XYZ England 1340 Lathe Machine
XYZ England 1340 Lathe Machine

XYZ England 1340 Lathe Machine

Price 38000 INR/ Piece

MOQ : 1 Piece

XYZ England 1340 Lathe Machine Specification

  • Product Type
  • Manual Lathe Machine
  • Material
  • Cast Iron Body
  • Cutting Thickness
  • Up to 20 mm
  • Cutting Speed
  • 40 to 2040 RPM
  • CNC Or Not
  • No
  • Automatic Grade
  • Semi-Automatic
  • Control System
  • Conventional (Manual Controls)
  • Max. Swing Diameter
  • 340 mm
  • Voltage
  • 415 V
  • Weight (kg)
  • 735 kg
  • Dimension (L*W*H)
  • 2060 x 910 x 730 mm
  • Capacity
  • 1340 mm between centers
  • Feature
  • Heavy Duty, Precision Engineering, Hardened Bedways, Geared Headstock
  • Color
  • Grey
  • Thread Range
  • 0.2 to 7 mm pitch
  • Lead Screw Diameter
  • 25 mm
  • Bed Width
  • 187 mm
  • Spindle Bore
  • 38 mm
  • Surface Finish Achievable
  • Up to 2 micron
  • Power of Main Motor
  • 2 HP
  • Carriage Traverse
  • 730 mm
  • Distance Between Centers
  • 1340 mm
  • Number of Speeds
  • 8 Speeds
  • Coolant Pump
  • Included
  • Chuck Size
  • 200 mm
  • Tailstock Quill Travel
  • 120 mm
  • Spindle Taper
  • MT4


XYZ England 1340 Lathe Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About XYZ England 1340 Lathe Machine

Make - XYZ (England)

Model - 1340

Center Height - 165 mm

Max. Length of Job - 1000 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 190 mm

Spindle Speeds - 53 rpm to 2000 rpm

Bed Width - 190 mm

Spindle Bore - 35 mm

Max. Job Diameter in Gap - 490 mm

3-Jaw Chuck Diameter - 160 mm

4-Jaw Chuck Diameter - 150 mm

Year of Make - 2007

- Complete with 3-Point Steady, Follow Rest etc.

- Equipped with Foot Operated Spindle Brake.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/PztNQxd8nsI



Engineered for Accuracy and Reliability

Experience top-tier performance with the XYZ England 1340 Lathe, featuring precision-ground, hardened bedways and a stable cast iron body. Its robust construction allows for precise metalworking, whether for prototyping or small-batch production. This lathe is engineered to deliver reliable results, even during continuous operation.


Versatile Operations and Broad Applications

With a distance between centers of 1340 mm and a max swing diameter of 340 mm, this lathe covers a wide range of turning needs. Eight selectable speeds, a 0.2 to 7 mm thread range, and a 2 HP motor enable users to process various materials and geometries, making it an excellent fit for workshops and manufacturing units.


Enhanced User Control and Safety

Operating on 415V and equipped with manual controls, the XYZ 1340 Lathe offers direct, intuitive machining for skilled operators. Safety features, coolant pump, and semi-automatic grade construction minimize risks, while consistent surface finishes up to 2 microns underscore its high-precision capabilities.

FAQs of XYZ England 1340 Lathe Machine:


Q: How do I operate the XYZ England 1340 Lathe Machine for optimal performance?

A: To achieve optimal results, ensure the machine is correctly leveled and installed on a stable floor. Select the appropriate spindle speed from the 8 available options, adjust the cutting parameters, and secure your workpiece within the 200 mm chuck. Always use proper safety gear during operation.

Q: What types of materials can be processed on this lathe?

A: The XYZ England 1340 Lathe is designed to handle a wide range of workpiece materials, including most metals and alloys, thanks to its heavy-duty cast iron construction and powerful 2 HP motor.

Q: When should I use the coolant pump included with the machine?

A: The coolant pump should be used during prolonged cutting sessions or when working with harder materials to maintain tool performance, improve surface finish, and prolong the lifespan of both tool and workpiece.

Q: Where is this lathe most commonly used?

A: This model is widely used in manufacturing facilities, engineering workshops, and educational institutions throughout the United Kingdom and abroad, serving exporters, importers, suppliers, and manufacturers alike.

Q: What is the process for changing spindle speeds on this lathe?

A: Changing spindle speeds involves manually adjusting the geared headstock mechanism. Follow the manufacturers guidelines for safe shifting between the 8 available speeds, making sure the motor is stopped before making changes.

Q: Can this lathe achieve high-precision surface finishes?

A: Yes, the XYZ England 1340 Lathe can achieve surface finishes up to 2 microns, given the proper selection of cutting tools, speeds, and feed rates.

Q: What are the main benefits of choosing a conventional, manual lathe like this model?

A: A conventional manual lathe provides direct operator control, versatility across different job types, lower maintenance requirements, and is ideal for both simple and precise workpieces without the need for CNC programming skills.
