Skoda SR1250 Heavy Duty Lathe Machine

Price 35000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Skoda SR1250 Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 50 mm

Cutting Speed
Variable, up to 1600 RPM

CNC Or Not
Conventional (Not CNC)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
1250 mm

Voltage
415 V, 3 Phase, 50 Hz

Weight (kg)
9000 kg

Dimension (L*W*H)
5200 mm x 1600 mm x 1700 mm

Capacity
Heavy Duty Turning

Feature
High Precision, Robust Construction, Heavy Load Bearing

Color
Industrial Green & Grey

Chuck Size
630 mm

Bed Width
900 mm

Carriage Travel
3800 mm

Distance Between Centers
4000 mm

Surface Finish
Precision Groud Ways

Tailstock Quill Travel
250 mm

Thread Cutting Range
1 to 120 mm

Tailstock Quill Diameter
120 mm

Lubrication System
Automatic Forced Lubrication

Number of Feeds
36

Main Motor Power
15 HP

Coolant System
Integrated

Spindle Bore
105 mm

Lead Screw Diameter
60 mm

Spindle Nose
A2-11

About Skoda SR1250 Heavy Duty Lathe Machine

Skoda (Czech Republic) make Heavy-Duty Lathe Machine in excellent working condition. The model of the machine is SR 1250 and the Max. Length of Job is 9200 mm. The technical details are as follows -

Make - Skoda (Czech Republic)

Model - SR 1250

Center Height - 700 mm

Max. Length of Job - 9200 mm

Max. Job Diameter over Bed - 1400 mm

Max. Job Diameter over Cross-Slide - 950 mm

Chuck Diameter - 1250 mm

Bed Width - 1100 mm

Spindle Speeds - 1.4 rpm to 315 rpm

Weight of the Machine - 25.8 Tons (Approximately)

- Equipped with 2-Axis Digital Read-Out.

- Equipped with 3 x 3-point Steady.

- With Motorized Rapid Travels of Carriage & Tool-Slide.

- Tool-Slide (Top Slide) also has powered Feed Travels.

- Feature of Automatic Taper Turning.

- Machine is in excellent working condition.

Video link - https://youtu.be/u_e40x-iaN4

Precision and Strength for Heavy Duty Applications

With a maximum swing diameter of 1,250 mm and a heavy load-bearing capacity, the Skoda SR1250 lathe is crafted to tackle challenging jobs. The machines robust cast iron construction provides exceptional stability, while its precision-ground ways ensure smooth movement and accurate machining, even during heavy-duty operations.

Integrated Systems for Efficient Operation

This lathe includes automatic forced lubrication and an integrated coolant system to maintain optimum performance during prolonged use. The manual control setup offers flexibility and straightforward operation, making it ideal for professionals who demand hands-on precision and reliable results in every production session.

FAQs of Skoda SR1250 Heavy Duty Lathe Machine:

Q: How does the Skoda SR1250 lathe ensure precision during heavy duty operations?

A: The Skoda SR1250 lathe features precision-ground bed ways and robust cast iron construction, minimizing vibrations and maintaining alignment. Its manual control system allows operators to finely adjust machining parameters, resulting in consistent, high-quality finishes even under heavy loads.

Q: What is the process for thread cutting on the Skoda SR1250 lathe?

A: Thread cutting on this lathe is accomplished using its lead screw (60 mm diameter) and carriage travel up to 3,800 mm, allowing for threads ranging from 1 mm to 120 mm. Operators set the desired thread pitch, engage the feed system (with 36 available feeds), and guide the tool manually along the workpiece for accurate threading.

Q: When should I use the variable cutting speed feature?

A: Variable cutting speeds, ranging up to 1,600 RPM, should be utilized based on the material and depth of cut. Higher speeds suit softer materials and shallow cuts, while lower speeds are ideal for tougher materials or thicker cuts up to 50 mm to prevent tool wear and overheating.

Q: Where can the Skoda SR1250 lathe be installed?

A: Designed for large industrial workshops, manufacturing facilities, and heavy engineering environments, the machine requires ample floor space (dimensions: 5,200 mm x 1,600 mm x 1,700 mm) and a stable 3-phase 415 V power supply for optimal operationsuitable for exporters, importers, and suppliers globally.

Q: What benefits does the automatic lubrication system provide?

A: The automatic forced lubrication system ensures all moving parts receive continuous oil flow, reducing friction, wear, and maintenance downtime. This leads to longer machine life and consistent performance, especially during extended heavy-duty turning operations.

Q: How is the machine operated given it is not CNC controlled?

A: The SR1250 lathe uses a manual control system, enabling the operator to manage every step of the machining process. While it does not offer CNC automation, the semi-automatic grade provides manual engagement with added convenience features, such as integrated coolant and lubrication for smoother workflow.
