Butler 12 inch Precision Toolroom Slotter Machine
Butler 12 inch Precision Toolroom Slotter Machine

Butler 12 inch Precision Toolroom Slotter Machine

Price 50000 INR/ Piece

MOQ : 1 Piece

Butler 12 inch Precision Toolroom Slotter Machine Specification

  • Voltage
  • 415V AC
  • Control System
  • Manual
  • Drive
  • Belt-Driven
  • Machine Type
  • Toolroom Slotter
  • Model No
  • Butler 12 Inch
  • Accuracy
  • ±0.02 mm
  • Frequency
  • 50 Hz
  • Motor Power
  • 2 HP
  • Noise Level
  • <75 dB
  • Cooling System
  • External Coolant Provision
  • Production Capacity
  • Depends on Application and Operator
  • Operating Temperature
  • 5°C to 40°C
  • Frame Type
  • Box type, heavy duty
  • Power Rating
  • 1.5 kW
  • Features
  • High precision, robust design, smooth operation
  • Lubricating System
  • Centralized Lubrication
  • Product Type
  • Slotter Machine
  • Technology
  • Conventional Machining
  • Power Source
  • Electric
  • Operating Type
  • Manual
  • Power
  • 2 HP
  • Pressure
  • Not Applicable (Mechanical Operation)
  • Surface Treatment
  • Painted
  • Dimension (L*W*H)
  • Approx. 1600 mm x 750 mm x 1800 mm
  • Weight (kg)
  • Approx. 1000 kg
  • Color
  • Industrial Green / Grey
  • Usage & Applications
  • Precision slotting, keyway cutting, toolroom and general engineering applications
  • Ram Adjustment
  • Up to 305 mm
  • Optional Accessories
  • Digital Readout System, Coolant Pump Kit
  • Maintenance Requirement
  • Low, with centralized lubrication and easy access points
  • Tool Slide Adjustment
  • Yes, Swiveling
  • Setup Time
  • Minimal, quick setup design
  • Main Shaft Speed
  • Variable, 25-120 SPM
  • Standard Accessories
  • Chuck, Clamping Kit, Tool Post, Operating Manual
  • Application Area
  • Die making, Gear manufacturing, Automotive, General Engineering
  • Table Rotation
  • 360°
  • Operator Safety
  • Mechanical guards and overload protection
  • Spindle Travel
  • 305 mm
  • Table Feed
  • Manual and power
  • Maximum Slotting Stroke
  • 12 inch (305 mm)
  • Maximum Table Diameter
  • 500 mm
  • Table Feed Graduation
  • 0.02 mm per division
  • Material of Construction
  • Cast Iron Body
  • Maximum Workpiece Height
  • 450 mm
  • Vibration/Damping
  • Heavy-duty damping provided


Butler 12 inch Precision Toolroom Slotter Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Butler 12 inch Precision Toolroom Slotter Machine

Make - Butler (England)

Model - 12"

Max. Stroke Length - 305 mm

Table Diameter - 610 mm

Stroke Rates - 19 strokes/min to 75 strokes/min

Cross Travel of Table - 600 mm

Longitudinal Travel of Table - 525 mm

Height between Table Top & Machine Body - 385 mm

Distance between Tool & Machine Body - 625 mm

Tilting of Ram - 0 degree to 5 degree

- Automatic Feed Travel on Cross, Longitudinal & Rotation of Table.

- Equipped with 2-Axis DRO.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/vDRMkPYjDig



Engineered for Precision and Reliability

The Butler 12 inch slotter combines advanced mechanical features with a robust, heavy-duty frame to deliver unmatched accuracy and repeatability. Featuring flexible ram and spindle travel adjustment, it is capable of handling a variety of workpieces, making it indispensable for precision slots, keyways, and intricate die components. The cast iron construction and professional-grade damping ensure vibration-free, long-term performance for demanding industrial environments.


Optimized Setup and Maintenance Efficiency

With its quick setup design and centralized lubrication system, the machine minimizes downtime and streamlines changeover processes. Access points are thoughtfully positioned for ease of maintenance, reducing operator effort and extending machine life. The slotter comes standard with accessories such as a chuck, tool post, clamping kit, and an operating manual, while optional upgrades like digital readouts and coolant pump kits further refine precision and workflow.

FAQs of Butler 12 inch Precision Toolroom Slotter Machine:


Q: How does the Butler 12 inch Toolroom Slotter ensure high precision during slotting operations?

A: The machines robust box-type frame, cast iron body, heavy-duty vibration dampening, variable speed control, and a high-accuracy feed graduation (0.02 mm per division) all collaboratively maintain slotting accuracy within 0.02 mm, enabling precise toolroom and keyway cutting applications.

Q: What types of industries and applications can this slotter machine be used for?

A: The Butler 12 inch slotter is suitable for die making, gear manufacturing, automotive component production, and general engineering. Its precision and versatility make it ideal for toolroom tasks, keyway slotting, and intricate cutting requirements across multiple sectors.

Q: When should I consider using the power table feed versus manual feed on this slotter?

A: Manual feed offers maximum control for intricate operations and fine adjustments, while the power table feed is best utilized for repetitive, consistent slotting processes or when working with larger workpieces, improving productivity and uniformity.

Q: Where can I install and safely operate this slotter machine in my workshop?

A: The machine should be placed in a stable, well-ventilated area that can accommodate its dimensions (approx. 1600 mm x 750 mm x 1800 mm) and provide access to a 415V AC power supply. Operator safety is ensured by mechanical guards and overload protectionalways follow the provided operating manual for best safety practices.

Q: What is involved in the process of setting up and maintaining the slotter machine?

A: Setting up involves securing the workpiece with the provided chuck and clamping kit, selecting appropriate speed and feed rates, and adjusting the ram and tool slide. Maintenance is straightforward, thanks to centralized lubrication and accessible service points; regular checks ensure consistent performance and low maintenance requirements.

Q: How does using this machine benefit my precision engineering workflow?

A: By combining high accuracy, quick setup, robust construction, and versatile operation, the Butler 12 inch slotter enhances productivity, reduces errors, and ensures reliable output for precision machining tasks, thereby increasing both efficiency and quality in engineering processes.
