TOS FGUE-32 Universal Double Spindle Milling Machine

Name: TOS FGUE-32 Universal Double Spindle Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FGUE-32 Universal Double Spindle Milling Machine Specification

Rotation
Both horizontal and vertical spindle rotation

Model
FGUE-32

Product Type
Double Spindle Universal Milling Machine

General Use
Milling various materials, gear cutting, drilling, slotting, universal operations

Material
Cast iron and alloy steel

Type
Universal Mill

Capacity
Longitudinal table travel 900 mm

Weight (kg)
2200 kg

Computerized
No

Automatic
Feed automatic

CNC Or Not
Not CNC (Conventional)

Control System
Manual

Table Size
1250 x 320 mm

Table Slide Way
Box type

Floor Space
1870 x 1700 mm

Fuel Tank Capacity
25 L (coolant tank)

Spindle Speed
56 1800 rpm (16 steps)

Power
4 kW (main motor)

Voltage
3 Phase, 400V, 50Hz

Dimension (L*W*H)
1870 x 1700 x 1780 mm

Feature
Double spindle, universal head, strong rigidity, high accuracy

Color
Green/Grey

WorkingSpeed
Feed range 12 630 mm/min

Horizontal Spindle Speed Range
45 1400 rpm

Max. Table Load
400 kg

Spindle Taper
ISO 40

Maximum Distance Between Table and Spindle Nose
400 mm

Number of Feeds
18

Coolant Pump Power
40 W

Lubrication Type
Centralized and manual

Vertical Spindle Power
2.2 kW

Travel of Knee (Vertical)
400 mm

Minimum Feed
12 mm/min

Vertical Spindle Speed Range
56 1800 rpm

Travel of Cross Slide
320 mm

Horizontal Spindle Power
2.8 kW

Swivel Angle of Universal Head
45

Rapid Feed
1800 mm/min

Table Swivel
45

TOS FGUE-32 Universal Double Spindle Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FGUE-32 Universal Double Spindle Milling Machine

Make - TOS (Czech Republic)

Model - FGUE-32

Table Size - 1250 mm x 320 mm

XYZ Travels - 850 mm x 280 mm x 425 mm

Horizontal Spindle Speeds - 31.5 rpm to 1400 rpm

Vertical Spindle Speeds - 45 rpm to 2000 rpm

Spindle Taper - ISO 50

Table Feed Rates of Travel - 14 mm/min to 900 mm/min

Over-Arm Travel of Vertical Head Slide - 700 mm

- Feature of Automatic Up/Down of Table by 0.5 mm.

- Equipped with a 3-Axis DRO.

- Rotating type Universal Table.

- Complete with many Tool Holders, Cutters, Collets & other accessories.

- Double Swivel type Vertical Milling Head suitable for Angular Milling Operations.

- Machine is capable of Horizontal, Vertical & Angular Milling Operations.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/Z1g0JF59erc

Versatile Dual Spindle Design

The FGUE-32 features both vertical and horizontal spindles, allowing the operator to perform a wide array of milling, drilling, and gear cutting functions in a single setup. Its universal head adjusts 45 and allows the table to swivel, giving superior flexibility for complex jobs and profile machining.

Enhanced Precision and Reliability

The machine is constructed from heavy-duty cast iron and alloy steel, providing vibration damping and excellent structural strength. Centralized and manual lubrication makes maintenance straightforward, while box-type table slide ways ensure accuracy and long-term durability.

High Performance and Efficiency

With a rapid feed of 1800 mm/min and a powerful main motor of 4 kW, the FGUE-32 is optimized for high productivity. Its large 1250 x 320 mm table supports up to 400 kg, and the automatic feed system increases efficiency for repetitive or long-cycle jobs.

FAQ's of TOS FGUE-32 Universal Double Spindle Milling Machine:

Q: How does the TOS FGUE-32 Universal Double Spindle Milling Machine improve operational flexibility?

A: The FGUE-32 offers both vertical and horizontal spindle configurations, supported by a universal head that swivels 45. This allows multiple milling, drilling, and slotting processes without frequent workpiece repositioning, making it ideal for complex and custom jobs.

Q: What materials can be processed with the FGUE-32 milling machine?

A: The FGUE-32 is suitable for a variety of materials, including stainless steel, cast iron, and alloy steel, thanks to its strong rigidity and powerful spindles. Its high maximum table load and universal operations make it versatile for various industry requirements.

Q: When should centralized lubrication be used on this milling machine?

A: Centralized lubrication should be routinely engaged before long machining sessions and periodically during operation as part of scheduled maintenance, ensuring all moving parts remain optimally lubricated for smooth and accurate performance.

Q: Where can the TOS FGUE-32 be installed, and what is the required floor space?

A: The machine should be installed in a well-ventilated industrial workshop with a level floor. It covers a floor space of 1870 x 1700 mm and stands 1780 mm tall, so ensure sufficient clearance around the unit for operation and maintenance.

Q: What is the process for changing between horizontal and vertical spindle milling?

A: Operators can switch between horizontal and vertical spindles by adjusting the universal head and selecting the desired spindle. Both spindles have dedicated controls and power sources, so transition is straightforward and quick, minimizing downtime between processes.

Q: How does the automatic feed system benefit regular milling operations?

A: The automatic feed system supports adjustable feed rates from 12 to 630 mm/min, streamlining repetitive tasks, improving accuracy, and reducing operator fatigue, which is especially advantageous in large batch or long-cycle production runs.

Q: What types of industries benefit most from the FGUE-32 milling machine?

A: Manufacturers, exporters, importers, and suppliers needing reliability, versatility, and precision across various machining applications-including gear cutting and slotting-will find the FGUE-32 particularly effective due to its robust build and universal operational capabilities.
