Vertical Turning Lathe Machine

Name: Vertical Turning Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Vertical Turning Lathe Machine Specification

Machine Type
Vertical Turning Lathe Machine

Accuracy
0.01 mm

Voltage
380-415 V AC

Cooling System
Integrated Coolant System

Frequency
50 / 60 Hz

Drive
Belt / Geared drive

Control System
Digital / CNC Panel

Connectivity Options
Ethernet/USB (for CNC variant)

Operating Temperature
5C to 45C

Noise Level
Below 75 dB

Motor Power
7.5 kW / 15 kW

Power Rating
10 HP / 15 HP / 30 HP

Lubricating System
Automated Lubrication

Model No
VTL-1800S

Production Capacity
Heavy-duty Industrial Use

Features
Heavy-duty construction, high rigidity, easy operator interface, precision machining

Frame Type
Cast Iron Body

Product Type
Vertical Turning Lathe Machine

Technology
CNC / Conventional

Power Source
Electric

Operating Type
Semi-Automatic / Automatic

Power
7.5 kW - 22 kW (Depending on configuration)

Pressure
Hydraulic/Manual (as per model)

Surface Treatment
Coated / Painted

Dimension (L*W*H)
Approx. 3500 x 2700 x 4000 mm

Weight (kg)
6500 - 15000 kg (Depending on model)

Color
Green

Usage & Applications
Heavy-duty turning of large, cylindrical workpieces in manufacturing and engineering industries

Max Swing Diameter
Up to 1800 mm

Spindle Bore
160 mm

Bed Type
Mono block rigid bed

Table Load Capacity
4000 12000 kg

Tailstock
Available (as per requirement)

Table Diameter
1250 mm / 1600 mm / 1800 mm

Safety Features
Emergency Stop, Interlock Switch, Overload Protection

Max Turning Height
1000 mm 1400 mm

Tool Post Type
Vertical, Electrically controlled

Rapid Traverse Rate
Up to 6000 mm/min

Chuck Type
Hydraulic / Manual 3 Jaw Chuck

Application Material
Cast Iron, Steel, Alloy steel and non-ferrous metals

Number of Tools
4 8 position turret

Main Spindle Speed Range
5 200 rpm

About Vertical Turning Lathe Machine

Experience the outstanding efficiency of our Best-seller Vertical Turning Lathe Machinespecifically engineered for heavy-duty machining with an astounding max swing diameter of up to 1800 mm. Purchase this sterling equipment at an unbeatable price and gain superior control with CNC or conventional technology. Its mono block rigid bed ensures stability for impressive accuracy (0.01 mm), while the 48 position turret offers greater flexibility. Ideal for turning cast iron, steel, alloy steel, and non-ferrous metals, this machine is an astoundingly reliable choice for large-scale industrial operations.

Versatile Application Across Multiple Industries

The Vertical Turning Lathe Machine is perfectly suitable for manufacturing and engineering sectors requiring precision in handling large, cylindrical workpieces. Excellent for machining cast iron, steel, alloy steel, and non-ferrous metals, its robust configuration supports heavy-duty industrial use. Application areas include automotive, shipbuilding, aerospace, and component fabricationwhere complex and high-strength materials are routinely processed. Its versatile design makes it ideal for diverse operating media, adapting seamlessly to semi-automatic or automatic workflows.

Efficient Export, Logistics & Packing Solution

We charge ahead as a prominent exporter, meeting global supply demand with streamlined logistics. Every Vertical Turning Lathe Machine is carefully packed and dispatched using industry-standard materials to ensure safe delivery. Our supply ability is defined by consistency and reliability, supporting continuous production and timely export to markets across Asia, Europe, Africa, America, and Australia. Packaging details cover robust crates and protective coatings, guaranteeing the integrity during transit and handling at all stages.

FAQs of Vertical Turning Lathe Machine:

Q: How does the Vertical Turning Lathe Machine enhance heavy-duty turning operations?

A: Its high rigidity, mono block cast iron bed, and precision control system provide stable support for machining large workpieces, ensuring accuracy up to 0.01 mm and effortless operation in demanding production environments.

Q: What materials can be processed using this machine?

A: The Vertical Turning Lathe Machine is suitable for cast iron, steel, alloy steel, and non-ferrous metals, making it versatile for various manufacturing requirements.

Q: When is the best time to use hydraulic or manual pressure options?

A: Hydraulic pressure delivers faster setup and higher efficiency for continuous industrial tasks, while manual pressure can be chosen for specific machining needs or where finer manual adjustments are required.

Q: Where is the machine primarily exported and supplied?

A: This machine is exported worldwide, with a strong presence in Asia, Europe, Africa, USA, and Australia, supported by efficient logistics and packing protocols.

Q: What is the process for order placement, packing, and dispatch?

A: Orders are processed through direct inquiry, followed by careful packing in reinforced crates with protective coatings. The logistics team oversees dispatch and delivery, ensuring safe arrival at your facility.

Q: How does the integrated safety system benefit operators?

A: Safety features like emergency stop, interlock switch, and overload protection ensure secure usage, minimizing hazards and promoting a safe work environment.
