TOS HOV-45 Heavy Duty Slotting Machine

Name: TOS HOV-45 Heavy Duty Slotting Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS HOV-45 Heavy Duty Slotting Machine Specification

Power Rating
3 HP

Machine Type
Slotting

Plastic Processed
Not applicable; for metals

Connectivity Options
Direct electric

Features
Heavy cast iron construction, robust slider, adjustable stroke, precision table rotation

Model No
HOV-45

Control System
Manual lever with mechanical feed

Motor Power
3 HP

Voltage
415 V

Lubricating System
Centralized oil lubrication system

Frequency
50 Hz

Cooling System
Coolant pump provided

Drive
Mechanical drive with V-belt

Production Capacity
4-8 units/hour

Operating Temperature
545C

Accuracy
0.05 mm

Noise Level
Moderate (<80 dB)

Frame Type
Rigid column with bed frame

Product Type
Heavy Duty Slotting Machine

Technology
Conventional Mechanical

Power Source
Electric

Operating Type
Semi-Automatic

Power
3 HP

Pressure
Manual/Mechanical Drive (No hydraulic pressure)

Surface Treatment
Painted/Coated

Dimension (L*W*H)
Approx. 2100 x 1500 x 2350 mm

Weight (kg)
Approx. 1800 kg

Color
Industrial Green

Usage & Applications
Slotting/internal cutting of metals and components

Table Cross Travel (X axis)
500 mm

Maximum Table Diameter
560 mm

Clamping Device
Provided

Number of Ram Strokes per Minute
32, 45, 63 (three-speed)

Maximum Workpiece Weight
700 kg

Maximum Slotting Stroke
450 mm

Main Motor RPM
1440 rpm

Foundation Required
Yes

Safety Features
Overload protection, electrical safety interlock

Coolant Tank Capacity
40 litres

Maximum Height from Table to Ram
710 mm

Standard Accessories
Coolant system, electrical panel, tool kit, instruction manual

Table Longitudinal Travel (Y axis)
400 mm

Table Rotation
360 manual

WorkingSpeed
Variable; Main ram: 32/38/50 strokes per minute

Phase
Three Phase

TOS HOV-45 Heavy Duty Slotting Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS HOV-45 Heavy Duty Slotting Machine

Make - TOS (Czech Republic)

Model - HOV-45

Max. Stroke Length - 450 mm

Table Diameter - 900 mm

Longitudinal Travel - 800 mm

Cross Travel - 700 mm

Height between Table to Machine Body - 640 mm

Distance between Toolhead edge to Column - 1000 mm

Max. Distance between Table Center to Column - 1430 mm

Stroke Rate - 10 strokes/min to 56 strokes/min

Feed Travel Rate - 0.1 mm/stroke to 2.0 mm/stroke

Head Rotation - +10 degree to -10 degree

- Feed & Rapid Travel on Table Rotation and on Cross & Longitudinal Travels.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/IuK75N0mAdE

Versatile Heavy-Duty Slotter

The HOV-45 slotting machine offers a powerful solution for precise internal cutting, groove creation, and keyway shaping in metals. Its adaptable table and variable ram speeds help users achieve efficient production rates of 4-8 components per hour. The designs flexibility allows easy operation for various component sizes up to a maximum weight of 700 kg.

Reliable and Safe Operation

This slotting machine comes equipped with essential safety features such as overload protection and an electrical safety interlock. The centralized oil lubrication and coolant system ensure smooth and continuous operation, even during extended shifts. Manual lever controls and mechanical feeds provide intuitive handling for semi-automatic tasks.

Built for Industrial Performance

Engineered with a rigid cast iron structure and robust slider, the HOV-45 stands up to demanding use. The machines adjustable stroke, precise table rotation, and mechanical drive system facilitate high accuracy while minimizing maintenance. Foundation installation is recommended for optimal stability and long-term durability.

FAQs of TOS HOV-45 Heavy Duty Slotting Machine:

Q: How is the TOS HOV-45 slotting machine operated?

A: The TOS HOV-45 is operated using a manual lever with a mechanical feed system. It features semi-automatic operations where the user controls settings, positioning, and initiates cutting cycles. Speed and table rotation are adjustable for various machining requirements.

Q: What safety features are included with this slotting machine?

A: The machine is equipped with overload protection and an electrical safety interlock system to prevent accidents. These features help safeguard operators and equipment during intensive metal slotting and cutting operations.

Q: When should I use the HOV-45 slotter for my workshop?

A: The HOV-45 is ideal when you need to perform precision internal cutting, grooving, or keyway operations on metal components weighing up to 700 kg. It is particularly beneficial for workshops handling medium to large parts requiring accurate slotting at variable production volumes.

Q: Where should the slotting machine be installed for optimal performance?

A: For best results, the machine should be installed on a solid foundation within an industrial workshop setting. This provides necessary stability and minimizes vibration, ensuring precise machining and operator safety.

Q: What is the process for adjusting the slotting stroke and table movement?

A: The slotting stroke is adjustable via the control levers on the machine, with stroke lengths up to 450 mm. The rotary table can be manually rotated 360 and offers cross and longitudinal travel, making it suitable for a wide range of component sizes and shapes.

Q: What are the key benefits of using the HOV-45 slotting machine?

A: Key benefits include high mechanical precision (0.05 mm), the capacity to handle heavy workpieces, flexible speed and stroke adjustments, a robust structure ensuring durability, and built-in lubrication and cooling systems that increase machine lifespan and performance.
