Myford MG-12 Precision Cylindrical Grinder

Name: Myford MG-12 Precision Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 12400 INR
Availability: InStock

Price 12400 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Myford MG-12 Precision Cylindrical Grinder Specification

Product Type
Precision Cylindrical Grinder

General Use
External and Internal Cylindrical Grinding

Material
Cast Iron, High-Grade Steel Components

Type
Manual

Capacity
Up to 12 (305 mm) between centers

Weight (kg)
Approx. 1000 kg

Computerized
No

Automatic
No

Control System
Manual Handwheel Controls

Drive Type
Belt and Gear Drive

Grinding Diameter
Max 3 (76 mm)

Grinding Length
Max 12 (305 mm)

Spindle Speed
Up to 2500 RPM

Grinding Wheel Size
12 x 1 x 5 (305 x 25 x 127 mm)

Voltage
415V, 3 Phase

Dimension (L*W*H)
Approx. 1700 x 1250 x 1400 mm

Feature
High Precision, Robust Construction, Adjustable Workhead

Color
Grey / Blue

Surface Finish Achievable
Up to 0.5 micron Ra

Chuck Type
3-Jaw Chuck

Lubrication
Centralized

Coolant System
Integrated

Table Travel
305 mm

Workhead Spindle Taper
Morse Taper #2

Maximum Workpiece Swing
Approx. 200 mm

Tailstock
Standard Provided

Wheelhead Motor Power
1.5 HP (1.1 kW)

Wheel Dressing Attachment
Fitted

Myford MG-12 Precision Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Myford MG-12 Precision Cylindrical Grinder

Make - Myford (England)

Model - MG-12 HP

Center Height - 65 mm

Max. Job Diameter - 125 mm

Max. Length of Job - 305 mm

Grinding Wheel Size - Diameter 305 mm x 40 mm Width

Work-Head Speeds - 100 rpm to 900 rpm (Infinitely variable)

Least Count - 1 Micron (0.001 mm)

Table Rotation - +10 degree to -10 degree

- Features like Auto-Cut, Delay, Plunge Grinding etc.

- Features like Super-Finishing and Automatic Wheel Retracting.

- With many different types of Wheel-Dressers and lots of other Accessories.

- Operating Manual and Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/jJbKGcBKkvw

Unmatched Precision and Construction

The MG-12 offers exceptional build quality with cast iron and high-grade steel components, ensuring dimensional accuracy and durability. Its stable bed structure and robust manual controls allow for precise adjustments and repeatable results on challenging materials.

User-Friendly Manual Operation

With intuitive handwheel controls, the MG-12 is designed for straightforward manual operation. Operators can easily adjust grinding parameters, set up workpieces between centers, and manage the wheelheads movements to achieve specific toleranceseven without computerized systems.

Versatile Applications and Performance

This grinder is well-suited for external and internal cylindrical grinding, handling workpieces up to 305 mm in length and 76 mm in diameter. The adjustable workhead and tailstock provide flexibility, making it ideal for both single-piece and small batch production in workshops and factories.

FAQs of Myford MG-12 Precision Cylindrical Grinder:

Q: How does the Myford MG-12 achieve such high surface finish accuracy?

A: The MG-12 achieves surface finishes up to 0.5 micron Ra by utilizing a stable cast iron construction, precise spindle system, and a wheel dressing attachment. The integrated coolant system further supports fine polishing by reducing heat and providing consistent lubrication during grinding.

Q: What materials can I grind with the MG-12 cylindrical grinder?

A: The MG-12 is suitable for grinding a variety of materials, including cast iron and high-grade steel. Its robust build and adjustable settings make it versatile for precision grinding of both soft and hard metals.

Q: When should I use the wheel dressing attachment?

A: The wheel dressing attachment should be used whenever you notice a decline in grinding accuracy or finish quality, or prior to starting a new job that requires a different wheel profile. Regular dressing ensures optimal wheel performance and prolongs its life.

Q: Where is the MG-12 typically used?

A: This grinder is commonly used in precision engineering workshops, manufacturing facilities, and tool rooms across the United Kingdom and beyond. Its valued by exporters, importers, manufacturers, suppliers, and traders for its reliability and versatility.

Q: What is the process for setting up a workpiece on the MG-12?

A: To set up a workpiece, secure it using the 3-jaw chuck and support the opposite end with the standard tailstock. Adjust the workhead to align the piece, then use the manual handwheels to position and operate the grinding wheel as required.

Q: What are the benefits of the MG-12s centralized lubrication system?

A: The centralized lubrication ensures all vital moving parts are consistently lubricated, reducing wear, minimizing maintenance, and enhancing the grinders overall operational life.
