TOS 200 mm x 600 mm Surface Grinding Machine

Send Inquiry

Request To Call Back

TOS 200 mm x 600 mm Surface Grinding Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 200 mm x 600 mm Surface Grinding Machine Specification

Rotation
Left / Right

Model
TOS 200 x 600

Product Type
Surface Grinding Machine

General Use
Precision surface grinding of metal components

Material
Heavy Duty Cast Iron

Type
Hydraulic / Manual

Capacity
High Precision

Weight (kg)
Approx. 1500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
200 mm x 600 mm

Table Slide Way
V & Flat Guideways

Magnetic Chuck Size
200 mm x 600 mm

Grinding Wheel Size
200 mm x 13 mm x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
600 mm

Floor Space
Approx. 1800 mm x 1600 mm x 1800 mm

Spindle Speed
2800 RPM

Power
3 HP

Voltage
415 V

Dimension (L*W*H)
Approx. 1800 mm x 1600 mm x 1800 mm

Feature
Robust Construction, Smooth Finish, Accurate Grinding

Color
Blue & White

TOS 200 mm x 600 mm Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS 200 mm x 600 mm Surface Grinding Machine

Make - TOS (Czech Republic)

Model - BPH 20

Magnet Size - 200 mm x 600 mm

Grinding Wheel Diameter - 250 mm

Grinding Wheel Width - 38 mm

Longitudinal Travel - 650 mm

Cross Travel - 230 mm

Max. Distance b/w Magnet Top to Wheel Center - 320 mm

- Motorised Rapid Vertical Travel of the Wheel-Head.

- Features like Auto-Cut, Rapid Movement of Cross Travel etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/Lw2Dt7A4p08

Engineered for Precision

The TOS 200 x 600 Surface Grinding Machine delivers exacting tolerances with a grinding accuracy of 0.002 mm, making it suitable for tasks demanding the utmost precision. The robust heavy-duty cast iron body minimizes vibration during operation, enhancing the smoothness and accuracy of each grinding cycle.

Flexible and Robust Design

Featuring a spacious 200 mm x 600 mm table, this machine accommodates a broad array of metal components. The variable table speed (325 m/min) and electro-magnetic chuck control ensure the flexibility to handle diverse workpieces, while the automatic lubrication and integrated coolant systems drive consistent performance.

User-Friendly Manual Operation

Control and adjustments are straightforward thanks to a graduated hand wheel with 0.01 mm increments and a manual, non-CNC control system. The practical design supports manufacturers, exporters, and suppliers who value manual precision and reliability in their production workflows.

FAQs of TOS 200 mm x 600 mm Surface Grinding Machine:

Q: How does the TOS 200 x 600 Surface Grinding Machine ensure high precision in grinding tasks?

A: This model achieves a grinding accuracy of 0.002 mm through its rigid cast iron construction, stable V & flat guideways, and fine hand wheel graduation of 0.01 mm. The integrated coolant and automatic lubrication systems further enhance precision by reducing thermal deformation and friction.

Q: What types of components can be processed with this surface grinding machine?

A: The TOS 200 x 600 is suitable for high-precision grinding of flat metal components up to 600 mm in length and 200 mm in width. It is commonly used in tool rooms, manufacturing, and repair workshops requiring quality surface finishes.

Q: When should I use the automatic lubrication and coolant systems?

A: Both the centralized automatic lubrication and the coolant system should be engaged during extended or intensive grinding sessions. These systems maintain consistent operation, reduce wear, and help prevent excessive heating, ensuring longer machine life and reliable results.

Q: Where is the TOS 200 x 600 surface grinding machine typically installed?

A: Due to its robust build and substantial floor space requirement (approx. 1800 mm x 1600 mm x 1800 mm), this machine is ideal for installation in industrial manufacturing facilities, tool rooms, or specialized engineering workshops focusing on precision metalworking.

Q: What is the process for operating this machine?

A: The operator manually secures the metal workpiece onto the electro-magnetic chuck, sets table travel and speed, and adjusts the grinding wheel as needed. Manual controls guide the grinding process, while the lubricant and coolant systems work automatically to maintain optimal conditions throughout the operation.

Q: How does the machine benefit manufacturers and exporters?

A: This model offers reliable, repeatable, and highly accurate grinding, which helps improve product quality, reduce scrap rates, and support efficient production exports. Its robust design ensures durability and low maintenance, making it cost-effective for high-precision batch work.
