Tiger FU-3L Universal Milling Machine

Price 23000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tiger FU-3L Universal Milling Machine Specification

Model
FU-3L

Rotation
Both clockwise and counterclockwise

Product Type
Universal Milling Machine

General Use
Industrial milling operations, metalworking

Material
High-grade cast iron, alloy steel

Type
Horizontal & Universal

Capacity
Heavy Duty

Weight (kg)
Approx. 2650 kg

Computerized
No

Automatic
Semi-automatic

CNC Or Not
Not CNC

Control System
Conventional (Manual)

Table Size
1600 360 mm

Table Slide Way
Box type slideways

Floor Space
2550 2150 mm

Spindle Speed
301500 rpm (graduated in 18 steps)

Power
5 HP (Main Motor)

Voltage
415 V (Three Phase)

Dimension (L*W*H)
Approx. 2550 2150 1850 mm

Feature
Swiveling table, hardened slideways, robust construction

Color
Green/Off White

Table Cross Travel
320 mm

Feed Range (Vertical)
8262 mm/min

Rapid Feed (Vertical)
770 mm/min

Main Electric Motor
5 HP / 3.7 kW

Table Longitudinal Travel
1000 mm

Coolant Pump Motor
0.18 kW

Table Vertical Travel
400 mm

Maximum Milling Cutter Diameter
125 mm

Feed Range (Longitudinal & Cross)
23785 mm/min

Spindle Taper
ISO 50

Rapid Feed (Longitudinal & Cross)
2300 mm/min

Distance Between Spindle Centre and Table Top
30430 mm

Overarm Travel
800 mm

Number of Feeds
18

Distance from Spindle Centre to Column Vertical Guideway
375 mm

Tiger FU-3L Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Tiger FU-3L Universal Milling Machine

Make - Tiger (Italy)

Model - FU-3L

Table Size - 1525 mm x 310 mm

XYZ Travel - 1050 mm x 300 mm x 470 mm

Spindle Taper - ISO 50

Spindle Speeds - 27 rpm to 1600 rpm

Feed Rates of Table Travel - 9 mm/min to 500 mm/min

- Equipped with 3-Axis DRO.

- Rotating type Universal Table.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/n14SHjyHsmc

Precision Engineering for Industrial Applications

Built with box-type slideways and a swiveling table, the Tiger FU-3L delivers both rigidity and versatility. Its robust frame and hardened components ensure smooth operation and precision, even under continuous heavy-duty milling. This model is particularly suitable for workshops focused on productivity and accuracy.

Flexible and Efficient Operations

The Tiger FU-3L supports both clockwise and counterclockwise spindle rotation and features rapid feed options for longitudinal, cross, and vertical movements. This allows for efficient machining of complex components, reducing setup and processing time on the shop floor.

FAQs of Tiger FU-3L Universal Milling Machine:

Q: How does the Tiger FU-3L Universal Milling Machine improve machining efficiency?

A: The Tiger FU-3L enhances efficiency with rapid feedsup to 2300 mm/min longitudinally and 770 mm/min vertically. The 18 feed rates and quick spindle speed changes streamline operations, significantly reducing setup and machining times in industrial environments.

Q: What materials and industries is the Tiger FU-3L ideally suited for?

A: Constructed from high-grade cast iron and alloy steel, the machine handles a wide range of metals and heavy-duty industrial applications, including manufacturing, metal fabrication, and engineering workshops requiring universal milling capabilities.

Q: Where can the Tiger FU-3L be installed and operated safely?

A: The machine requires a floor space of approximately 2550 2150 mm and is best installed in well-ventilated, industrial-grade workshops or factories with a reliable three-phase 415V power supply, ensuring optimal operation and safety.

Q: What is the process for operating the Tiger FU-3L, given its manual control system?

A: Operators position the workpiece on the 1600 360 mm table, select appropriate speeds and feeds, and manually control movements using the conventional interface. The swiveling table and overarm facilitate different milling processes, including horizontal and angular operations.

Q: What are the benefits of using the Tiger FU-3L for metalworking tasks?

A: Users benefit from its heavy-duty capacity, precise feed control, and versatility for both horizontal and universal milling. Its hardened slideways and robust construction ensure long-term reliability and accuracy across diverse metalworking projects.

Q: When should the machines rapid feed functions be utilized?

A: Rapid feeds should be used during non-cutting movements, such as positioning the table before or after milling, to save time and increase workflow efficiency. For cutting operations, suitable feed rates must be selected to maintain accuracy and tool longevity.

Q: How does the swiveling table enhance usage flexibility?

A: The swiveling table feature allows operators to perform angular and complex contour milling without repositioning the workpiece, increasing the machines flexibility for intricate jobs and reducing the need for additional setup steps.
