Pfauter P400 Hydraulic Gear Hobbing Machine

Name: Pfauter P400 Hydraulic Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Pfauter P400 Hydraulic Gear Hobbing Machine Specification

Weight
Approx. 5 Tons

Condition
Used

Voltage
380 V

Feature
High Productivity, Hydraulic Controlled, Robust Construction

Color
Green

Output
High Accuracy Gear Hobbing

Capacity
Max Gear Diameter 400 mm

Dimension (L*W*H)
3200 mm x 1600 mm x 2150 mm

Power
12 kW

Machine Type
Hydraulic Gear Hobbing Machine

Used For
Precision Gear Cutting

Application
Automotive, Machinery, Industrial Gears

Main Motor Power
Up to 12 kW

Hob Slide Stroke
220 mm

Number of Feeds
Variable

Country of Export
Available for Export Worldwide

Maintenance
Low Maintenance Required

Spindle Speed Range
40 350 rpm

Table Diameter
325 mm

Max Gear Width
450 mm

Control
Hydraulic with Manual Controls

Automation Grade
Semi-Automatic

Coolant System
Equipped

Max Module
8

Min Module
1

Pfauter P400 Hydraulic Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Pfauter P400 Hydraulic Gear Hobbing Machine

Make - Pfauter (Germany)

Model - P400

Max. Module - 8 Modules

Max. Gear Diameter - 400 mm

Max. Vertical Travel of Hob Slide - 310 mm

Minimum Number of Teeth - 6

Max. Hob Cutter Diameter - 160 mm

Table Diameter - 410 mm

Max. Hob Cutter Shifting - 120 mm

Hob Cutter Speeds - 80 rpm to 500 rpm

Serial Number - 20678

- High Production Hydraulic Machine with Auto-Cycle Working.

- Change Gears available and equipped with Chip Conveyor.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/lrswcvsR7o8

Precision Gear Cutting for Industrial Applications

The Pfauter P400 Hydraulic Gear Hobbing Machine is built to meet demanding gear production needs across automotive, machinery, and industrial sectors. Its hydraulic controls, variable feeds, and high output accuracy ensure consistent results for gears ranging from module 1 to module 8, with a width capacity up to 450 mm.

Robust Construction and Worldwide Support

Manufactured in Germany, this machine features a sturdy green design that supports long-term use while minimizing maintenance. As an exporter, importer, manufacturer, supplier, and trader, the Pfauter P400 is available globally for businesses seeking reliable gear hobbing solutions.

FAQs of Pfauter P400 Hydraulic Gear Hobbing Machine:

Q: How does the Pfauter P400 Hydraulic Gear Hobbing Machine operate?

A: The Pfauter P400 functions using hydraulic controls combined with manual adjustments, offering semi-automatic operation. Its hob slide stroke of 220 mm and variable feeds allow precise control over gear cutting, while the integrated coolant system maintains tool longevity and quality.

Q: What industries can benefit from using this gear hobbing machine?

A: Industries such as automotive, general machinery, and manufacturers of industrial gears utilize the Pfauter P400 due to its high accuracy, robust construction, and adaptability to different gear sizes, making it suitable for high-volume production environments.

Q: When is the ideal time to consider upgrading to the Pfauter P400 machine?

A: Businesses experiencing increased demand for precise gear production, or those seeking equipment with enhanced productivity and low maintenance, should consider upgrading to the Pfauter P400. Its ability to handle modules from 1 to 8 and gear widths up to 450 mm make it versatile for evolving needs.

Q: Where can the Pfauter P400 Hydraulic Gear Hobbing Machine be exported?

A: The machine is available for export worldwide. It is supplied by manufacturers, exporters, importers, and traders, with options to ship internationally from Germany, ensuring broad accessibility across markets.

Q: What is the process for achieving high accuracy gear hobbing with this machine?

A: High accuracy is achieved through hydraulic control, precise spindle speed adjustment between 40350 rpm, and a stable table diameter of 325 mm. The combination of these features enables accurate and repeatable gear cutting for a range of module sizes and gear diameters.

Q: How does the coolant system contribute to production efficiency?

A: The equipped coolant system efficiently dissipates heat generated during operation, reducing wear on the hob and maintaining consistent cutting quality. This contributes to lower maintenance requirements and uninterrupted production cycles.

Q: What are the key benefits of choosing the Pfauter P400 for gear manufacturing?

A: Key benefits include high productivity, robust construction, hydraulic control for precise operation, variable speed and feed settings, low maintenance, and worldwide availability. Its versatility enables manufacturers to meet diverse gear requirements efficiently.
