TOS SUI-40A 1500 Lathe Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS SUI-40A 1500 Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
High-grade Cast Iron

Cutting Thickness
Depends on Tool and Material

Cutting Speed
8-1800 RPM

CNC Or Not
Conventional (Not CNC)

Automatic Grade
Manual

Control System
Manual Control

Max. Swing Diameter
400 mm

Voltage
415 V

Weight (kg)
2500 kg

Dimension (L*W*H)
3070 x 1150 x 1410 mm

Capacity
Precision Turning

Feature
Hardened & Ground Bed, Precision Gears

Color
Standard Industrial Grey & Green

Number of Spindle Speeds
18

Tailstock Quill Travel
200 mm

Spindle Bore
52 mm

Distance Between Centers
1500 mm

Spindle Motor Power
5.5 kW

Tailstock Quill Diameter
65 mm

Bed Width
350 mm

Metric Thread Range
0.5 - 112 mm

Lead Screw Diameter
35 mm

Inch Thread Range
56 - 0.25 TPI

TOS SUI-40A 1500 Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS SUI-40A 1500 Lathe Machine

Make - TOS Trencin (Slovakia)

Model - SUI 40A

Center Height - 210 mm

Length of Job - 1500 mm

Max. Diameter of Job over Bed - 420 mm

Max. Diameter of Job over Cross-Slide - 220 mm

Bed Width - 360 mm

Chuck Diameter - 250 mm

Spindle Speeds - 11.2 rpm to 2240 rpm

Spindle Bore - 57.5 mm

Max. Diameter of Job Near Chuck - 470 mm

- Equipped with Automatic Taper Turning Attachment.

- Feature of Motorised Rapid Travels of the Carriage & Cross-Slide.

- Complete with Job Steady, & other accessories.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/fNz09L6fAsY

Engineered for Precision Work

The TOS SUI-40A 1500 Lathe Machine stands out with its rigorously constructed hardened and ground bed, ensuring longevity and high accuracy during operation. Its substantial lead screw diameter and precision gears enable consistent thread cutting within both metric and inch ranges, making it suitable for a variety of workpieces. This reliability is especially valued by manufacturers requiring repeatable, high-quality outputs across a range of production environments.

Adaptable to Diverse Turning Needs

With a swing diameter of 400 mm and a 1500 mm center distance, the machine accommodates sizable workpieces with ease. Its versatility is enhanced through 18 spindle speeds (8-1800 RPM) and a 5.5 kW motor, allowing users to set cutting parameters that match the specific material and tooling requirements. This adaptability is particularly beneficial for jobs ranging from roughing to fine detail turning in workshops and factories.

FAQ's of TOS SUI-40A 1500 Lathe Machine:

Q: How does the manual control system of the TOS SUI-40A benefit machining operations?

A: The manual control system gives operators direct command over each turning process, allowing for real-time adjustments and meticulous oversight. This approach is ideal for jobs requiring a high degree of customization and craftsmanship, particularly when handling unique or complex parts that demand precision.

Q: What materials can the TOS SUI-40A 1500 Lathe Machine handle effectively?

A: Thanks to its high-grade cast iron construction and robust design, the TOS SUI-40A can process a wide array of metals, including steel, aluminum, and brass. The specific cutting thickness will depend on both the selected tooling and the material being machined.

Q: When is it advisable to use the full 18 spindle speeds?

A: Utilizing the full range of 18 spindle speeds (8-1800 RPM) is advisable when working with different materials and varying cutting operations. Higher speeds are effective for light finishing on softer metals, while lower speeds are essential when roughing out harder materials or large workpieces to prevent tool wear and overheating.

Q: Where can the TOS SUI-40A lathe be installed and operated?

A: Because of its size (3070 x 1150 x 1410 mm) and weight (2500 kg), the SUI-40A requires a stable, reinforced flooring-usually in professional workshops, manufacturing plants, or educational training centers. Proper power supply (415 V) and adequate operational space should also be ensured.

Q: What is the process for changing from metric to inch thread cutting on this lathe?

A: Changing between metric (0.5-112 mm) and inch threads (56-0.25 TPI) involves adjusting the gear settings on the lead screw drive. This process is manual and outlined in the machine's operating manual, ensuring accurate thread selection for any project.

Q: How does the design improve usability and durability?

A: The machine features a hardened and ground bed for wear resistance and precision gears that ensure smooth power transfer. Its cast iron base minimizes vibrations, enhancing both user comfort and the long-term accuracy of machined parts.

Q: What primary benefits does the TOS SUI-40A offer to users?

A: Users benefit from the machine's exceptional durability, flexibility in handling various workpiece sizes, and the capacity for precise, repeatable turning tasks. As a manual lathe, it offers great appeal for skilled machinists who value hands-on control and adaptability for custom or batch production.
