Lorenz SV-00 Gear Shaper Machine
Lorenz SV-00 Gear Shaper Machine

Lorenz SV-00 Gear Shaper Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Lorenz SV-00 Gear Shaper Machine Specification

  • Voltage
  • 415 V, 3 Phase
  • Capacity
  • Maximum gear diameter up to 320 mm
  • Output
  • High precision gear profiles
  • Weight
  • Approx. 1500 kg
  • Power
  • Approx. 3 HP
  • Used For
  • Precision gear shaping and cutting
  • Machine Type
  • Gear Shaper Machine
  • Condition
  • Used
  • Dimension (L*W*H)
  • 1700 mm x 1500 mm x 2000 mm (approx.)
  • Color
  • Grey
  • Feature
  • Manual operation, robust construction, compact design
  • Control Type
  • Conventional
  • Electricals
  • Standard industrial wiring
  • Shank Type
  • Stub & Standard
  • Spindle Speed
  • Variable speed, manual control
  • Noise Level
  • Moderate
  • Max Workpiece Height
  • 100 mm
  • Maximum Module
  • Up to 6 module
  • Stroke Length
  • Up to 70 mm
  • Shaper Cutter Diameter Range
  • Up to 100 mm
  • Model
  • SV-00
  • Coolant System
  • Integrated, manual
  • Table Diameter
  • Approx. 400 mm
  • Clamping Type
  • Manual, mechanical vice
  • Number of Feeds
  • Manual multi-feed capability


Lorenz SV-00 Gear Shaper Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Lorenz SV-00 Gear Shaper Machine

Make - Lorenz (Germany)

Model - SV-00

Max. Gear Diameter - 180 mm

Max. Module Capacity - 4 Modules

Max. Stroke Length - 55 mm

Spindle Diameter - 85 mm

Spindle Type - Hollow

Height between Table to Spindle Body - 140 mm

- Complete with Change Gears.

- Machine is in excellent working condition.


Video of the Machine -

https://youtu.be/e0RZsRh-oc0



Precision and Versatility

The Lorenz SV-00 excels in precision gear shaping, offering a compact design that accommodates a range of modules up to 6, and gear diameters up to 320 mm. Suitable for both stub and standard shank cutters, this versatile machine allows manufacturers to produce high-quality gears for various applications with ease.


Robust German Engineering

Crafted in Germany, the SV-00 Gear Shaper boasts robust construction for long-term industrial use. Its mechanical vice clamping, integrated manual coolant system, and sturdy build ensure consistent performance and durability in demanding environments, making it a dependable choice for gear fabrication units.


User-Friendly Operation

With manual controls for spindle speed, feed, and clamping, the Lorenz SV-00 offers straightforward, reliable operation for skilled machinists. The multi-feed capability and adjustable stroke length provide flexibility, while the compact design ensures efficient use of workshop space.

FAQ's of Lorenz SV-00 Gear Shaper Machine:


Q: How does the manual control system on the Lorenz SV-00 work during gear shaping?

A: The SV-00 features a conventional manual control system, allowing operators to adjust the spindle speed and feeds according to the specific requirements of each gear shaping operation. This setup provides optimal flexibility for producing complex and precise gear profiles.

Q: What types of gears can be produced with the Lorenz SV-00 Gear Shaper?

A: This machine is capable of producing a variety of precision gear profiles up to a maximum module of 6, with workpieces of up to 320 mm in diameter. Its versatility supports both stub and standard shank types, making it suitable for a wide range of gear-shaping applications.

Q: When should the integrated manual coolant system be used?

A: The integrated manual coolant system should be activated during gear shaping processes that generate significant heat, such as continuous cutting of large modules or extended production runs. Proper cooling helps prolong tool life and ensures dimensional accuracy in the finished gears.

Q: Where can the Lorenz SV-00 Gear Shaper be effectively utilized?

A: This gear shaping machine is ideal for use in precision manufacturing facilities, tool rooms, and gear production workshops. Its compact footprint and robust features make it suitable for exporters, importers, manufacturers, suppliers, and traders with limited space yet high demands for quality gears.

Q: What is the typical process for clamping a workpiece on this gear shaper?

A: A workpiece is secured using the machine's manual, mechanical vice. The operator places the workpiece on the table and tightens the vice to hold it firmly, ensuring stability during shaping and minimizing the risk of inaccuracies caused by vibrations or movement.

Q: How does the Lorenz SV-00 benefit manufacturers aiming for high-precision gear profiles?

A: Thanks to its rigid construction, multi-feed capability, adjustable stroke length, and precision controls, the SV-00 produces gears with high accuracy and consistency. This enables manufacturers to meet stringent quality standards and improve productivity in precision engineering environments.
