XYZ England 400 mm x 800 mm Surface Grinder Machine

Name: XYZ England 400 mm x 800 mm Surface Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

XYZ England 400 mm x 800 mm Surface Grinder Machine Specification

Model
XYZ England

Rotation
Standard

Product Type
Surface Grinder Machine

General Use
Precision surface grinding operations

Material
Cast Iron

Type
Surface Grinder

Capacity
Heavy Duty

Weight (kg)
2500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
400 mm x 800 mm

Table Slide Way
Box type hardened

Magnetic Chuck Size
400 mm x 800 mm

Grinding Wheel Size
355 mm x 38 mm x 127 mm

Grinding Wheel Speed
2800 rpm

Grinding Length
800 mm

Floor Space
Approx. 2800 mm x 1700 mm

Fuel Tank Capacity
60 liters

Spindle Speed
2800 rpm

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2800 mm x 1700 mm x 1700 mm

Feature
High Precision, Sturdy Construction

Color
Blue & White

Working Speed
Variable

Lubrication System
Automatic

Handwheel Increment
0.01 mm

Max Workpiece Weight
600 kg

Hydraulic Oil Grade
HP 68

Longitudinal Table Speed
Up to 22 m/min

Vertical Feed Travel
350 mm

Table Cross Travel
400 mm

Surface Finish
Up to 0.2 microns Ra

Coolant System
Built-in

Minimum Feed
0.005 mm

Application
Tool room, Die shop, Engineering industries

XYZ England 400 mm x 800 mm Surface Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

XYZ England 400 mm x 800 mm Surface Grinder Machine About

Make - XYZ (England)

Model - 1632

Magnet Size - 400 mm x 800 mm

Longitudinal Travel of Table - 900 mm

Cross Travel of Table - 500 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Height between Table Top to Wheel Center - 500 mm

Least Count of Vertical Travels - 1 Micron (0.001 mm)

Least Count of Cross Travels - 1 Micron (0.001 mm)

- Micro-Feed Travels in both Cross & Vertical Travels.

- Equipped with a wheel-top Mounted Wheel Dresser.

- Complete with Dust Collector, Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/vMuGbTjgwGI

Engineered for Precision Surface Grinding

The XYZ England Surface Grinder delivers exceptional accuracy, with handwheel increments as fine as 0.01 mm and a table cross travel of 400 mm. Its heavy-duty, rigid cast iron construction minimizes vibration, ensuring high surface finish and dimensional consistency on each job-ideal for precision work in tool rooms and engineering workshops.

Built-In Features for Enhanced Productivity

Equipped with an automatic lubrication system, a built-in coolant unit, and variable working speed, this surface grinder increases productivity and extends machine life. The integrated hydraulic system and box-type hardened slide ways ensure smooth, precise table movement for efficient material removal and fine surface finishes.

FAQ's of XYZ England 400 mm x 800 mm Surface Grinder Machine:

Q: How does the XYZ England Surface Grinder achieve high precision in operations?

A: The machine utilizes metric feed increments as small as 0.005 mm and handwheel adjustments of 0.01 mm, combined with a box-type hardened table slide way for stable, precise movement. This allows for exceptional surface finish quality and exact sizing.

Q: What materials and industries is this surface grinder suitable for?

A: This model is ideal for precision grinding operations in tool rooms, die shops, and engineering industries. Its heavy-duty capacity and high-precision capabilities make it perfect for use with a variety of tools, dies, and engineering components, especially those up to 600 kg.

Q: When should I perform maintenance on the lubrication and coolant systems?

A: The surface grinder features an automatic lubrication system, reducing manual maintenance. However, you should regularly check lubricant and coolant levels, inspect lines for blockages or leaks, and replace filters as part of a routine maintenance schedule to maximize operational reliability.

Q: Where can this surface grinder be installed considering its size and power requirements?

A: Due to its sizeable floor space requirement (2800 mm x 1700 mm) and 7.5 HP, 415 V power supply, this machine should be installed in an industrial setting such as a workshop or factory that can support heavy machinery and has suitable electrical infrastructure.

Q: What process does the built-in coolant system support during grinding operations?

A: The built-in coolant system supports grinding by continuously cooling both the workpiece and the wheel. This minimizes thermal expansion, prevents material burning, and helps achieve a high-quality surface finish-even on demanding jobs.

Q: How does the variable working speed benefit users during grinding tasks?

A: Variable working speed allows operators to tailor the grinding speed according to material hardness, workpiece thickness, and required surface finish. This flexibility enhances productivity while ensuring optimal results for different grinding applications.
