Wotan Horizontal Rotary Surface Grinder

Name: Wotan Horizontal Rotary Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Wotan Horizontal Rotary Surface Grinder Specification

Rotation
Table rotary

Model
Wotan

Product Type
Rotary Surface Grinder

General Use
Surface grinding of metal workpieces

Material
Cast Iron Body

Type
Horizontal Rotary

Capacity
Up to 600 mm diameter

Weight (kg)
3500 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
600 mm

Table Slide Way
Rotary

Magnetic Chuck Size
600 mm

Grinding Wheel Size
400 mm

Grinding Wheel Speed
1440 RPM

Grinding Length
600 mm

Floor Space
2200 mm x 1800 mm

Fuel Tank Capacity
50 Liters (Hydraulic)

Spindle Speed
1440 RPM

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
2200 mm x 1800 mm x 2000 mm

Feature
High precision, robust construction

Color
Grey

Chuck Type
Electromagnetic

Lubrication System
Automatic

Maximum Workpiece Height
350 mm

Grinding Accuracy
±0.005 mm

Applications
Tool rooms, Die & Mould making, Foundries

Table Load Capacity
Approx. 800 kg

Table Drive
Hydraulic

Working Speed
Variable

Coolant System
Provided

Made in
Germany

Minimum Increment
0.01 mm

Wotan Horizontal Rotary Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Wotan Horizontal Rotary Surface Grinder

Make - Wotan (Germany)

Table Diameter - 600 mm

Max. Job Diameter - 850 mm

Max .Grinding Wheel Diameter - 400 mm

Max .Grinding Wheel Width - 50 mm

Max. Table Travels - 450 mm

Max. Height between Table Top to Wheel Center - 355 mm

Least Count - 5 Microns (0.005 mm)

- 3-Step Table Rotation Speeds.

- Feature of Automatic Depth Adjustment "Auto-Cut".

- Complete with lots of spare NEW Wheels, Wheel Flange etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/yvi4B8lfWRQ

Precision and Durability

Built with a cast iron body and robust construction, the Wotan Horizontal Rotary Surface Grinder delivers exceptional precision and stability. With grinding accuracy maintained at 0.005 mm and features such as automatic lubrication and a hydraulic table drive, users can rely on consistent results even under heavy-duty conditions.

Versatile Applications

This surface grinder is highly suitable for tool rooms, die and mould manufacturing, and foundry operations, handling metal workpieces up to 600 mm in diameter and 350 mm in height. The variable working speed and electromagnetic chuck enhance operational flexibility and ensure secure clamping during grinding.

German Engineering Excellence

Manufactured in Germany, the Wotan model embodies quality and reliability. The combination of high-precision components, effective coolant and lubrication systems, and manual control makes this machine a trusted choice for manufacturers, exporters, importers, suppliers, and traders worldwide.

FAQ's of Wotan Horizontal Rotary Surface Grinder:

Q: How does the Wotan Horizontal Rotary Surface Grinder achieve high precision in surface grinding?

A: The grinder features robust cast iron construction, a rotary table guided on precise slide ways, and an electromagnetic chuck for stable work holding. It achieves a high grinding accuracy of 0.005 mm and allows fine adjustments with its 0.01 mm minimum increment, ensuring superior surface finishes on metal parts.

Q: What types of workpieces and industries is this grinder suitable for?

A: This machine is ideal for surface grinding of metal workpieces in tool rooms, die and mould manufacturing, and foundry operations. Its 800 kg table load capacity and 600 mm table size make it suitable for a wide range of medium-to-large industrial applications.

Q: When should the coolant and lubrication systems be maintained?

A: Routine checks and maintenance should be performed according to the manufacturer's schedule, especially after continuous use in heavy-duty settings. The coolant system protects workpieces from heat, while the automatic lubrication system ensures smooth operation of moving parts, both critical for prolonging machine life.

Q: Where is the Wotan Horizontal Rotary Surface Grinder manufactured?

A: This model is made in Germany, known for its engineering excellence and rigorous manufacturing standards, ensuring top-tier build quality and performance.

Q: What is the grinding process on this model?

A: The manual control system allows precise operation, with the hydraulic rotary table securely holding and rotating the workpiece beneath the 400 mm grinding wheel. The table's variable speed and electromagnetic chuck optimize grinding efficiency and safety during prolonged use.

Q: How does the electromagnetic chuck benefit the operator during surface grinding?

A: The 600 mm electromagnetic chuck offers strong and uniform clamping force, preventing slippage of the metal workpiece and maintaining precise positioning, essential for achieving consistent high-quality surface finishes.

Q: What are the main benefits of using this surface grinder for industrial operations?

A: Key advantages include high grinding accuracy, robust construction for durability, flexibility in handling different workpiece sizes, ease of operation with manual controls, efficient coolant and lubrication systems, and overall reliability, making it a valuable asset for various metalworking industries.
