TOS Czech BPH-20 Hydraulic Surface Grinder Machine

Name: TOS Czech BPH-20 Hydraulic Surface Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS Czech BPH-20 Hydraulic Surface Grinder Machine Specification

Rotation
Manual/Auto Table Rotation

Model
BPH-20

Product Type
Surface Grinder Machine

General Use
Precision surface grinding

Material
Cast Iron

Type
Hydraulic Surface Grinder

Capacity
High precision

Weight (kg)
1800 kg

Computerized
No

Automatic
Semi Automatic

CNC Or Not
Not CNC

Control System
Hydraulic

Table Size
200 x 500 mm

Table Slide Way
V and flat guideways

Magnetic Chuck Size
200 x 500 mm

Grinding Wheel Size
200 x 13 x 76 mm

Grinding Wheel Speed
2850 RPM

Grinding Length
500 mm

Floor Space
1750 x 1450 mm

Fuel Tank Capacity
45 liters

Spindle Speed
2850 RPM

Power
3.5 kW

Voltage
415 V

Dimension (L*W*H)
1750 x 1450 x 1700 mm

Feature
Heavy Duty Construction

Color
Green & White

Lubrication
Centralized

Working Speed
Adjustable

Longitudinal Table Feed
Auto & Manual

Max Grinding Height
300 mm

Table Travel
550 mm

Coolant System
Included

Machine Condition
Used/Excellent

Cross Feed
Auto & Manual

TOS Czech BPH-20 Hydraulic Surface Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS Czech BPH-20 Hydraulic Surface Grinder Machine

Make - TOS (Czech Republic)

Model - BPH-20

Grinding Capacity - 200 mm x 630 mm

Magnet Size - 200 mm x 600 mm

Grinding Wheel Size - Diameter 250 mm x 25 mm Width

Longitudinal Travel - 690 mm

Cross Travel - 225 mm

Max. Distance b/w Magnet Top to Wheel Center - 275 mm

- Motorised Rapid Vertical Travel of the Wheel-Head.

- Feature of Automatic Depth Adjustment "Auto-Cut".

- Complete with Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/GQaRFe0xp7s

High Precision Grinding

The BPH-20 boasts a grinding length of 500 mm and employs both V and flat guideways for its table slide, optimizing accuracy. Its magnetic chuck and heavy-duty build ensure stability during operation, making it suitable for fine-tolerance engineering and metalworking applications.

Flexible Operation Modes

Operators can select between auto and manual feed for both longitudinal and cross movements, offering adaptability for various workpiece requirements. The semi-automatic hydraulic control allows smooth transitions and precise control, enhancing both productivity and safety.

Efficient Cooling and Lubrication

Equipped with a centralized lubrication system and a built-in coolant system, the BPH-20 maintains optimal temperature and reduces friction, extending machinery life and ensuring consistent grinding quality even during extended usage.

FAQ's of TOS Czech BPH-20 Hydraulic Surface Grinder Machine:

Q: How does the TOS Czech BPH-20 ensure high precision in surface grinding?

A: The BPH-20 integrates V and flat guideways for table slide stability, a rigid cast iron structure, and a magnetic chuck measuring 200 x 500 mm, all of which collectively enable consistent, high-precision grinding results.

Q: What types of operations can be performed on this machine?

A: This model supports both automatic and manual table feeds for longitudinal and cross movements, allowing for a variety of grinding operations, including high-precision flat surface grinding and rapid material removal tasks.

Q: When is it recommended to use the coolant system?

A: The integrated coolant system should be engaged during all grinding operations, particularly for prolonged runs or when working with heat-sensitive materials, to prevent thermal distortion and ensure a fine finish.

Q: Where is the centralized lubrication system advantageous?

A: Centralized lubrication simplifies machine maintenance and guarantees constant lubrication of critical components, reducing wear, enhancing accuracy, and extending the operational lifespan-especially useful in continuous production environments.

Q: What is the process for adjusting the grinding speed on the BPH-20?

A: The grinding wheel and spindle speeds can be adjusted up to 2850 RPM, allowing operators to tailor the machine's performance to different materials and surface finish requirements directly via control settings.

Q: How does the machine handle heavy-duty and continuous grinding tasks?

A: Thanks to its robust 1800 kg construction, 3.5 kW power, heavy-duty hydraulic system, and centralized lubrication, the BPH-20 delivers reliable, continuous performance for industrial applications requiring sustained precision and durability.
