Schutte Germany Hydraulic Universal Tool & Cutter Grinder
Schutte Germany Hydraulic Universal Tool & Cutter Grinder

Schutte Germany Hydraulic Universal Tool & Cutter Grinder

Price 100000 INR/ Piece

MOQ : 1 Piece

Schutte Germany Hydraulic Universal Tool & Cutter Grinder Specification

  • Machine Type
  • Hydraulic Universal Tool & Cutter Grinder
  • Operate Method
  • Hydraulic + Manual Controls
  • Cutter Type
  • Manual & Universal Cutter
  • Drill Bits Types
  • Universal Tool & Cutter Grinder
  • Shape
  • Rectangular Base with Vertical Grinder Head
  • Cutting Capacity
  • Up to 250 mm diameter tools
  • Features
  • Hydraulic Table Movement, Universal Head, 3-Jaw Chuck, Multi-Axis Wheelhead
  • Cutting Force
  • Hydraulic Operated (Variable)
  • Operation Type
  • Hydraulic Automatic with Manual Adjustment
  • Coating Type
  • No Coating
  • Cutting Speed
  • Infinitely Variable (Hydraulic)
  • Coating
  • No Coating
  • Hardness
  • Suitable for HSS, Carbide Tools
  • Length
  • 400 mm Max. Work Length
  • Cutting Accuracy
  • High Accuracy within 0.01 mm
  • Tool Type
  • Tool & Cutter Grinder
  • Material
  • Cast Iron, Steel
  • Diameter
  • 250 mm Max. Work Diameter
  • Maximum Torque
  • Dependent on Hydraulic System
  • Processing Type
  • Precision Grinding
  • Accessories Included
  • Centers, Collets, Wheel Flanges, Diamond Dresser
  • Wheel Head Movement
  • Universal Swivelling & Tilting, Multi-Axis
  • Spindle Speed
  • Variable up to 3600 rpm
  • Coolant System
  • Integrated Recirculation Pump
  • Application
  • Grinding, Sharpening and Regrinding Tools/ Cutters for various industries
  • Make & Model
  • Schutte Germany Hydraulic Universal
  • Control Panel
  • Front-mounted ergonomic controls
  • Weight
  • Approx. 1800 kg
  • Power Supply
  • 3-phase, 415 V / 50 Hz
  • Table Travel
  • Up to 500 mm (Longitudinal), 200 mm (Crosswise)


Schutte Germany Hydraulic Universal Tool & Cutter Grinder Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Schutte Germany Hydraulic Universal Tool & Cutter Grinder

Make - Schutte (Germany)

Table Clamping Size - 110 mm x 1030 mm

Max. Swing Diameter on Work-Head - 260 mm

Max. Distance between Centers - 675 mm

Longitudinal Travel - 600 mm

Cross Travel - 255 mm

Vertical Travel - 300 mm

Spindle Speeds - 1325 rpm to 5300 rpm

Max. Grinding Wheel Diameter - 200 mm

Max. Height between Wheel-Center to Table Top - 320 mm

Min. Height between Wheel-Center to Table Top - 20 mm

- Automatic Hydraulic Longitudinal Travels of the Table.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/eVLqqV1VZM4



Versatile Multi-Axis Grinding

This machine's universal swivelling and tilting wheel head allows for multi-axis movements essential in tool grinding and sharpening. Its variable hydraulic cutting force and infinitely adjustable speed enable operators to tackle a wide range of complex geometries and tool materials, maximizing performance and flexibility for modern workshops.


Precision and Durability

With a robust cast iron and steel construction, the Schutte tool & cutter grinder ensures stability and consistent results. Its high accuracy-within 0.01 mm-combined with a variable spindle speed up to 3600 rpm makes it a dependable solution for heavy-duty precision grinding tasks, ensuring longevity and repeatable accuracy for critical tool applications.


Integrated Coolant and Ergonomic Control

An integrated coolant system with recirculation pump keeps tools and grinding surfaces optimally cooled, prolonging tool life and maintaining surface integrity. The front-mounted ergonomic control panel and manual/hydraulic adjustment features streamline operation, making setup and adjustments straightforward for efficient workflow.

FAQ's of Schutte Germany Hydraulic Universal Tool & Cutter Grinder:


Q: How does the universal swivelling and tilting wheel head benefit tool and cutter grinding operations?

A: The universal swivelling and tilting wheel head provides multi-axis movement, allowing the grinder to precisely approach complex tool geometries and cutting profiles. This capability increases flexibility and accuracy during sharpening, making it ideal for industries requiring specialized or custom tool shapes.

Q: What is the maximum size of the tool that can be ground or sharpened on this machine?

A: The Schutte Germany Hydraulic Universal Tool & Cutter Grinder can accommodate tools with diameters up to 250 mm and lengths up to 400 mm. This enables grinding and regrinding of various large or long tools commonly used in industrial environments.

Q: When should the variable spindle speed feature be adjusted, and why?

A: Variable spindle speed-reaching up to 3600 rpm-should be adjusted depending on the type of material (such as HSS or carbide), desired finish, and the geometry of the tool being processed. Controlling the speed helps optimize grinding efficiency, reduce heat buildup, and achieve specific surface finishes.

Q: Where is the control panel located and how does its design improve operator efficiency?

A: The control panel is ergonomically mounted on the front of the machine, which provides straightforward access to hydraulic and manual controls. This design minimizes unnecessary movement and streamlines setup/operation, enhancing user comfort and productivity during extended grinding sessions.

Q: What process steps are involved in sharpening tools using this grinder?

A: Sharpening with this machine involves securely mounting the tool using provided centers or collets, selecting appropriate wheel flanges, adjusting spindle speed and hydraulic table movement, and using the universal head for precise alignment. Integrated coolant ensures temperature control throughout the grinding process.

Q: What are the main benefits of using the Schutte Hydraulic Universal Tool & Cutter Grinder for industrial precision grinding?

A: Benefits include highly accurate grinding within 0.01 mm, versatile handling of both HSS and carbide tools, multi-axis flexibility for complex shapes, efficient cooling for extended tool life, and ergonomic controls for safe, precise operation. Its robust design also ensures reliable, repeatable performance.
