Ramira 320 mm Vertical Slotting Machine

Name: Ramira 320 mm Vertical Slotting Machine
Brand: Liberty Metal & Machines Private Limited
Price: 40000 INR
Availability: InStock

Price 40000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ramira 320 mm Vertical Slotting Machine Specification

Lubricating System
Centralized manual lubrication

Production Capacity
NA (operation-dependent)

Machine Type
Vertical Slotting Machine

Features
Robust construction, smooth operation, easy maintenance

Control System
Manual/Handle Lever

Motor Power
3 HP

Frame Type
Heavy Duty Cast Iron

Power Rating
3 HP

Operating Temperature
5C to 50C

Accuracy
0.05 mm

Drive
V-Belt Drive

Voltage
415V

Noise Level
<80 dB

Model No
Ramira 320 mm

Cooling System
Manual coolant tray

Frequency
50 Hz

Product Type
Vertical Slotting Machine

Technology
Conventional Mechanical

Power Source
Electric

Operating Type
Semi-Automatic

Power
2.2 kW (approx)

Pressure
Manual (Not applicable for slotting machine)

Surface Treatment
Painted / Coated

Dimension (L*W*H)
Approx. 1500 x 900 x 2000 mm

Weight (kg)
1600 kg (approx)

Color
Green

Usage & Applications
Slotting and keyway operations on metal, tools, dies

Longitudinal Table Traverse
400 mm

Table Diameter
500 mm

Table Rotation
360

Maximum Workpiece Height
400 mm

Electrical Protection
Overload and short-circuit protection

Max Distance Table to RAM
500 mm

Number of Feeds
4 (Stepwise)

Main Spindle Speed
Multiple (Depends on pulley settings)

Vertical Traverse of RAM
450 mm

Cross Table Traverse
300 mm

Foundation Required
Yes

Max Slotting Stroke
320 mm

WorkingSpeed
Variable (Step pulley system, approx 1575 strokes/min)

Surface Finish
Fine (Ra 3.2m to 6.3m)

Ramira 320 mm Vertical Slotting Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ramira 320 mm Vertical Slotting Machine

Make - Ramira (Romania)

Model - M 320

Max. Stroke Length - 320 mm

Table Diameter - 630 mm

Stroke Rates - 20 strokes/min to 80 strokes/min

Cross Travel of Table - 560 mm

Longitudinal Travel of Table - 630 mm

Distance between Table Top to Machine Body (Height) - 510 mm

Angle for Taper Slotting - 0 degree to 10 degree

- Automatic Feed Travel on Cross, Longitudinal & Rotation of Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/TA-XSCenlmg

Precise and Versatile Machining

Designed for accuracy up to 0.05 mm, the Ramira 320 mm Vertical Slotting Machine delivers consistent, high-quality slotting and keyway shaping. Its large vertical and horizontal travel capabilities enable operators to handle larger, complex workpieces, maximizing versatility for a range of industrial applications.

Sturdy Construction and User Safety

Manufactured from heavy-duty cast iron, this machine stands out for its durability and stability. Featuring a V-belt drive, overload and short-circuit electrical protection, and centralized manual lubrication, it prioritizes both operator safety and equipment longevity, reducing maintenance requirements.

Adaptable for Industrial Needs

With four stepwise feeds, variable stroke speeds (approx. 1575 strokes/min), and full 360 table rotation, the Ramira Slotting Machine adapts seamlessly to various workpiece geometries. Its manual coolant tray ensures optimal cooling, while the painted surface helps protect against corrosion.

FAQs of Ramira 320 mm Vertical Slotting Machine:

Q: How does the Ramira 320 mm Slotting Machine control the feed and speed during operation?

A: Feed is managed in four distinct steps, selectable by the user, while working speed is adjusted using a step pulley system, offering approximately 15 to 75 strokes per minute for adaptable machining performance.

Q: What are the main benefits of using this slotting machine for my workshop?

A: The Ramira 320 mm offers precision slotting up to 0.05 mm, handles large and varied workpieces, and features robust construction for reliable, long-term use. Its ease of maintenance, integrated safety features, and simple manual controls further enhance productivity.

Q: Where should the Ramira 320 mm Slotting Machine be installed?

A: For stability and vibration absorption, its essential to install the machine on a proper foundation in a well-ventilated, industrial workspace with adequate electrical supply (415V, 50 Hz). Ensure sufficient floor space for the machines dimensions and safe operational clearance.

Q: What types of workpieces or applications is this slotting machine suitable for?

A: This machine is ideal for slotting and keyway operations on metals, machine components, tools, and dies. Industries involved in fabrication, tool making, or repair and maintenance will benefit from its versatility and precision.

Q: How is maintenance performed on the Ramira 320 mm Machine?

A: Regular maintenance involves monitoring the centralized manual lubrication system, ensuring coolant levels in the manual tray, checking for electrical safety, and cleaning the painted surfaces. The heavy-duty design simplifies long-term upkeep.

Q: When should the overload protection system be checked?

A: The overload and short-circuit protection systems should be inspected during each routine maintenance cycle, or immediately if an unexpected power interruption or machine halting occurs, to uphold optimal safety.

Q: What accuracy and finish can I expect from this machine?

A: You can achieve slotting accuracy within 0.05 mm, and fine surface finishes ranging from Ra 3.2m to 6.3m, meeting stringent industrial standards and quality requirements.
