Precis France Pillar Drilling Machine

Name: Precis France Pillar Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Precis France Pillar Drilling Machine Specification

Condition
New

Diameter
25 mm Max

Noise Level
Low

Dimension (L*W*H)
700 x 400 x 1700 mm

Frequency
50 Hz

Machine Type
Pillar Type

Table Size
250 x 250 mm

Motor Power
1.5 HP

Spindle Speed
90-2200 RPM

Features
Precision components, adjustable speed, robust construction

Cutting Area
250 mm

Product Type
Pillar Drilling Machine

Material
Cast Iron

Computerized
No

Automatic Grade
Manual

CNC Or Not
Not CNC

Control System
Mechanical

Voltage
415 V

Power
1.5 HP

Power Source
Electric

Weight (kg)
130 kg

Capacity
25 mm Drilling

Color
Green

Usage & Applications
Drilling, tapping, reaming in metal and wood

Drill Chuck
1 - 16 mm

Made In
France

Safety Features
Overload protection, emergency stop

Max Distance Spindle to Table
650 mm

Spindle Travel
120 mm

Driven Type
V-Belt Drive

Max Distance Spindle to Base
1200 mm

Drilling Precision
±0.05 mm

Base Size
500 x 350 mm

Cooling System
No (manual cooling recommended)

Column Diameter
80 mm

Quill Diameter
45 mm

Number of Speeds
8

Precis France Pillar Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Precis France Pillar Drilling Machine About

Make - Precis (France)

Capacity - 15 mm

Spindle Diameter - 56 mm

Spindle Speeds - 300 rpm to 5000 rpm

Spindle Travel - 105 mm

Table Size - 325 mm x 350 mm

Spindle Taper - MT 1

Max. Height between Top of Table to Spindle - 555 mm

Vertical Pillar Diameter - 120 mm

Motor Power - 0.55 kW

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/wejvFyOs8ko

Engineered for Precision and Durability

Manufactured in France, the Precis Pillar Drilling Machine features a sturdy cast iron structure, precision components, and adjustable speed ranges to handle demanding drilling requirements. Its robust construction ensures stability while minimizing operational noise and vibration, supporting long-term accuracy for industrial tasks.

Safety and User-Focused Features

The machine is equipped with essential safety elements such as overload protection and an emergency stop, ensuring operators can work with confidence. Although not automatic or CNC-controlled, its manual operation offers users detailed control over processes, making it suitable for both skilled tradespeople and manufacturing professionals.

Versatile Applications in Metal and Woodworking

Suitable for drilling, tapping, and reaming, the Precis Pillar Drilling Machine accommodates a wide range of project sizes and materials. With a drilling capacity of up to 25 mm and flexible table or base positioning, the tool supports various applications, from light manufacturing to advanced workshop use.

FAQ's of Precis France Pillar Drilling Machine:

Q: How does the Precis Pillar Drilling Machine ensure drilling accuracy?

A: The machine features a precision spindle with 0.05 mm drilling accuracy and adjustable speeds across 8 ranges, maintaining consistent results in both metal and wood drilling projects.

Q: What safety features are included to protect the operator during use?

A: Operator safety is prioritized with integrated overload protection and a prominent emergency stop button, providing immediate shutdown in case of any risk or malfunction.

Q: Where is this pillar drilling machine manufactured?

A: This model is manufactured in France, guaranteeing European standards for quality, robustness, and performance.

Q: What is the recommended cooling process for this machine?

A: Though the machine does not have a built-in cooling system, manual cooling methods, such as applying cutting fluids or air, are advised to prevent overheating during extended use.

Q: When should the V-belt be adjusted or replaced?

A: The V-belt should be inspected regularly for wear, slippage, or cracks and should be tightened or replaced whenever performance diminishes or unusual noises occur during operation.

Q: What types of materials can this machine process?

A: Designed for versatility, the machine efficiently drills, taps, and reams both metallic and wooden materials, with a robust spindle and adjustable chuck accommodating various tool sizes.

Q: What are the main benefits for industrial users or traders using this model?

A: Industrial users benefit from its reliable manual controls, high precision, substantial drilling capacity, and durable build-making it ideal for consistent use in workshops, factories, and trade environments.
