchester (England)

Model - Mascot 1600

Center Height - 225 mm

Max. Length of Job - 1500 mm

Max. Job Diameter over Bed - 440 mm

Max. Job Diameter over Cross-Slide - 265 mm

3-Jaw Chuck Diameter - 310 mm

Spindle Speeds - 20 rpm to 1600 rpm

Bed Width - 342 mm

Max. Swing Diameter in Gap - 710 mm

Face Plate Diameter - 530 mm

Spindle Bore - 78 mm

- Complete with Steady, Face Plate, Tool Holders & other accessories.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/s2u8FynAicQ

Superior Construction and Capacity

The Colchester 1500 mm Lathe Machine boasts a hardened and ground cast iron bed matched with precision steel gears. The expansive 1500 mm distance between centers facilitates machining longer workpieces, supported by a rigid 250 mm wide bed and maximum swing diameter of 375 mm, ensuring stability and accuracy for heavy-duty applications.

Versatile Machining Performance

Equipped with a 3 HP (2.2 kW) motor, the lathe delivers spindle speeds from 30 to 2000 RPM with 12 selectable speeds. The 3-jaw 200 mm chuck, quick-change gearbox, and thread cutting ranges (0.214 mm metric, 272 TPI imperial) provide users with adaptable capabilities for a wide variety of turning, threading, and finishing tasks.

Ergonomic Manual Controls and Safety

The Colchester 1500 mm Lathe Machine features a user-friendly manual control system, including a four-way tool post and clearly organized feed rates. Efficiency is enhanced by the longitudinal feed range of 0.05 to 1.70 mm/rev, cross slide travel of 200 mm, and a noise level maintained below 70 dB for operator comfort and safety during prolonged use.

FAQs of Colchester 1500 mm Lathe Machine:

Q: How is the Colchester 1500 mm Lathe Machine operated?

A: This lathe is designed for manual operation and does not utilize CNC technology. All machining processes are controlled directly by the operator via ergonomic handwheels, levers, and the quick-change gearbox, offering precision and flexibility for skilled machinists.

Q: What types of materials can be processed with this lathe machine?

A: Thanks to its heavy-duty cast iron bed and hardened steel gears, the Colchester lathe handles a broad spectrum of metals, including steel, aluminum, and brass. The robust construction and powerful motor make it suitable for both rough stock removal and fine finishing tasks.

Q: When should I use the quick-change gearbox on this lathe?

A: The quick-change gearbox is best utilized when you need to adjust feed rates or perform thread cutting operations. It delivers rapid and precise transitions between threading and feeding modes, minimizing downtime and improving overall productivity.

Q: Where can the Colchester 1500 mm Lathe Machine be installed?

A: This machine is suitable for workshops, manufacturing facilities, and training centers equipped with a 415 V, 3-phase power supply. Its substantial size and weight (approx. 1200 kg) require a firm, level surface capable of supporting heavy equipment.

Q: What is the process for changing spindle speeds on this lathe?

A: Spindle speeds can be adjusted by selecting from 12 available speed settings using the control levers positioned on the headstock. This allows the operator to match cutting speeds to material and tooling requirements for optimal machining results.

Q: How does the lathe benefit users in terms of precision and efficiency?

A: Precision is ensured through features such as the hardened and ground bedways and high rigidity structure, while efficiency is enhanced by the 4-way tool post, quick-change gearbox, and comprehensive threading and feed options. These aspects help reduce setup times and maintain consistent accuracy.

Q: Is the Colchester 1500 mm Lathe Machine compliant with safety and noise standards?

A: Yes, it is designed with operator safety in mind, maintaining noise levels at 70 dB and offering straightforward controls. Material strength and construction contribute to safe, stable operation during heavy-duty machining.
