TOS HOV40 Heavy Duty Slotting Machine

Name: TOS HOV40 Heavy Duty Slotting Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS HOV40 Heavy Duty Slotting Machine Specification

Operating Temperature
Ambient (5°C to 45°C)

Motor Power
7.5 HP

Noise Level
Low

Power Rating
7.5 HP

Features
Heavy Duty Frame, Robust Structure, Adjustable Stroke

Cooling System
Integrated Coolant Pump

Drive
Gear Driven

Model No
HOV40

Control System
Manual Lever & Rotary Switch

Voltage
415 V

Lubricating System
Automatic Lubrication

Accuracy
High Precision Slots

Production Capacity
High

Machine Type
Slotting

Frequency
50 Hz

Frame Type
Heavy Cast Iron

Product Type
Heavy Duty Slotting Machine

Technology
Conventional Mechanical

Power Source
Electric

Operating Type
Semi-Automatic

Power
7.5 HP

Pressure
Standard

Surface Treatment
Coated/Painted

Dimension (L*W*H)
1800 x 1400 x 2600 mm

Weight (kg)
2500 kg

Color
Machine Grey

Usage & Applications
Metal Slotting, Keyway cutting, Internal Gear Cutting, Shaping Operations

Standard Accessories
Tool Kit, Coolant Pump, Electrical Panel

Maximum Workpiece Table Diameter
600 mm

Packaging
Wooden Crate

Tool Holders
Standard Shank

Finish
Rust Resistant Paint

Feed Type
Automatic & Manual

Operator Safety Features
Mechanical Guards, Emergency Stop Switch

Main Construction Material
High Grade Cast Iron

Electrical Protection
Overload & Short Circuit Protection

Cross Table Travel
330 mm

Table Rotation
360°

Spindle Speed Range
Variable (as per gear change)

Ram Stroke Length
Up to 400 mm

Table Motor Power
1.5 HP

Longitudinal Table Travel
475 mm

Installation Type
Floor Mounted

Maximum Slotting Height
400 mm

TOS HOV40 Heavy Duty Slotting Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS HOV40 Heavy Duty Slotting Machine

Make - TOS (Czech Republic)

Model - HOV40

Max. Stroke Length - 440 mm

Table Diameter - 800 mm

Longitudinal Travel - 850 mm

Cross Travel - 600 mm

Height between Table to Machine Body - 600 mm

Distance between Toolhead edge to Column - 900 mm

Max. Distance between Table Center to Column - 1300 mm

Stroke Rate - 11.2 strokes/min to 71 strokes/min

Feed Travel Rate - 0.2 mm/stroke to 2.0 mm/stroke

Head Rotation - +10 degree to -10 degree

- Feed & Rapid Travel on Table Rotation and on Cross & Longitudinal Travels.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/gTldV-XZ2GI

Precision and Durability

Built from high-grade cast iron and finished with rust-resistant paint, the HOV40 offers exceptional durability and stability. Its heavy-duty frame minimizes vibrations, ensuring high-precision slots every cycle even during extended use.

Easy Operation and Versatility

Users benefit from both manual lever and rotary switch controls, as well as variable spindle speeds for adapting to different tasks. The 360 rotating table and adjustable ram stroke empower operators to handle a variety of workpiece geometries and slotting needs efficiently.

Enhanced Safety and Reliability

Multiple safety features, including overload and short circuit protection, mechanical guards, and an emergency stop switch, provide peace of mind during operation. The integrated coolant and lubrication systems help maintain optimal machine health and reduce maintenance intervals.

FAQ's of TOS HOV40 Heavy Duty Slotting Machine:

Q: How do I operate the TOS HOV40 Heavy Duty Slotting Machine safely?

A: To operate the TOS HOV40 safely, ensure all mechanical guards are secured before powering up. The machine includes overload and short circuit protection, and an emergency stop switch for immediate shutdown. Always use proper personal protective equipment and follow the operating manual for procedures.

Q: What types of operations is the HOV40 Slotting Machine best suited for?

A: The HOV40 is ideal for metal slotting, keyway cutting, internal gear production, and shaping operations. Its high precision and heavy-duty capabilities make it suitable for manufacturing, engineering workshops, and industrial keyway or gear slotting tasks.

Q: Where can the HOV40 Slotting Machine be installed?

A: This floor-mounted slotting machine is designed for use in industrial environments, such as manufacturing plants, tool rooms, and metalworking workshops. Its robust construction and standard electric power supply ensure compatibility with most industrial settings.

Q: When should I utilize the automatic feed over manual feed?

A: Automatic feed is recommended for repetitive or long-duration slotting tasks, as it enhances efficiency and consistency. Manual feed is suitable for intricate or short-run operations where close operator control is required.

Q: What benefits does the integrated coolant and lubrication system provide?

A: The integrated coolant pump and automatic lubrication system reduce heat buildup, minimize tool wear, and support sustained precision during heavy-duty tasks. This leads to longer tool life and reduces maintenance intervals for the machine.

Q: How does the TOS HOV40 achieve high-precision slotting?

A: With a stable cast iron structure, variable spindle speed, and adjustable ram stroke, the machine minimizes deflections and vibrations. Combined with high-quality tooling and fine control, it consistently delivers accurate slots with minimal deviation.

Q: What is the installation and commissioning process for the HOV40?

A: The HOV40 ships in a wooden crate for protection. On delivery, place it on a level floor space, connect the electrical supply (415 V, 50 Hz), and ensure all safety checks are performed. Follow the manufacturer's installation manual and, if required, consult a professional technician for setup and testing.
